0:00
Hello friends welcome to Solid Works
0:01
tutorial and in this tutorial we will
0:04
model this uh gear cover in solid works
0:07
as you can see that I have already
0:09
modeled it and this is the gear cover
0:13
with three mounting screws and we will
0:16
model it from the scratch so I will
0:19
close this file and create a new
0:22
file you can also visit my website macn
0:25
nexus.com and you can visit this solid
0:29
work tutorials tab where I have written
0:33
so many tutorials on solid works where
0:38
stepbystep guide to model the
0:41
parts if you like my method of teaching
0:44
then you can also support me on kofi.com
0:47
you can buy me a cup of coffee your
0:51
small support will help these channels
0:53
to grow and it will motivate me to
0:56
create more awesome content on solid
0:58
works so so let's come back to our
1:02
tutorial so here I have created a new
1:05
file now if you look at our drawing we
1:08
will create our base feature on a right
1:12
plane and we will extrude to the
1:14
distance of uh 165 approximate
1:22
so we will first select the right plane
1:25
and uh create a rough profile
1:41
now we will give the dimension select
1:43
smart Dimension and give it
2:05
and angle we will give the
2:11
45 so this is the base profile which we
2:14
have created now we will come out of the
2:25
extrude and uh give it distance 130
2:30
and from here select mid plane click on
2:34
okay and now we will uh create a
2:39
fillet select the fillet and uh give the
2:46
65 and select these two
2:58
edges and now we will create a fillet of
3:26
now we will uh create the shell
3:34
we will select this pH and click on the
3:43
here we will find out the thickness of
4:00
so you can see that uh shell has been
4:03
created but we do not M material here so
4:08
phas and click on the sketch and click
4:14
entities and we will select the profile
4:18
Cut and from here we will say it through
4:25
okay so you can see that inside Hollow
4:35
now we will uh place our model to the
4:39
View and now we will uh create this uh
4:45
rib or we can say that a leg so for this
4:50
we will select the face and uh select
4:55
the plane and give the
5:03
now we will uh select this dat temp
5:07
plane and uh create a
5:11
sketch we will move to the top
5:18
hide the DAT temp plane and now we will
5:28
rectangle and here here we will delete
5:31
this line and create a three-point
5:48
Dimension and this is a 30
5:56
mm and from Outer it is 65
6:18
uh we will select this point and this uh
6:22
origin point and add the horizontal
6:31
or we will select this origin
6:51
this and uh this is the 70
6:57
mm select smart dimension
7:12
so if we see the center of this
7:17
hole and we will read the
7:20
dimension if you see here it is a
7:45
center it is 70 so it is clearly
7:48
mentioned here so what we will do we
7:55
Dimension and here it is a 70 mm so this
8:02
this fillet this age so from
8:16
mm because here is a center and it is
8:19
the ending of this Arc so click on
8:23
okay now we will come out of the sketch
8:30
select the sketch click on
8:35
it and select uh up to
8:47
now we will create this cut so for this
8:51
we will select this phase and click on
8:54
sketch and we will make this uh phase
9:16
now make this diameter
9:25
uh give this value 60
9:33
and will select the origin and this
9:36
sketch and add a vertical
9:40
relation come out of the sketch select
9:47
extrude and from here select up to
9:50
surface and select the inside surface
9:57
now we will create this to leg so for
10:01
this I will select the phase and click
10:10
uh we will select these two edges and uh
10:13
click on the convert
10:15
entities and uh we will make this phase
10:25
create the rough profile
10:29
and I will delete this line and select a
10:45
Arc and uh width of this is uh
10:55
26 26 and uh from the h
11:11
or it is the from the center not from
11:25
this from this radius to the center
11:35
mm and from origin to this Center is of
11:46
82.5 and we will come out of the
11:53
and we will create a extrude of 10
11:57
mm select the reverse
12:06
okay now we will mirror this leg on the
12:09
other sides so we will uh go here and
12:16
and select the right
12:23
okay so we have successfully created
12:28
leg now we will create the three
12:35
10.5 so first select this
12:38
face and uh it is a plain hole so I will
12:43
sketch go to the sketch and select the
12:56
Dimension give it uh 10.5
13:08
sketch select extrud
13:11
cut and from here select uh up to
13:15
surface and select this bottom pH click
13:22
now we will create a hole here select
13:26
the phase and click on the sketch
13:29
and here snip to the radius and create a
13:36
and give it a diameter of
13:46
10.5 come out of the
13:49
sketch select sketch click on the
13:56
cut and from the bottom
14:02
all and now we will mirror this hole on
14:06
the other side so go to the
14:22
okay now press crl 7 so here we have
14:27
successfully modeled this the gear cover
14:30
in Solid box from scratch I hope you
14:33
have enjoyed this tutorial if you have
14:34
enjoyed this tutorial then please like
14:36
subscribe and share my channel and also
14:38
support me on coffee.com you can buy me
14:41
a cup of coffee your small support will
14:44
help this channels to grow and it will
14:46
motivate me to create more awesome
14:48
content on solid works link is given in
14:51
the video description thank you for
14:53
watching and thank you for your valuable
