Hello friends welcome to Solid Works
0:01
tutorial and in this tutorial we will
0:04
model this uh angle bracket in solid
0:07
works as you can see that uh I have
0:10
already modeled it and I will show you
0:13
from the scratch how you can model this
0:15
simple part in solid works so this
0:18
tutorial is for the beginner user those
0:20
who have just started learning the part
0:23
modeling and I will close this file and
0:26
create a new file and uh I will show you
0:29
from the scratch so let's
0:33
start you can also visit my website macn
0:36
nexus.com and you can visit this solid
0:40
works tutorials tab where I have written
0:44
so many tutorials on solid works where
0:47
you can follow the stepbystep guide to
0:52
parts if you like my method of teaching
0:55
then you can also support me on kofi.com
0:58
you can buy me a cup of coffee your
1:02
small support will help these channels
1:04
to grow and it will motivate me to
1:07
create more awesome content on solid
1:09
works so let's come back to our tutorial
1:14
so here I have a created a new file and
1:17
if we see our drawing then we can find
1:20
that uh our base profile will become on
1:23
a right plane so we will select the
1:26
right plane and creat this base profile
1:29
and then we will will extrude it and
1:31
then we will create our rest of the
1:33
feature so we will select this right
1:35
plane and here I will select the line
1:43
uh create a rough profile similar to our
1:52
shape and then we will provide the
1:55
dimension and we will constrain it
2:04
here we will uh created a profile and
2:09
now here is a angle of 120° so first
2:13
thing we will provide the angle of
2:24
so if it is a 120 then
2:35
mm so for this uh we will create a
2:41
line and make this as a construction and
2:46
select the smart Dimension and
3:02
and this and this will be the
3:12
parallel and here we will delete this
3:23
relation and uh we will move this and
3:31
we will provide here angle
3:38
105 and uh we will uh select this and
3:46
parallel and this is the perpendicular
3:49
so this will be automatically
3:55
now we will give the dimension
4:02
here this is the 70 +
4:06
r25 so we will directly add the value
4:14
uh provide the thickness of uh 10
4:37
and this will be also 10
4:46
here this line will not be the
4:49
horizontal so we will delete this
4:51
relation and uh select this line and
4:55
this one and add the perpendicular
5:02
and we will delete this
5:05
constraint and we will delete this
5:15
Dimension we will press contrl
5:19
Z and we will select this line and
5:25
it and we will create a fresh line
5:32
and this line will be perpendicular to
5:36
this and we will select these two points
5:45
merge and select smart Dimension and
5:49
Define this uh line which is of 80 mm
6:01
and uh from this bottom line will be the
6:20
and our sketch is fully constraint so we
6:22
will come out of it so this is how our
6:26
base profile is and now
6:30
we will select the sketch click on
6:32
extrude and uh provide the 50 mm
6:38
and select on the mid blade click on
6:43
okay press uh control
6:46
7 and now here is a fillet of r25 so we
6:50
will select the fillet
6:52
tool and uh provide the value
6:56
r25 select this age and this AG click on
7:02
okay similarly at a bottom
7:10
fillet and here it is the same select
7:13
this age and this H and click on
7:19
okay and now we will create this
7:23
rib so as we have did our Extrusion
7:28
symmetric to this uh right plane so to
7:32
create the rib we will select the same
7:35
plane and uh we will make our part
7:38
normal towards the right directions and
7:52
triangle and now we will select smart
7:58
Dimension and provide it uh length of a
8:11
sketch and exit it and click on
8:16
extrude and uh this uh rip thickness is
8:22
mm and made it symmetric to the mid
8:26
plane and click on okay
8:43
9.9 so I think so 9.9 drill will not be
8:47
available in a whole wizard so we will
8:53
via sketch so select the phase and uh
8:57
click on the sketch and
9:00
we will uh create the four
9:19
now we'll select smart
9:24
so here we will project
9:31
Age first thing uh we will make it
9:36
normal and then we will project this uh
9:43
construction and now we will select this
9:45
point and this point and add the
9:50
relation similarly this point to this
9:53
point and uh add the horizontal relation
10:00
select this and this add a vertical
10:04
select uh this and this add a
10:09
vertical and select this and this and
10:15
horizontal now Center to Center distance
10:23
32 so we will constrain it and give it
10:30
C2 and uh we will uh select this point
10:34
and origin point and provide uh distance
10:41
16 and Center to Center is of
10:51
38 and here we will select one of the
10:54
whole and provide the size of uh 9.9 d
11:04
and we will select all this
11:08
uh four whole sketch and uh make it
11:15
equal and come out of
11:18
it select the sketch click on extrude
11:21
Cut and from here select uh up to
11:25
surface and say select this surface you
11:29
can also set through all no
11:36
now we will uh create a slot here so we
11:40
will select the face and click on the
11:42
sketch and we will uh make it
11:57
uh and make make it uh
12:08
uh Center to Center is of
12:19
25 and uh we will come out of the sketch
12:22
select the sketch click on extrude
12:26
Cut and from here select
12:29
surface and select the back side of a
12:35
surface now we will place our model to
12:38
the isometric View and here is a common
12:41
fillet of uh R3 which you can provide
12:46
fillet so I'm not providing the all the
12:51
fets you can uh provide it and here I
12:54
will give the value of R3
12:59
now press control 7 so you can see that
13:03
we have successfully modeled this angle
13:05
bracket in a solid works and this
13:08
tutorial is designed for the beginner
13:10
user of solid works those who have just
13:12
started learning the part modeling in
13:14
solid works and I hope you have enjoyed
13:17
this tutorial if you have enjoyed it
13:19
then please like subscribe and share my
13:21
channel and also support me on a
13:23
coffee.com you can buy me a cup of
13:26
coffee your small support will help this
13:28
channel to grow and it will motivate me
13:31
to create more awesome content on solid
13:33
works you can find the link in a video
13:37
description so this is all about angle
13:40
bracket tutorial in solid walks thank
