0:00
Hello friends welcome to Solid Works
0:02
tutorial and in this tutorial we will
0:04
model the anchor bracket in solid works
0:07
as you can see that uh I have already
0:09
modeled it and I will show you from the
0:12
scratch how you can do the same in solid
0:14
works so I will close this file and
0:19
file you can also visit my website macn
0:22
nexus.com and you can visit this solid
0:26
works tutorials tab where I have a
0:29
written so many tutorials on solid works
0:33
where you can follow the stepbystep
0:38
parts if you like my method of teaching
0:41
then you can also support me on kofi.com
0:44
you can buy me a cup of coffee your
0:48
small support will help these channels
0:50
to grow and it will motivate me to
0:53
create more awesome content on solid
0:55
works so let's come back to our tutorial
1:00
so here I have created a new file and
1:03
the first thing which I will do is to
1:06
create this base profile and for this I
1:10
will select the right
1:26
sketch a very rough profile
1:35
similar to our uh drawing and now I will
1:40
select this and this and say it
1:47
parallel this Dimension
2:22
12 this angle is of 60°
2:45
53 so this is the base profile which we
2:49
have created and now we will come out of
2:55
Extrusion so we will click on extrude
2:58
and we will extrude to the distance of
3:02
40 and uh selected mid plane click on
3:12
now we will uh remove the material at
3:16
this side so for this we will select the
3:19
phase and click on the
3:21
sketch we will uh create a
3:25
circle we will select this and this and
3:35
Dimension and provide the dimension of
3:42
mm and this diameter is of a
3:51
construction selected make it
3:56
now select uh a line and create a line
4:03
here and then make this line tangent to
4:10
circle now click on the
4:12
trim and now we will close this profile
4:16
so select your Treepoint
4:20
Arc select the line tool
4:37
now our sketch is fully constrained we
4:41
will come out of it select the sketch
4:46
Cut and from here drop down select up to
4:50
surface and select this surface and
4:53
click on okay now we will mirror this
4:56
cut on the other s side we will select
4:58
the mirror and from here we will select
5:09
okay now here is a fillet of R six so I
5:16
edges and click on the
5:19
fillet and provide the r
5:27
six now we will create a slotted cut
5:32
here select phase and click on
5:44
now create a rectangle and we will
5:50
line we will select this line and ede
6:00
make this normal select the three-point
6:07
Arc now from the bottom it is 35 so
6:19
35 and uh width is of 10 mm
6:31
and from Center it will be 5
6:37
mm now we will come out of the
6:41
sketch click on extrude
6:45
Cut and from here select up to
6:48
subface and select this pH click on
6:55
okay now we will create this
6:58
boss see select the phase and click on
7:02
sketch now select the circle
7:10
tool and create a pad of a 3
7:25
okay now we will create this hole of Dia
7:29
13 .5 select the face click on the
7:39
and create a circle of
7:54
13.5 now select the sketch click next
8:11
okay now we will add the material at
8:15
this portion so for this we will select
8:18
this phase and click on the
8:20
sketch and uh we will
8:28
select the this and click on convert
8:31
entities now make this
8:38
now I will uh create a three-point
8:50
merge select the line tool
9:00
select this and this and create a
9:14
tool make this vertical select
9:19
this and this and add the
9:49
constraint and give this radius
10:09
point and this H click on coincident
10:19
profile select the line
10:26
tool close the profile
10:31
now create the extrude of a 3
10:42
now we will mirror it on the other side
10:46
this we will uh go to the plane select
10:50
this phas outer phas and
10:55
interface click on okay now select these
10:58
features and click on the
11:01
mirror and from the drop down select
11:06
plane which we have created now we will
11:14
plane now we will uh create these two
11:19
holes on this surface so we will select
11:21
the face it is a Plaine drill hole so I
11:24
will use the sketch tool now I will make
11:42
circles select this origin point and
11:45
Center points and add the
11:49
horizontal add a vertical relation
11:55
this vertical relation
12:01
Center to Center distance between the
12:14
and if you see here from the outer edge
12:26
40 and diameter is of
12:37
11.5 select this two and uh make it
12:45
now we will click on exclude and uh
12:49
remove the material and say true
12:56
okay now press control 7
13:01
and here is a common fillet note is R3
13:04
so we can provide the fillet at a
13:06
required ages of R3 which I'm not going
13:08
to do and uh you can see that uh we have
13:13
successfully made the model of this
13:14
anchor bracket in solid works I hope you
13:17
have enjoyed this tutorial if you have
13:19
enjoyed it then please like subscribe
13:21
and share my channel and also support me
13:23
on coffee.com you can buy me a cup of
13:26
coffee your small support will help this
13:28
channel to go thank you for watching and
13:31
thank you for your valuable time
