Hello friends welcome to Solid Works
0:03
tutorial and uh in this tutorial we will
0:05
model this part and this is the tutorial
0:08
number four and you can see that I have
0:11
already modeled it and I will show you
0:13
from the scratch how you can model this
0:17
so I will close this file you can also
0:21
visit my website macn nexus.com and you
0:24
can visit this solid works tutorials tab
0:28
where I have a written so many tutorials
0:32
on solid works where you can follow the
0:34
step byst step guide to model the
0:38
parts if you like my method of teaching
0:41
then you can also support me on kofi.com
0:44
you can buy me a cup of coffee your
0:48
small support will help these channels
0:50
to grow and it will motivate me to
0:53
create more awesome content on solid
0:55
works so let's come back to our tutorial
1:01
here I have created a new file and
1:03
selected front plane and we will uh
1:12
rectangle and uh we will create a rough
1:19
profile click on the trim and trim
1:25
it and uh select horizontal Dimension
1:32
70 and vertical is of
1:56
6.4 now if we Zoom our
2:02
drawing we can check this Dimension
2:10
6.4 and here is a of 70 if we add this
2:15
radius here so I will uh provide this
2:18
drawing in a video description so you
2:21
uh view this drawing in a en llarge View
2:24
and follow the steps of my
2:27
modeling now our uh sketch is fully
2:31
constrained and uh we will look click on
2:34
extrude and extrude it to the distance
2:40
31.8 and from here select uh mid plane
2:46
okay and now we will give the fillet so
2:51
we will use the face fillet
2:54
options we will select this last one
2:57
select uh three three
3:03
faces select thir pH so solid works will
3:07
automatically calculate the fillet and
3:10
click on okay same way we will apply the
3:12
fillet here so click on the
3:16
fillet select first phas select second
3:20
phase and select the third phase click
3:27
okay now we will press uhr 7 for
3:31
isometric and select this pH and click
3:35
on the sketch and now make this uh
3:43
circle and uh create a circle and now we
3:48
will uh select this and this and uh made
3:52
equal click on okay and
3:56
uh select the sketch click on extrude
4:01
and provide the Extrusion difference uh
4:11
now we will uh create this rip so for
4:15
this uh we will select this front plane
4:23
sketch and uh click on
4:35
one click on convert entities now click
4:44
here we will uh select a three-point Arc
4:57
uh you the value of radius uh
5:04
2.5 now uh select a radius uh sorry line
5:17
tangent now select the smart
5:26
here Dimension is of a 25.4
5:38
this and select smart
5:51
Dimension not from here
5:58
bottom so so we will delete
6:04
Dimension and it will be a overridden
6:09
25.4 click on okay and
6:16
now we will uh provide the tangency
6:25
here now we will come out of the sketch
6:31
and uh we will uh create uh
6:36
extrude and this is the extrude of
6:49
6.4 select sketch click on
7:00
and from here click on mid
7:06
and unmerge this solid because if you
7:09
merge it it will not get merged because
7:12
of here is a gap so we will fill this
7:17
sketch and add the material so we will
7:20
select the phase and click on the sketch
7:23
and we will click on convert entities
7:26
and uh we will convert it and and we
7:29
will select this age click on convert
7:45
uh we will uh select it
7:51
and select it horizontal and now we will
8:15
extrud and from here select uh up to
8:22
surface so now it is merge and we will
8:30
select and click on the
8:46
now let's uh move to the next feature
8:50
first we will place our model to the
8:52
isometric and now here we will create a
8:56
cut so select the face and uh
9:26
19.1 and uh create a cut and set the in
9:31
all and from here say through all say
9:41
okay and now here uh it is a third angle
9:49
so we can see here rectangular cut which
9:54
will come on this phase so we will
9:56
select the phase and click on the sketch
9:59
and uh we will uh create
10:11
Dimension and give it a
10:16
22.2 and uh make this value symmetric
10:20
select this and this and at
10:25
equation uh press the equal symbol and
10:37
bottom and give it a
10:53
7.9 and uh come out of the
10:57
sketch and here we will uh create a cut
11:09
okay and now we will uh provide the
11:13
of8 mm to the all four corners so select
11:19
fillet and uh click on the normal
11:23
fillet and provide the here value
11:33
0.8 and select all the four
11:42
corners and uh click on
11:49
now we will uh select this phase and uh
11:54
hole so select the phase and uh click on
11:58
the sketch and and now make this phase
12:02
normal and uh select the circle and
12:07
circle and select smart
12:19
3.2 and uh vertical is of
12:28
10.3 3.2 and 10.3 and this is the whole
12:42
3.45 and now come out of the
12:46
sketch select the sketch click on
12:50
exclude and uh say it through all say
13:00
there are the two holes at a 45° angle
13:03
so first we will select this phase and
13:05
click on the AIS tool and insert
13:12
then we will uh select this plane and uh
13:18
axis and uh we will select this front
13:22
plane and here in angle we will give the
13:27
45 and select to hear the flip and click
13:35
okay and now select This Plane one and
13:40
again select this reference
13:51
uh selected this plan and now
14:02
plane or instead of a front plane we
14:05
will delete it we will select the axis
14:09
so first reference will be plane and
14:11
second reference will be the axis and uh
14:16
this is the perpendicular so it
14:21
will create a plane in fact this
14:24
plane is a must because we will create
14:29
so we will uh select this plane and uh
14:34
sketch and we will uh create a
14:38
circle and we will select the center and
14:42
uh this axis and uh add the coincidence
14:47
and now select the smart Dimension and
14:50
select this bottom Edge and
14:53
uh provide the dimension of uh 7 uh 8
15:22
3.45 and uh click on the sketch select
15:27
the sketch click on extrude cut
15:35
arrow and click on okay now we will
15:39
select this to plane and axis and uh
15:41
hide it now select this extrude cut and
15:45
from here go to the mirror and from the
15:51
top select the mirror and click on okay
16:01
and now here is a one boss so we will
16:04
select the phase and click on the
16:07
sketch we will make this phase normal
16:12
circle and create a circle select
16:16
diameter and give the value of 19.1
16:31
and we will give the Extrusion of
16:44
okay so this is how we have uh completed
16:48
this model and I hope you have enjoyed
16:50
this tutorial if you have enjoyed it
16:52
then please like subscribe and share my
16:54
channel and also support me on
16:56
coffee.com you can buy me a cup of
16:58
coffee your small support will help
17:01
these channels to grow and it will
17:03
motivate me to create more awesome
17:05
content on solid works link is given in
17:08
a video descriptions thank you for
