BRX Do-More PLC Monitoring and Testing the Program

We will now look at monitoring and testing our BRX Do-More program in our controller. Our first program for the BRX Do-More PLC involved a start-stop jog circuit. We will now use the Do-More Designer Software to monitor, test, and modify this program. As a system integrator, this ability can prove very useful to you in the field when troubleshooting your automation system. We will be monitoring the ladder logic status and bits. Changing the bit status will be done by forcing the inputs and outputs. Here is a link explaining the logic behind our circuit. How to Make a Start Stop Jog Circuit in a PLC https://accautomation.ca/how-to-make-a-start-stop-jog-circuit-in-a-plc/ Let’s get started! More information can be obtained at our website. This includes all of the links mentioned in this video. http://accautomation.ca/brx-plc-monitoring-and-testing-the-program Previously in this BRX Do-More Series PLC, we looked at the following: System Hardware https://accautomation.ca/brx-plc-system-hardware System Hardware Video https://youtu.be/wSYgY09VYeA Unboxing Video https://youtu.be/-Tf8m3BqzPo Installing the Software https://accautomation.ca/brx-plc-installing-the-software Installing the Software Video
