BRX Do-More PLC Drum Instruction Sequence

We will now look at the drum instruction in our BRX Do-More Controller. Drum instructions are great tools when you have a simple sequence of events that need to occur at a set time interval or as a result of an event. They mimic an electromagnetic drum sequencer. The BRX Do-More Series PLC has a drum in the instruction set. Have you ever seen the mechanisms of a music box? Ok, so it’s a little drum with pegs that catch and flick the chimes in a particular sequence to play whatever tune is on the drum. So in the PLC, you can have a drum driven by an event, (input from a limit switch or button), or by time. We will discuss the drum instruction and look at an example of controlling traffic lights with a crosswalk signal. More information can be obtained at our website. This includes all of the links mentioned in this video. https://accautomation.ca/brx-plc-drum-instruction Previously in this BRX Do-More Series PLC, we looked at the following: System Hardware https://accautomation.ca/brx-plc-system-hardware System Hardware Video https://youtu.be/wSYgY09VYeA Unboxing Video https://youtu.be/-Tf8m3BqzPo Installing the Software https://accautomation.ca/brx-plc-installing-the-software Installing the Software Video https://youtu.be/iFI1ebP8Zkk Establishing Communication https://accautomation.ca/brx-plc-establishing-communication Establishing Communication Video
