Hello friends welcome to Solid Works
0:02
tutorial and in this tutorial we will
0:04
learn the Revol tool in solid
0:08
works for Revol tool we need two things
0:12
first is a center line and second is a
0:15
profile so as you can see in the image
0:18
we have the center lines Mark as a b and
0:22
profile as a a and when we revolve we
0:25
will get this profile C so let's start
0:29
you can also visit my website macn
0:32
nexus.com and you can visit this solid
0:36
works tutorials tab where I have written
0:40
so many tutorials on solid works where
0:43
you can follow the step byst step guide
0:48
parts if you like my method of teaching
0:51
then you can also support me on kofi.com
0:54
you can buy me a cup of coffee your
0:58
small support will help this channels to
1:00
grow and it will motivate me to create
1:03
more awesome content on solid works so
1:07
let's come back to our
1:09
tutorial for this I will just selected
1:16
sketch and first I will uh create a
1:23
line and I will select this line and
1:31
I will select the line tool and I create
1:47
image now we will uh give the rough
1:51
dimension for this profile
1:57
a so first I will make it
2:01
horizontal and now I will give the
2:03
dimension so first I will constrain my
2:07
diameter select the smart
2:13
Dimension if you drag it on the other
2:16
side then it will be a
2:19
diameter so diameter I give
2:28
150 and this diameter I will give
2:34
now I will give my length of 100
2:42
mm and I move it to the
3:03
and I will add vertical relation with
3:13
thickness I will give 20
3:19
mm so now we have a fully constrained
3:23
sketch and now we will uh come out of
3:30
and we will click on the revolve boss
3:33
base and we will select our Center Line
3:36
of a revolution so you can see that uh
3:49
Angle now if we edit the feature then we
3:53
can find the multiple option of the
3:56
Revolution here is the angle and uh you
4:02
can increase or decrease the angle as
4:05
you can see that uh I want only 180° of
4:11
rotation and symmetric to the plane so
4:15
you can see that uh it is a 180° with my
4:20
plane 90° on one side and 90° on the
4:25
other side you can choose blind options
4:30
and uh you can set the angle as you want
4:34
like if I want only 60° of rotation then
4:45
60° so you can see that it is only 60°
4:48
of rotation with respect to my profile
4:51
now let's again edit the
4:54
feature and here you will have option of
4:58
uh direction to if if you check it then
5:02
you can see that uh other side also we
5:06
have a blind options and it is a
5:09
60° you can set the angle as per your
5:13
choice for example in a one side I want
5:16
60 and other side I want only 30° of
5:20
rotation then I can set
5:25
it now we again edit the features and
5:29
you can either use the both the
5:32
direction or Only One
5:34
Direction now let's uh give the angle of
5:47
okay so this is how to use the Revol
5:53
works this is all about this tutorial
5:55
thank you for watching and thank you for
