Learn how to use Memory Bits in CODESYS PLC programming with a practical buzzer control example. Memory Bits are internal PLC variables used to store logic states and control operations without requiring physical inputs or outputs. This tutorial explains how Memory Bits work and how they can be used in ladder logic to control a buzzer.
** Video Topics **
0:00 Memory Bits
1:21 Open CODESYS
2:30 Memory Bit Latching
3:11 using Memory Bit in another network
4:14 Memory Bits for Set Program
5:15 Another Memory Bit for Reset
6:52 Memory Bits Logic Tested
✨ FOLLOW US ✨
👉WhatsApp: https://whatsapp.com/channel/0029VaAbUecLNSa4rDPOV31o
👉Telegram: https://t.me/+u3qORX5FKec1NjA1
👉LinkedIn: https://www.linkedin.com/company/instrumentationtools/
👉Facebook: https://www.facebook.com/instrumentationtoolss/
👉Instagram: https://www.instagram.com/instrumentationtools/
👉YouTube: https://youtube.com/instrumentationtools?sub_confirmation=1
👉JOIN Courses: https://automationcommunity.com/
Show More Show Less View Video Transcript
0:00
[Music]
0:06
Hello everyone, welcome to automation
0:09
community. Today in this video we are
0:12
going to discuss an example in which we
0:15
will be controlling two burgers using
0:18
two switches.
0:20
So let's look at the example first.
0:23
Example 10. If toggle switch one is on
0:27
then buzzer one and buzzer two will be
0:29
on. If toggle switch one is off then
0:32
buzzer one and buzzer two will be still
0:35
on. If toggle switch two is on then
0:38
buzzer one and buzzer two will be off.
0:41
That means when we turn on the toggle
0:43
switch one both the buzzers buzzer one
0:47
and buzzer two turn on. And when we will
0:50
turn off the toggle switch one both the
0:52
buzzers remain on. And to turn off the
0:56
buzzers, we will uh turn on toggle
0:59
switch two. So to keep the buzzers on
1:03
even when the toggle switch is turned
1:05
off, we will implement latching. And
1:08
with that we will be using some memory
1:11
bits, normally open contacts and
1:13
normally close contacts. So let's move
1:16
to codices where we will draw a ladder
1:19
diagram for this example.
1:21
So I will open cortices.
1:36
So firstly we need to create a new
1:38
project. Click on new project.
1:42
Write the name of the uh of the this
1:44
project. Keep it as example
1:48
10. And we can also select the location
1:52
where this file will be saved. And then
1:55
we can also select the template as
1:57
standard project and click on okay.
2:03
After that you can select your device
2:05
from this drop-own list and also we can
2:08
select the PLC programming for now we
2:11
will be using LA logic diagram and then
2:14
click on okay.
2:19
We need to click here
2:22
on PLC programming.
2:25
So double click here and here we will
2:27
draw the ladder diagram.
2:30
So first of all we will insert an a
2:33
contact a normally open contact for
2:36
toggle switch one. So this will be
2:38
toggle switch one.
2:42
Okay. And then we will insert a coil for
2:46
a memory bit. So it will be
2:49
memory bit.
2:52
Okay. And we will latch this memory bit
2:57
here. So we will insert a normally open
3:00
contact
3:02
in parallel with this toggle search one.
3:04
So this will be again memory bit.
3:12
And after that we will use this memory
3:14
bit in the next network. So we will
3:16
insert right click here and insert
3:19
network below. Click here.
3:22
So one more network will be inserted
3:24
here below this network and here we will
3:27
insert a contact and this contact will
3:32
be for the upper memory bit. So we will
3:34
write memory bit
3:38
and this memory bit will be used to turn
3:41
on the two buzzers. So for that we will
3:44
insert a coil and this coil the first
3:47
coil will be buzzer one. Okay.
3:53
And after that we need to add one more
3:56
buzzer. For that we will insert one more
3:59
coil here. But before that we need to
4:02
insert branch so that we can insert one
4:04
more coil. So we will insert one more
4:06
coil here and this will be buzzer
4:11
two.
4:13
Okay.
4:15
So when toggle switch one is turned on
4:18
memory bit gets through and when the
4:20
memory bit gets through. So firstly the
4:23
when toggle switch one is turned on the
4:25
signal will pass through this contact.
4:28
As a result, this memory bit gets to
4:30
gets on. And when this memory bit gets
4:33
on, the signal will pass through this
4:36
contact. As a result, this buzzer one
4:38
and buzzer two gets on. And when toggle
4:42
switch one is turned off, the signal
4:44
will not pass through this. But this
4:47
memory bit is true. This contact is also
4:50
true. So the signal will pass through
4:52
this. As a result, this memory bit
4:54
remains true even when the toggle switch
4:56
one is turned off. And when the memory
4:59
bit is true, the signal still passes
5:02
through this contact. As a result, these
5:04
two buzzers still remain on. So when
5:07
toggle switch one is turned on, buzzer
5:09
one and buzzer two both gets on. And
5:12
when toggle switch one is turned off,
5:14
both the buzzers remain on. And to turn
5:18
off these two buzzers, we will we are
5:20
going to use one more toggle switch that
5:23
is toggle switch two. And for that
5:27
we will use a normally closed contact.
5:30
So here we will use a normally closed
5:33
contact.
5:36
So we will insert a normally closed
5:38
contact like this. And
5:42
this will be toggle
5:46
switch two.
5:49
Okay.
5:50
So when toggle switch two is turned on,
5:54
when toggle switch two is turned on, the
5:57
signal will not pass through this. As a
6:00
result, this buzzer one and buzzer two
6:02
gets off. We can also use this buzzer
6:05
two here.
6:10
So that when toggle switch two is turned
6:13
on the uh the signal will not pass
6:16
through this as a result. So this is a
6:18
normally closed contact. So a normally
6:22
closed contact in true state will not
6:24
allow signal to pass through this. As a
6:27
result this memory bit gets off and when
6:29
it gets off the signal will not pass
6:31
through this also. As a result buzzer
6:34
one and buzzer two gets off. So we will
6:39
generate code
6:41
go to online and start simulation
6:45
and after that we will log in.
6:49
Yes.
6:51
And then we will start. Okay. So
6:55
initially both the buzzers are off. So
6:57
to turn on these two buzzers we have to
7:00
turn on toggle switch one. So to turn on
7:03
this toggle switch one, we need to
7:05
change its state. We will click here.
7:08
When the true appears here, we will go
7:10
to debug and click on write values. You
7:13
can see here toggle switch one gets
7:15
true. With that, this memory bit gets
7:18
true because the signal passes through
7:20
this. And you can see here this toggle
7:22
switch two. This toggle switch two is in
7:25
false state and it is used as a normally
7:29
closed contact. So a normally closed
7:31
contact in false state allow the signal
7:34
to pass to this as a result this memory
7:36
bit gets through. You can see here
7:38
memory bit is true and when this memory
7:41
bit is true it is a normally open
7:43
contact here. So the state of this
7:45
contact is true. So the signal will pass
7:47
through this. As a result this buzzer
7:49
one and buzzer two gets true. And then
7:54
we will turn off this toggle switch one.
7:56
Click here. When false false appears
7:58
here then we will go to debug and write
8:01
values. You can see here toggle switch
8:03
one gets false but memory bit remains
8:07
true because we have latched this memory
8:09
bit here. So the signal passes through
8:11
this as a result this memory bit still
8:14
remains true and when memory bit is
8:17
still true the current still flows
8:19
through this. As a result this uh this
8:21
buzzer one and buzzer two still remains
8:24
on. And to uh to turn off these buzzer
8:27
buzzers buzzer one and buzzer two we
8:30
will be using this toggle switch two we
8:32
need to turn it on. Click here make it
8:34
true and then go to debug and click on
8:36
write values. You can see here the
8:38
toggle switch two does not allow signal
8:42
to pass through this because it is a
8:44
normally closed contact in true state.
8:46
It will not allow signal to pass through
8:48
this. As a result this memory bit gets
8:50
false. You can see here memory bit got
8:53
false and as a result this memory bit
8:55
will not allow signal to pass through
8:57
this as a result this buzzer one and
9:00
buzzer two got got off. So the state of
9:03
buzzer one and buzzer two
9:05
uh will be false. So when toggle switch
9:08
two is turned on buzzer one and buzzer
9:11
two gets off. It was all about this
9:14
example. Thank you for watching.
9:18
