Universal Signal Conditioner and Isolator

Oct 13, 2022
Signal conditioners are used with analog current and voltage signals. They have the ability to change your input analog signal to another output analog signal. As an example, we can have a 4-20mA analog input and change it to a 0-10VDC output signal so we can wire this into our PLC. Typically signal conditioners will also electrically isolate the input and output signals. This is either done by magnetic or optical isolation. You would usually specify the input and output signals that are required in your circuit to choose the signal conditioner required. Using a universal signal conditioner will take a variety of signals and is a great product to use in troubleshooting analog circuits. We will be using a universal signal conditioner to convert a thermocouple temperature input into a 0-10VDC linear output. This will be wired into the analog card of the Click PLC. More information can be obtained on our website. This includes all of the links mentioned in this video. https://accautomation.ca/universal-signal-conditioner-and-isolator Additional discrete component connections to PLC include the following: Here’s a Quick Way to Wire NPN and PNP Devices https://accautomation.ca/heres-a-quick-way-to-wire-npn-and-pnp-devices/ - Wiring NPN Sensor to PLC Video https://youtu.be/Z09l3HKMpqs - Wiring PNP Sensor to PLC Video https://youtu.be/nP33k5e_Y-k - Wiring Contact Discrete PLC Inputs Video https://youtu.be/xh5dE2Z09d0 Wiring Interposing Relays https://accautomation.ca/wiring-interposing-relays/ - Wiring NPN and PNP sensors into the PLC with an Interposing Relay Video https://youtu.be/abh_Q7eKT34 Click PLC HMI Rotary Encoder Dial Input - Video
