0:00
Hello friends welcome to Solid Works
0:01
tutorial and in this tutorial we will
0:04
model this idler pulley in solid works
0:07
as you can see that uh I have already
0:09
modeled it and I will show you from the
0:11
scratch how you can do the
0:14
same I will also show you the section
0:21
it with respect to the drawing and uh
0:24
you can see that uh internal sections of
0:27
this idler p is matching with the our
0:30
drawing and I will show you from the
0:32
scratch how you can do the same in solid
0:34
works so I will close this file and
0:38
file you can also visit my website macn
0:42
nexus.com and you can visit this solid
0:46
works tutorials tab where I have written
0:49
so many tutorials on solid works where
0:53
you can follow the step by step guide to
0:58
parts if you like my me me of teaching
1:00
then you can also support me on kofi.com
1:03
you can buy me a cup of coffee your
1:07
small support will help these channels
1:10
to grow and it will motivate me to
1:12
create more awesome content on solid
1:15
works so let's come back to our
1:20
tutorial so here I have created a new
1:23
file and uh I will select the right
1:28
plane and uh click click on the
1:31
sketch and uh then we will create our
1:36
profile so first I will
1:43
a horizontal line and I will make it a
1:48
construction and I will give it a
2:00
I will uh draw the approximate profile
2:05
and then we will constrain with the
2:10
first I will uh start from here
2:50
and we will delete this
3:18
join so now you can see that we have
3:22
created approximate profile with respect
3:25
to our the section View and
3:33
first we will start constraining the
3:37
diameter so first select smart Dimension
3:39
and select the outermost
3:41
boundary and move these Dimensions below
3:45
the construction line so it will be
3:52
143 and this one is a eight
4:03
and first thing which we will do is to
4:07
add the vertical relation
4:16
Dimension this to this is a
4:27
uh chamfer line is of 3 mm which you can
4:43
here will in fact delete this line
4:45
because here is a straight and then is
4:48
45° so for timing we will delete it we
4:53
will create a straight line and then
5:11
Dimension this is the diameter of
5:17
40 and then it is of 3
5:25
mm and this angle is a 45
5:39
now we will constrain this
5:43
one this Dimension is little bit not
5:46
clear so we will give it the approximate
6:04
or we can also give this as a
6:08
diameter so we will select smart
6:17
Dimension so we have considered this
6:19
thickness 5 mm now we will constrain
6:23
this this is of uh 12 mm
6:32
uh this outer diameter is of
7:09
73 and this one is of
7:13
20 so which is already 20 now this
7:27
now we will uh move our diamond
7:31
iions so that you can clearly see
7:37
it this is the 45 this is the
7:48
and this is a 105 this is
7:54
now you can see the all the dimensions
7:57
here so our scale is fully constrained
8:05
revolve tool to revolve it into the 360
8:08
so we will click on revolve boss or base
8:11
and it automatically selected the center
8:17
okay and now here we will uh give the
8:31
and this age and click on the
8:35
fet and give the here value
8:38
R6 click on okay so you can see that we
8:42
have successfully made this
8:46
uh Ider pulley and uh some common fillet
8:51
here is a mention which we can uh do it
8:55
so just select this age
9:07
sections if you go to the sections and
9:10
select this right one and click on okay
9:13
so you can see that in section view it
9:15
is perfectly matching with our idler
9:17
pulley and uh here uh our model is get
9:22
completed and this tutorial is for the
9:24
beginner user those who have just
9:26
started learning the solid works and and
9:29
uh this tutorial is basically to get
9:32
familiar with the revolve tool of a
9:35
solid works to create a circular parts
9:38
so this is all about this tutorial I
9:40
hope you have enjoyed this tutorial if
9:42
you have enjoyed the then please like
9:44
subscribe and share my channel and also
9:46
support me on a coffee.com you can buy
9:49
me a cup of coffee your small support
9:52
will help this channels to grow and it
9:54
will motivate me to create more awesome
9:56
content on solid works thank you for
9:58
watching and thank thank you for your
