Motion Control Drives with RS485 Communication

0:00
Yes, this is our four axis uh RS485
0:03
based intelligent drive. Uh this is this
0:07
drive can handle four different motors.
0:09
So you can see access 1 2 3 4 and this
0:13
has a RS485 port by which we we are
0:16
communicating through an HMI. uh we can
0:19
change uh uh whatever speed like for
0:23
example this you can see uh I am
0:26
changing the speed of the access one or
0:29
the communication
0:33
okay the speed changes uh you can change
0:37
the index [snorts] so if you want to see
0:40
uh we can change uh and the speed of the
0:44
indexing and also we you can see it the
0:48
speed changes is
0:50
you make this row slow. The PLC resides
0:53
inside. This is uh programming uh is
0:56
done using our free software. Uh we call
0:59
it as a Q programming. So in the Q
1:02
programming um you can write the whole
1:04
logic. Uh and this has uh two inputs and
1:07
one output for each axis. So it can be
1:10
used independently in the program. We
1:13
have timer, we have counters, we have
1:15
mathematical calculations inside uh the
1:18
drive and this is not only limited to
1:21
this drive in all our products whether
1:23
it's a stepper, it's a step servo or a
1:25
servo, you have this intelligence
1:28
inbuilt and if you see this particular
1:31
drive there is a C type charging port.
1:33
So you don't need a special cable. So
1:36
this cable is readily available with
1:38
each and everyone. Now uh you can use
1:40
your mobile cables also to program and
1:44
also the beauty is this particular uh uh
1:47
HMI
1:49
also has that C C port uh below uh by
1:52
which uh you know you don't need an SMPS
1:55
to program it. You can use your 5V power
2:00
to do the programming and you can
2:02
directly connect to the laptop using the
2:04
USB port. to buy these products uh you
2:07
can visit our website and get our
2:09
contact details. Thank you.
