Hello friends Welcome To freet tutorial
0:03
and in this tutorial we will model this
0:05
uh helical compression spring in freead
0:09
as you can see that I have already
0:11
modeled it and I will show you from the
0:14
scratch how you can do the same in
0:17
freead you can also visit my website
0:20
Mech nexus.com where I write articles
0:23
and tutorials on free care you can also
0:26
download my tutorial Source F from the
0:28
here you can also support my work by
0:32
buying my free cat crash course for
0:34
beginner it is a very basic level course
0:37
for the beginner user where a beginner
0:40
user can Master the free
0:43
Cad and you can also support my work on
0:46
coffee.com you can buy me a cup of
0:49
coffee you will get my website link and
0:52
my Kofi donation page Link in a video
0:58
description for this tutorial we are
1:00
going to use part as well as part design
1:04
workbench so let's start our tutorial I
1:10
file and I will create a new
1:13
file and I will switch to the part
1:18
workbench sorry part workbench and on
1:21
part workbench here you will get a
1:27
creative create Primitives
1:33
click on it and uh here
1:38
Helix and here we will enter the data
1:42
and we will create our
1:45
Helix pit we will give uh 50
1:49
mm height I will give
1:53
500 radius I will give
1:57
150 and I will create one helic
2:00
so you can see that Helix has been
2:04
created now we will create our spring
2:12
Helix so this uh Helix is made with a
2:16
part workbench and now we will use part
2:19
design workbench so that is the beauty
2:22
of a freeat that you can use multiple
2:26
workbenches with a part now I will
2:30
switch to the part design
2:33
workbench and here on a part design
2:35
workbench I will create a body and uh I
2:41
plane here I will select This
2:51
exit and I will create a sketch on this
2:55
plane I will off my origin plane as
3:05
150 so I will create a
3:09
circle I will give my diameter of a
3:28
mm 10 will be very small so I will give
3:32
25 and I will select this point and this
3:36
point and I will make it
3:39
horizontal now I will give the
3:45
dimension our radius is 150 so I will
3:49
150 so this uh diameter I will again
3:55
30 and I will close the
3:58
sketch now we have a path of our spring
4:06
diameter that is the also known as a
4:12
diameter now we will uh click on this
4:16
uh tool for creating the
4:34
and you can see that uh it has been
4:37
created but we will give our actual
4:41
value so while designing the Helix we
4:44
have given the pitch 50
4:56
okay so you can see that uh we have
5:00
created our compression
5:03
spring and best part is that we have
5:06
made this Helix in a part workbench and
5:10
uh this additive Helix in a part design
5:13
workbench so here we have also learned
5:16
how we can use multiple workbenches to
5:20
part we can easily modify this
5:23
diameter pit as per our requirement so
5:27
this is how to model comp operation
5:30
spring in free CAD so this is all about
5:33
this tutorial thank you for watching and
5:35
thank you for your valuable time
