Learn how to use the SCL (Scaling) function in Omron PLC to convert raw analog input signals (like 4-20mA or 0-10V) into real engineering values. This tutorial explains step-by-step scaling in CX-Programmer with practical examples.
JOIN OMRON FULL COURSE HERE:
https://learn.automationcommunity.com/courses/omron-plc-training-course-using-cx-programmer/
#scaling #scl #plc
Tags:
omron plc,omron scl instruction,omron analog scaling,omron plc analog input,omron plc analog signal scaling,scl function in omron plc,scaling 4-20ma signal,scaling 0-10v signal,omron cx-programmer tutorial,omron plc programming,analog input to engineering value,plc analog input scaling,scl instruction cx programmer,omron plc analog example,omron plc training,industrial automation,plc analog sensor,omron scl example,plc input scaling
Show More Show Less View Video Transcript
0:13
[Music]
0:16
hello everyone welcome to automation
0:19
community In this session we are going
0:21
to see about one of the most important
0:24
and you know useful instruction in
0:27
homegrown PLC which is called as
0:30
SC scaling function So this is one of
0:34
the most important instruction in PLC
0:37
programming Why because whenever we are
0:40
going to deal with some analog values we
0:43
have to do this scaling function Correct
0:47
for example let's take you have a water
0:50
tank over there in your industry So you
0:53
are having the level transmitter there
0:55
So what will be the output of the level
0:57
transmitter it will be in terms of uh
0:59
you know 4 to 20 milliamps Level
1:02
transmitter is giving the output as 4 to
1:04
20 milliamps But you want to uh you know
1:08
calculate that in the percentage like
1:10
how much percentage uh my water is
1:13
filled in the water tank Okay you are
1:15
you know calculating that as a 0 to 100
1:18
in terms of 0 to 100 percentage right so
1:23
now you want to write a program so that
1:26
the level transmitter output 4 to 20
1:28
milliamps can be readed in the form of
1:31
percentage Can you understand the
1:33
concept so this is called a scaling You
1:35
can able to
1:37
scale any input to the required
1:41
output All right So let's see that in
1:44
the program So this is how ACL will be
1:49
instruction will be like ACL in the
1:51
overall and the first one is having the
1:53
source word So which is the data you
1:56
want to transfer like your level
1:58
transmitters input is the source word
2:00
here Okay And what is your result word
2:04
result word will be your percentage
2:06
output Okay So you are going to read 4
2:09
to 20 milliamps any any any value in
2:12
between 4 to 30 milliamps and your
2:14
output is any value between 0 to 100 All
2:16
right So now what is this P1 so this P1
2:20
is going to uh you know play the vital
2:23
role So what it is going to do means you
2:26
have to tell the scaling function that
2:29
you're going to convert 4 to 20
2:30
milliamps to 0 to
2:34
100% or for example 0 to 10 volt to 4 to
2:38
20 m or 0 to 10 volt to some degree uh
2:41
you know 30° to 500° like that you can
2:44
fix any range according to your
2:46
application So you have to tell the Sccl
2:49
that this is my input range input
2:52
minimum and maximum range and this is my
2:54
output input and maximum range like that
2:57
you have to tell the SCL so that it will
2:59
calculate the you know output and it
3:02
will it will give the output according
3:04
to your application All right I hope you
3:07
have understand the basic concept of CI
3:11
So look at this This is your input
3:15
source Okay Imagine this is your 4 to 20
3:18
milliamps This is your unsigned BCD
3:21
output This is our okay result So this
3:25
is
3:27
your 0 to 100
3:31
percentage So now this as S is the
3:35
minimum range in your input So what is
3:37
the minimum range of our input which is
3:39
four Correct minimum value not range
3:41
sorry it's a value So four BS
3:45
is your 20 milliamps Correct And how
3:49
about this A R which is your zero BR is
3:53
100 Look at this So P is having some
3:57
address Let's take D
3:59
100 Okay So B
4:02
100 is having a R A R is nothing but the
4:07
lower minimum value of your output Okay
4:11
Which is zero What is a as minimum value
4:14
of your input which is what
4:17
four Are you following it's easy to
4:20
understand now So a R is the minimum
4:24
value of your output AS is the minimum
4:27
value of your input BR is maximum of
4:30
output Maximum of output And BS is
4:33
minimum of your input Sorry maximum of
4:37
your input Okay So by using this SCL
4:43
will be knowing that okay this is the
4:45
range and this is the input I have to
4:48
convert like that so that can understand
4:50
the concept and it will give you
4:53
the okay so I'll explain you in the
4:57
program so that you can understand in a
4:59
very better
5:00
way This is my running
5:04
condition and let's take AC L What is my
5:08
source address let's take D00
5:14
uh
5:17
input
5:19
data
5:20
Okay And we have to
5:23
give this parameter address now So this
5:26
is D200
5:29
And the next fellow code is
5:46
D parameter minimum maximum This is
5:50
output
5:52
in
5:55
percentage Okay
6:02
It's
6:07
correct All right So go for the
6:20
simulation Let's take a watch table
6:26
I'm going to give D
6:28
100 D
6:32
200 D 2 not 1 2 3 and this is going to
6:38
be my 300 Okay So why I'm taking all
6:42
these because I have to give the minimum
6:44
and maximum H correct
6:56
Now what is this value this is
7:00
my outputs minimum
7:04
Correct this is my outputs minimum First
7:07
value is the output minimum This is
7:10
output
7:14
maximum Output minimum
7:18
[Music]
7:22
beginning
7:24
board Okay
7:37
So
7:54
then okay I'm giving this
7:59
as zero Okay And this fellow is going to
8:04
be your 100 Correct 100
8:07
This is going to be your
8:09
four This is going to be your 20
8:13
milliamps All right So you have given
8:15
the value So this is your parameters
8:20
first address So that is going to be
8:22
your outputs minimum This is output
8:24
maximum This is input minimum This is
8:27
input maximum Why I'm telling you this
8:31
we can see
8:33
this conversion 4 to 20 milliamps to 0
8:37
to
8:38
100% So if it is input is if your level
8:42
transmitter is giving 4 milliamps that
8:44
means what there is no water inside that
8:46
is a 0% water If your level transmitter
8:49
is giving 20 milliamps then we get to
8:52
know there is a 100% loaded and in
8:54
between 50%age half water tank is per
8:59
mills Okay So we'll apply this input
9:03
condition and we'll check whether we are
9:05
getting the
9:10
output I'm going to
9:13
give four here 4 milliamps is given by
9:17
my level
9:19
transmitter Output have to be
9:23
what it have to be zero Right so we are
9:27
getting
9:28
zero Okay
9:31
Now we'll give 12 which is 50%
9:42
So we are
9:46
getting 32
9:51
over okay let's give 20% let's see
9:55
whether it is giving it's giving
10:01
64 so the answer is in BCD that one also
10:05
we have to see the answer is in BCD
10:21
So this is
10:23
0 100 4
10:28
20
10:31
less So if I give 20 millia I should get
10:35
100 Okay I'm giving I'm getting 64
10:40
64 is in
10:55
BCD is 100 Yes See here look at this 064
11:01
is nothing but the 100 So it's giving
11:03
the correct value
11:14
Okay
11:17
So try to change the data type of this
11:19
so that you can
11:33
understand Okay Can you see here
11:37
100 I'll give
11:39
12 So it should give 52 Can you see it's
11:43
giving
11:44
50 That's a problem with run on because
11:47
we cannot able to see the expected uh
11:50
way If you want you can make use of such
11:54
options in the home run software Okay
11:56
It's showing in the BCD You have to
11:59
understand
12:00
that we are we are expecting the answer
12:03
in the decimal See 12 you know 0 to 100
12:05
is nothing but the decimal value right
12:08
here it is showing the BCD you have to
12:09
understand okay 32 BCD is nothing but 50
12:12
in the decimal that's what you can
12:14
convert
12:15
here you can convert all so that you can
12:19
see everything in the
12:29
integer
12:36
Okay this is how scaling will be
12:41
working and this is like in the
12:44
practical way we have taken the example
12:46
like 4 to 20 milliamps to you know
12:49
percentage
12:50
So you can make use of any
12:53
application There are so many
12:55
conversions people will be calculating
12:58
uh the same 4 to 20 milliamps to some
13:01
you know uh to the voltage 0 to 5 volt
13:04
or 0 to 20
13:05
volt or in temperature range like that
13:08
they will be calculated correct look at
13:11
this 0 to 100 4 to 20 milliamps the
13:15
answer is 50 Okay What if if you're
13:18
giving
13:19
16 16 is nothing but nearly it will be
13:23
75% so it is giving
13:26
72
13:27
okay you give
13:31
18 8 milliamps answer is
13:36
22 okay so for this it should be
13:39
actually 25 this is giving 22 no this
13:42
should be some offset value you have to
13:43
add offset according to
13:45
the
13:47
answer Okay So this is the offset we
13:50
usually call it as you can add the
13:55
three it should be the 25 So you can add
13:59
or subtract the offset according to
14:04
the
14:05
okay So if again you give over to giving
14:11
zero the exact percentage are coming So
14:14
12 is giving
14:18
50 and 20 is giving
14:21
100 All
14:23
right So let's see what 19 is giving 19
14:26
is giving 96 is the most
14:29
close Okay So this is called as a
14:32
scaling application in industry So
14:36
scaling is most important instruction
14:42
So you can apply this to
14:44
any scaling function anything like 4 to
14:48
20 millia as I have told you I have
14:50
taken the level transmitter you can uh
14:53
you know take the temperature
14:54
transmitter or pressure transmitter that
14:58
to convert to the you know some other
15:01
value So this conversion is mostly used
15:03
for processing it is used to uh help in
15:06
processing the
15:07
data Okay So this is scaling function
15:12
and one more application over here that
15:14
is the reverse
15:15
scaling We'll see that
15:18
also What is reverse
15:20
scaling so reverse scaling is your B r
15:26
is less than a
15:28
R So what does that mean
15:32
your sometimes what will happen no let's
15:35
take the same example 4 to 20 milliamps
15:37
is converting to 0 to 100 uh percentage
15:40
Sometimes the requirement will be like
15:43
zero have to be I mean four have to be
15:46
matched to
15:47
100 20 have to be matched to zero In
15:50
that case what you will do you have to
15:51
reverse the range What is this
15:54
application
15:56
means let's take uh you know flow flow
15:59
of some liquid or something is there
16:02
Okay according to your level transmitter
16:04
value You are going to close the val or
16:07
open the
16:08
valve Okay So there are two types of val
16:11
that is normally closed val or normally
16:13
open val So for this you are going to
16:16
give the instruction whether that may be
16:18
the 100%age or zero percentage So you
16:21
can fix whether four is matching with
16:24
the 0 percentage or four is matching
16:26
with
16:27
100% 20 is matching with 100 or 20 is
16:30
matching with 0 percentage
16:32
Okay So suppose in the previous scaling
16:36
function what we have done 4 is equal to
16:38
0 and 20 is equal to 100 In your some
16:42
other application you want four have to
16:43
be equal to 100 In that case what you
16:46
will do you can do the reverse scaling
16:49
Okay So it's simple You can see the
16:52
difference Here a R is down BR is up Now
16:58
so here also A R is BR is down AR is up
17:02
That means what the lower range have to
17:05
be up Lesser range have to be
17:07
down So what you can do in the
17:12
instruction
17:13
[Music]
17:15
is you can interchange the 100 and zero
17:18
That's it Nothing
17:21
big How the output you want like that
17:23
you can put So here I'm giving
17:27
100 Here I'm giving zero This is reverse
17:30
scaling nothing big Okay I'm doing
17:36
force Now see you are giving 20
17:39
milliamps but your output is zero 0% 0
17:45
percentage here 0% you give 4
17:49
milliamps your answer is output is 100
17:52
100%age open valve is 100% open Now for
17:57
empty empty tank what is 4 milliamps
18:01
there is empty tank so you have to open
18:02
the work you know fully so you are
18:05
giving
18:07
100%age correct so like this you can
18:10
make use of scaling and reverse scaling
18:11
in your application I hope you have
18:14
understood this concept I'll meet you in
18:16
a session with another interesting topic
18:18
thank
18:21
[Music]
18:28
[Music]
