Hello friends welcome to Solid Works
0:01
tutorial and in this tutorial we will
0:05
block as you can see that uh I have
0:08
already modeled it and I will show you
0:10
from the scratch how you can model from
0:12
the scratch so I will close this file
0:14
and create a new file you can also visit
0:18
my website macn nexus.com and you can
0:22
visit this solid works tutorials tab
0:24
where I have written so many tutorials
0:28
on uh solid works where you can follow
0:31
the step by step guide to model the
0:35
parts if you like my method of teaching
0:38
then you can also support me on kofi.com
0:41
you can buy me a cup of coffee your
0:45
small support will help these channels
0:47
to grow and it will motivate me to
0:50
create more awesome content on solid
0:52
works so let's come back to our
0:56
tutorial so here I have created a new
1:00
we can see in our drawing that our
1:02
dimensions are in inches so we will
1:08
then we will select this Top Lane and
1:14
sketch and we will create a
1:28
in and uh from the center it is
1:39
1.25 and uh we will select this line and
1:42
this origin point and add the
1:46
constraint select uh smart Dimension and
1:57
4.75 and now we will close it
2:02
press control 7 for isometric and we
2:05
will select the sketch and click on
2:07
extrude and add the material of A5
2:16
now we will add the material here so for
2:20
this uh we will select this side of a
2:23
face and uh click on the
2:27
sketch and uh we will select the line
2:44
line and add the 3point
2:58
uh we will uh add the
3:04
uh we will add this uh AR point and this
3:08
H and add a coincidence constraint and
3:12
select smart Dimension and uh give the
3:22
1.38 and this height is of 1.38
3:30
which is the same now we will Define
3:43
2.05 now we will uh come out of the
3:47
sketch select the sketch click on
3:53
reverse and uh from here select up to
4:02
now we will uh add the fillet here so
4:07
select the fillet and give the fillet of
4:24
now we will uh create this uh material
4:29
we will add the material and for this we
4:32
will create a datm plane so select the
4:35
phase and uh click on the
4:38
plane and give it a 75 and uh say it a
4:44
flip offset and uh say okay now select
4:48
the plane and click on the
4:52
sketch and now they will select this age
4:58
entities and and uh make it
5:01
normal and now we will draw the
5:05
two one horizontal line and one vertical
5:14
line now our sketch is fully
5:18
constrained we will select a sketch and
5:22
extrude and we will flip it and add
5:36
height and now we will uh create a cut
5:41
so for this we will select this phase
5:46
sketch we will select this age and click
5:51
entities select it and make it for
5:58
now we we will make this
6:02
normal and here we will
6:08
circle and uh create a
6:13
circle now we will come out of
6:17
it and we will uh remove the
6:22
material to this pH so select the sketch
6:28
Cut and from here select uh up to
6:31
surface and select this surface click on
6:36
okay now we will remove the material
6:40
here so we will again select this phas
6:42
and click on the sketch select the
6:45
circle and uh create a
6:51
circle of a 2 in dimension
7:04
it and uh create a cut of
7:09
a88 in select the sketch click on extrud
7:14
Cut and give 88 in click on
7:21
okay now press control 7 for isometric
7:28
will create this hole so we will select
7:31
this phase and click on the sketch click
7:39
circle and uh give the smart
7:44
Dimension and give it
8:04
sketch and click it through all say
8:12
now we will create one hole here so we
8:16
will select the phase and click on the
8:18
sketch press control 7 for isometric and
8:26
circle and uh give the dimension of
8:35
75 and uh from here to here it is a
8:57
and we will uh come out of the
9:00
sketch and click on extrude
9:04
Cut and from here we will say true all
9:12
okay so now you can see that we have
9:16
successfully modeled this shoe block
9:18
from scratch in solid works and I hope
9:20
you have enjoyed this tutorial if you
9:23
have enjoyed this tutorial then please
9:24
like subscribe and share my channel and
9:27
also support me on coffee.com you can
9:29
buy me a cup of coffee your small
9:32
support will help this channel to grow
9:34
and it will motivate me to create more
9:36
awesome content on solid works link is
9:38
given in a video description thank you
9:40
for watching and thank you for your
