If the programmable logic controller PLC
0:06
is the brain of an industrial automation
0:08
system, the power supply is undoubtedly
0:10
its heart. Without a clean, reliable
0:12
flow of energy, the smartest control
0:14
systems in the world are just expensive
0:16
paper weights. In the complex ecosystem
0:18
of an industrial control cabinet,
0:20
managing power isn't just about turning
0:22
things on. It's about safety,
0:24
reliability, and longevity. Today we're
0:27
looking at a workhorse component
0:28
designed exactly for this environment,
0:30
the PSRS 24 to 60 power supply and
0:33
exploring why dedicated industrial power
0:36
and proper installation practices are
0:39
Detailed information contained in this
0:41
video can be found at acccca.ca.
0:44
A link has been put in the description
0:46
below. The website offers extensive
0:48
links, references, and coding samples,
0:50
making it a one-stop shop for all your
0:52
automation queries. accutomation.ca.
0:57
Why do industrial cabinets need
0:59
specialized power supplies? Walk up to
1:02
any industrial control panel. The power
1:04
coming into that cabinet is usually raw
1:06
high voltage AC, perhaps 120V, 240V, or
1:10
even 480V 3-phase. It's powerful, but
1:14
it's also noisy, fluctuating, and
1:16
inherently dangerous. Conversely, the
1:18
sensitive components inside the cabinet,
1:20
the PLC's, sensors, HMIs, and safety
1:23
relays operate in a different world.
1:25
They require stable, clean, low- voltage
1:28
DC power, almost universally 24VDC. In
1:30
modern automation, you cannot simply
1:32
plug a sensitive DC sensor into a 480V
1:35
AC line. You need a bridge that does
1:37
more than just convert AC to DC. You
1:40
need a device built to withstand the
1:42
heat, vibration, and electrical noise
1:43
typical of a factory floor, all while
1:46
providing unwavering voltage regulation.
1:48
The critical role of isolation beyond
1:50
just converting voltage. The most vital
1:53
function of an industrial power supply
1:55
like the PSRS 2460 is providing galvanic
1:58
isolation. Imagine a massive voltage
2:01
spike occurring on the incoming AC mains
2:03
line due to a nearby motor starting or a
2:05
lightning strike. Without isolation,
2:07
that spike could travel directly through
2:08
to the DC side, instantly destroying
2:11
sensitive and expensive control
2:12
components. Galvanic isolation
2:15
physically separates the input AC high
2:17
voltage circuit from the output DC low
2:19
voltage circuit using a transformer.
2:22
There is no direct metallic conductive
2:24
path between the high side and the low
2:26
side. Energy is transferred via magnetic
2:28
fields. Why this matters for your low
2:30
voltage circuits? Component protection.
2:33
It acts as a firewall. Faults on the
2:34
main side do not propagate to the DC
2:36
side. Ground loop prevention. It helps
2:39
prevent noise issues caused by
2:41
differences in ground potential across
2:42
the facility. Personnel safety seal. By
2:46
isolating the output from dangerous line
2:48
voltages, the 24V DC side becomes a
2:51
safety extra low voltage SEV circuit
2:55
which is significantly safer for
2:56
technicians to work around for
2:58
maintenance and troubleshooting.
3:00
Spotlight on the PSRS 2460. The PSRS
3:04
2460 is designed specifically to sit in
3:06
that critical gap between line power and
3:08
control power. As a 24VDC 60W supply, it
3:12
occupies a sweet spot for many
3:13
industrial applications. It provides
3:15
enough power to run a standard PLC CPU,
3:18
several input output cards, and a
3:19
handful of field sensors without being
3:21
overly bulky or expensive. Designed for
3:24
DNR rail mounting, it integrates
3:26
seamlessly into standard cabinet
3:27
layouts, providing the necessary
3:29
isolation and regulated DC power that
3:31
keeps processes running smoothly without
3:34
interruption. Installation corner. The
3:36
importance of fererals with stranded
3:38
wire. We can't talk about reliable power
3:41
without talking about reliable
3:42
connections. In industrial cabinets, we
3:45
almost exclusively use stranded wire
3:47
rather than solid core wire. Stranded
3:49
wire is flexible, making it easier to
3:50
route through tight wire ducts and able
3:52
to withstand the constant vibration of
3:54
machinery without work hardening and
3:56
snapping. However, stranded wire has a
3:59
weakness. Screw terminals. When you
4:01
insert bare stranded wire into a
4:03
terminal block or the input terminals of
4:05
the PSRS 2460 and tighten the screw,
4:09
several things go wrong. Spllaying. The
4:11
twisting action of the screw pushes the
4:13
strands apart. Broken strands. The sharp
4:16
edge of the screw cuts some of the fine
4:17
copper strands, reducing the current
4:19
carrying capacity. Loose connections,
4:22
hot spots. Over time, thermal cycling
4:24
causes the splade strands to settle,
4:26
leading to a loose connection, increased
4:28
resistance, heat buildup, and eventual
4:30
failure. The solution? Use a fereral. A
4:33
fereral is a thin tincoated copper tube
4:35
crimped over the end of stranded wire.
4:38
By using a feral, you consolidate the
4:40
strands into a solid gas-tight mass.
4:43
When you insert a fereral wire into the
4:45
PSRS 2460 terminal block, the screw
4:48
makes solid contact with the metal tube.
4:51
This ensures maximum surface area
4:52
contact, prevents oxidation between
4:54
strands, and guarantees a vibration
4:56
proof connection that won't loosen over
4:58
time. Using fererals isn't just extra
5:01
credit work. It's an industry best
5:02
practice that ensures the reliable power
5:05
delivered by your supply actually makes
5:07
it to the device that needs it. If you
5:09
are enjoying this video, please hit the
5:10
like button below. Keeping up with all
5:12
the latest automation innovations can be
5:14
difficult, so hit the subscribe button.
5:16
Remember to hit the bell beside your
5:18
subscription to receive the
5:23
Selecting the correct wire size is
5:25
crucial for safety and performance.
5:27
Using a wire that is too small for the
5:28
current load can lead to overheating,
5:30
voltage drops, and potential fire
5:32
hazards. Below is a general guide for
5:35
typical copper wire impacity used in
5:37
control panels. Note, this chart is for
5:39
general guidance only. Always consult
5:41
local electrical codes such as the NEC
5:44
in the US or CEC in Canada, wire
5:46
manufacturer specifications, and
5:48
consider factors like ambient
5:49
temperature, wire insulation type, and
5:52
number of conductors in a raceway when
5:53
making a final selection. Note, this
5:56
chart is for general guidance only.
5:58
Always consult local electrical codes
6:00
such as the NEC in the US or CEC in
6:03
Canada, wire manufacturer
6:04
specifications, and consider factors
6:06
like ambient temperature and insulation
6:08
type. A reliable control panel starts
6:10
with a stable foundation. By choosing a
6:12
rugged isolated power supply like the
6:14
PSRS 2460 and adhering to best
6:16
installation practices like using fuels
6:19
and selecting the correct wire size, you
6:20
ensure the long-term health and safety
6:22
of your automation investments.
