Hello friends welcome to Solid Works
0:02
tutorial and in this tutorial we will
0:04
model this coffee Mark in solid works so
0:08
let's start our tutorial and I will show
0:10
you from the scratch how you can do the
0:14
works so I will close this file and I
0:17
will create a new file you can also
0:20
visit my website macn nexus.com and you
0:24
can visit this solid works tutorials tab
0:27
where I have written so many tutorials
0:31
on solid works where you can follow the
0:34
stepbystep guide to model the
0:37
parts if you like my method of teaching
0:40
then you can also support me on kofi.com
0:43
you can buy me a cup of coffee your
0:47
small support will help these channels
0:49
to grow and it will motivate me to
0:52
create more awesome content on solid
0:54
works so let's come back to our tutorial
1:01
so here I have uh created a new file now
1:04
I will select the top
1:06
plane and here we will create a
1:14
circle select smart Dimension and I will
1:18
give it a diameter of 80
1:22
mm and now I will close
1:25
it press contrl 7 for isometric view
1:29
select this page click on exclude
1:32
boss and give the height 95
1:41
okay now we will use the shell command
1:45
to remove the material select the top
1:53
here tick mark the shell
1:56
outwards and uh give the thickness of a
2:04
okay so you can see that uh material is
2:12
outside this is the body of our coffee
2:14
mug now we will uh select the front
2:19
plane and create a sketch now we will
2:22
make the handle of our coffee MK we will
2:32
we will uh create a rough
2:42
sketch we will add the
2:46
fillet click on the fillet and give the
3:03
origin we will uh fix our
3:07
Dimension so from here I will give it uh
3:17
42.5 and uh I will add the vertical
3:22
relation and from the
3:25
origin to the top of the line I will
3:35
and from bottom to this
3:37
point we will give 25
3:44
mm and this Center to this
3:52
Center or we will simply give this
4:12
from this Center to this point we will
4:19
mm so this is the our handle
4:23
profile we will come out of the
4:30
we will create a datm plane at the mid
4:33
of this so for this we will select a
4:37
plane select this point and this
4:41
line and click okay now we have datam
4:44
plane now we will select this plane and
4:53
direction as this is the 25 mm so we
4:57
will give the 12.5 mm
4:59
click on okay now we will hide our first
5:04
plane and now we will create profile on
5:08
this plane select this
5:12
plane right click and select
5:15
sketch now make this view
5:20
normal now here we will select this
5:24
point and click on convert entities so
5:27
that point is projected here
5:45
slot we will use the center
6:01
from this point to this is the 2.5
6:05
Dimension and give it uh
6:18
R5 move the dimension so this is the our
6:24
profile which is fully constrained now
6:26
we will come out of the sketch press
6:31
7 we will hide our dat temp
6:34
plane now we will sweep
6:38
it so click on accept boss
6:46
profile and then select this guided
6:49
curve and from here select in the both
6:52
the direction this middle one and say
6:56
okay so you can see that uh coffee mug
7:02
created now we will beautify our coffee
7:06
mug with some fillets so we will select
7:12
Edge and this inner Edge and uh bottom
7:21
fillet and we will apply the fillet of 1
7:30
so this is how we have created a coffee
7:33
mug in solid works this is all about
7:36
this tutorial thank you for watching and
7:39
thank you for your valuable time
