So, hey everyone and thanks for joining me this evening, wherever you are in the words

So, hey, good evening, good night and good morning. So, I'm here to just talk about the Azure Data Factory

So, it's a quite popular topic sent to the Azure. So, in the world of the data, in the world of the big data, we always talk about the data

And then data exists in multiple forms. It's an organizational structure, it's just an organized structure in a relational format

or in non-relational format or any other, it's just, it's just a question of many other systems

So, however, on its own data, raw data doesn't have their own proper meaning or doesn't have

any context, it doesn't have any meaningful insights to the yst, data scientist or

to the business decision maker. So the big data always, once we have coming from the multiple sources, we always require

the surveys that can orchestrate, can operationalize the process to refine this enormous storage of the raw data

into actionable business insights. So that's why the Azure Data Factory, which I'm going to talk about is a very vital

plays a very vital role in the cloud service that build for the complex hybrid structure

So this is about me, a little bit of my introduction. I'm a C Sharp Corner MVP holding a couple of certifications

This is my blog sites, YouTube channels, Twitter, LinkedIn, at the end, the C Sharp Corner sites

So I'm quite active on the C Sharp Corner. You can follow me on the C Sharp Corners

and like comments on the articles if you need any help. I'm always available for that

I'm working and I'm MindTree Limited in a Bangalore located as a senior technical architect

Thanks for that. So now come back to the topic. So, Azure Data Factory

So what is Azure Data Factory basically? So Data Factory, as you can see on the screen

is just a cloud-based data integration service and used to compute the data storage, data movement

processing the service into the automated data pipeline. So once we talk about what is Data Factory actually

So Data Factory is a cloud-based path solution, platform-as-a-service solution. So it's just, we don't need to worry about the servers

for the scalability, for the patching, it's a server less activity. What ever we are using the component

how much we are consuming, we need to pay for that. Second, we say that data integration service

definitely it's allowed to integrate multiple sources and generate and provide a common platform

where we can integrate multiple sources of data at a single form

And then orchestras and automation. So it has 80 plus connector and pipeline can be automated

whenever it's required. data transformation. Then definitely when we get the data

we have ability to transform to the insights, data break, as your function, other data transformations tools

So when we talk about the Azure Data Factory, so in the past, if you will see SSIS package

when the peoples are using into the on-premises system. So it's a cloud-based service on the Azure Data Factory

So here the things come, what is ETS? So when we talk about SSIS

So that's the terminology come ETL and ELT. What is both and what's the difference in between those

So ETL is just like extract transformation and load the data. First, we need to extract and then transform

and then load the data or ELT, we'll say extract, load and transformation

as you see at this section. So first we need to transform the data using some formulas

but we are going to write filters, lookup before loading the data. or here we are going to transform the data

loading into the data warehouse, and then we have an ability to change the query on the fly

and read the data and change the data as per the needs

That is ELT. That's depending on the business scenarios which we are going to use, ETL or ELT

So it's a very high level comparisons, SSIS and ADF. So on a very high level or 30,000 feet

I will talk about SSIS is the on-premises solutions which were used earlier

Now, we're talking about the cloud, we have an ADF. It has a much higher scalability

It has a cloud and SAS connectors. It has an event-based trigger

We can run the SSIS package with an ADF also. If we have, we can do the connectivity

with the on-premises environment and we can run it on the Azure Data Factory

So data factory considerations, we'll talk about. So there are basically the two versions

of the data factories is there. So V2 and the V1. V1 was the first, so currently the V2

it's a quite improved version as compared to the V1. And then we have a build option

So there are a lot of options that exist to do the coding sources to the configuration

in this section. We have a PowerShell option, .NET, Python, REST, on the web, that ARM templates

So it's a highly integrated with that DevOps key walls where we are storing our credentials

on a secure manner. Monitors, we can monitor all our pipelines or our integration services

We can do the automation for those sections. No data storage. So this is a key factor

Azure Data Factory doesn't store anything within itself. It just process the data and move from one locations

to the another required location where we need actual processing. It's have a security standards on its own

HTTP or CLS whenever is possible. So let's talk about the main data factory element here

So I'll just draw the simple diagrams to make it easy so we can understand

So if you see here, so this section is just a toy and this toy is having a two component

we need to integrate. This is a buzzer and this is a battery section

So if need to add into this section, so the activity and the jobs run one by one

First, we are going to fit the battery into the toy And then in the next job

we are going to fit the buzzer also into the toy. So each job is done by the one particular person

which is the activity here, right? So this is called the activity

So in short, if I will say, what is pipeline? So this terminology is very important

So after a couple of minutes, when I will go to the demo, so it's very useful to understand what is pipeline

what is activity? So activity, combinations of activities called a pipeline here

and then it's the integration runtime. So what jobs is running, it is called integration runtime

and the trigger actions when my job is going to trigger. Okay, and here is a link services

So if I just talk about in the examples, in the next slide I will talk it more about

what is the link services, why is required. So basically once my job is going to done

it's going to connect with any of the services. If I'm taking the data from the blog

so I need to connect with the blog as a connection string. I need to push the data into the SQL

I need to connect with the SQL via connection string. So those activities

So this job, which we are calling is a data set. So it has a commission of the components

what we need to do called a data set here. So entire process which comes here

the data sets, pipelines, activity, link service is called Azure Data Factory

So we'll try to understand all these things one more time here to get the more clear picture So we have a pipeline which is a group of logical group of the activity and those activities going to consume with a data set which consumes and then produce the results for the activity

and those data sets what we have data sets can be the my where my data exists into the multiple

storage which may be the block storage bucket it's going to store there and it's going to connect

with those services which is called the link services and my activity run on those liaison

of link services configures. So, take the real-time example. So, what is the data factory element and relationship

Okay, so here we're going to talk about Azure Data Factory. First, whenever we are going to define

the structures of the Azure Data Factory, so one pipelines come into the picture

In the pipelines, we need to define the integrations of runtime. Under the integrations runtime

so here I will just talk about, I have two components I'm going to take

So I will just store my data in the backend data, which is coming from the multiple sources

some other systems is dumping into the blog storage. So it's going to, I need to move the data

from the blog storage to the SQL server. So this is the Azure data factory

So we can write a code also to do all this activity, but code is not feasible when I'm doing

on a very large basis, all those structures. So it's an error, prone and just a cloud base

we can say ETL as a service, this process. So the blog is going to connect to the link service

Similarly, SQL is also connected with their own link service. And then once it's connected to the link service

which is part of that data set. Similarly, SQL also having a link service

and a part of data sets. And both we have a one section where my data exists

And this is another section where data needs to go. And then activity comes in between

So which is called the activity. So there is a multiple activity exists

what we need to do with the data. So I just in this scenario, we need to take the data and dump into the SQL server

using the copy activity. So we'll take the scenarios before going to the demo

So for example, if you talk about the aerospace industry, so there is a lot of

industry is having a lot of data. And then data, what those airport authorities

or the airline authorities, they want to process the data, what time the flight is going to schedule, okay

What's the status of the flights? How many passengers are there? What's the origins

What's the destination? So such type of data, each airline is having

their own storage. So the airlines or the airport authority, they want to process the data

So in that scenario, they feel talk about the real time and it would be very helpful to take the data

from the multiple sources, but in a blob storage, S3 buckets. So lot of storage are there and we can just dump it

into the one hard data warehouse and do the processing and connect to the Power BI and generate the recordings

So that's all for this. I'll just quickly jump to the demo and we'll see

Yep, so I login to the portal.azure.com. Here I will just create from the scratch the entire

structure. So I will just take the storage account first I will create here. I click

on storage account. I will just click on create. So here I will just create our new resource group access to the Azure Virtual Conference

04 is my resource group. I just give the name Azure Virtual Conference 04 Blobs Storage. Yep

So here is this. I will click on the, I am okay with the other configurations

I will just take it by default, other configurations, and click on the create

So let it create the storage account where I'm going to dump the some CSV file

Apparently, I'm going to create the Azure Data Factory here. So here is a Data Factory

I'll just take Data Factory. I'll just click on Create. So I'll select the same resource group

which I use here. and I will give the name ABC04 and say our data factory to the next one yeah so the github I will just not connect for this demo purpose I will just write forward go

I will just the next I am ok with other configuration review and just click on the create

So the data factory object also created. Now data factory is the intermediate layer. Now I need to create a SQL server also. I will just go to the again to the portal home sections. I will create a SEO SQL, create resources. I will just SQL database

Click on create. So here I will select my resource group where everything should go

I will just keep the name ABC04 Azure SQL Database. I will just put the name of the new server

here we see 04 is your SQL database server yep I'll create a password just here I will create like that SA admin

I'll create a password for this one password so the password is created click on okay

So the server is get created. Now the compute storage, I don't need that much storage

I will just reduce it. For this demo, I need a minimal requirement

So I just click, looking for the standard. I'm okay with this cost

So creating the SQL server, the cost is coming almost 991 INR

I'm okay with that. Apply. And I'll just go for the next

Just check, okay, public endpoint. So for the production purpose, we should not do the public endpoint

We should define all the IP address which is required, but for time of purpose

I'm just using the endpoints for our public, create and review. Yep

So what I did, I just created a blob storage. I created Azure Data Factory

I created a SQL Server. Blob storage I created, I will dump the file there

I just assume the multiple sources as dumping into the Blob storage file

I will take the file, process into the Azure Data Factory extract the data and move it to the SQL server. So that is the gamut theme. So let it create

I will in the meantime I will go to my resources and just check the blob storage. I will go to the

home, my resource group. So let it come. AVC04 is my resource group which I created. So blob

storage has already came data factory SQL server is in provision stage I will go to the

blob storage. So in blob storage I will create a one container and just give the name of

the containers as a input where I manually place the file as of now I will just click create Yep it created So for the demo purpose I have already the file which is having the some data

I will take this file and upload it here. So just click on upload

Select the file. Yep, select flight data. Upload

So this file is get uploaded, which is my raw data, which is coming from the multiple sources to me like that

How we better we can check what content exists here. I'll just go click on edit and click on the preview board

Yeah, so this is the data. What we have the IDs, flight names, where is the to

what is the airport code, countries, and all such data we have

have almost 44 records exist so that's pretty good I got the data here now move

to the SQL server and let's create the table structure for us at least move to

the resource group yep let it come it's still from its name so the server has came up

It's taking some time to come up. Okay. Let it refresh one more time

SQL server should come here. Yep, just waiting to load. Yes

So the SQL server database, it's came here. I select the SQL server

So here we can go to the query editor and we can see the SQL server structures what we have

It just asks for the credentials. So I'll just have a SQL server authentication

I will use this one. Password, click OK. Yep, so I got what the structures I have

As of now, nothing is there. I have a blank table. So I'll create a one blank table as per the schema

what I have. So let me go into the structures. I have that structures

the query I have already made it. I will just take the particular query

and go back and run it. So now my tables, blank tables will be there

in the SQL server. All right. Yep, nothing will be there. It's just a blank table we have

Now we move to the Azure data service and our actual work will start there

I'll go to the resource group, Azure data factory. So, once I click to the Azure Data Factory

this is the interface where we land it. And here we have a sections like authors and the monitors

Once I click in author and monitor, it will go to the adf.azoo.com

The Azure Data Factory interface will come up here. And here we can define our own pipelines

activity and data sets. So let it float. So we'll configure for the blog and the SQL connections

and integrations between both here. Yep, so once you land in this page, so this page has a very well documented all the components

from the Microsoft, what is Azure Data Factory and why we need to use all the other activities

just go through this documentation is very useful. And they have defined the entire process itself, we need to create a pipeline, we need to create

a data flow, and we can create a pipeline from the existing template and we can store

our process, what we are going to create as a template. We can use the activity like the copy data

We can configure the SSIS integrations from the on-premises as well as what we are doing

in the Azure Data Factory, the cloud-based and GitHub repository also we can add

So I will just click it here and go to the actual process

where we can define. So this is my factory resources. So to start with, we need to define a pipeline

So for the pipeline, I click on the right-click and the new pipeline

So here it's come. So I'll just give the name. We need to store the data from the block to the SQL

I will just give the name block to SQL here, just a name here

And for the time being, I will just place the one activity. It just will wait

So it shouldn't for the error while doing any processing. So I got the blank activity

which I just dummy it here as a wait. Now let's move to the data sets and create a data sets

which will connect with our block storage. So I'll just select the blob storage here, click continue

So what type of, if I'm talking with a blob storage, what type of content we have in blob storage

I have a CSV file. So we can define what type of content we are getting

from the multiple sources. So that type of format we can select here

So I have a CSV file, I selected this one. I'll click on continue

So I can keep the name blob-plied-data. So I can select the link services

I click on new. So the link service, there are multiple options to create a link service

So it's just a connection strings, which we are creating here. So I'll give a name, the block

flight, data, link service. Just for the names sake, okay, it should be the proper naming convention

So I can understand. Yep, I'll just keep it the accounts key

So basically once for the production purpose, if we are going to use, we need to use the manage

identity is a recommended one but for this time I use the account key and I will select my subscription

and then I select my storage account which is the 04 blob storage which I created and I just check it for the connection

if everything goes smooth it will show success else we need to correct the error

if it succeeds I click on create So let it create a connection

So once it's created, we created a linked service. Now we need to give the file path where our file exists

So here we are just giving hardcoded this particular file name, but we can make the parameterize

and we can just take it this as a parameter and we can change it in the actual project

So the first row what is coming here, we can select as a header. Click OK

So this settings we can do the changes later point of time also

So here also we have those configuration settings. So this is the one data sets we created

which is connected with the Blob Storage. Now we will connect with the SQL in a similar fashion

So the SQL, I'll just go to the Azure and select the Azure SQL database

So here I'm creating the SQL flight data and create a link service here also which is going to connect with a SQL. So I will

give the name here SQL.Slight Data Link Service

So for the connections I will select my subscriptions. Let it be as is those

things Server names what we have 04 Database name 04 and the Authentication I will use SQL I created those one SAadmin is my user name password is my password

Okay, we just check it this one. So this database, this data set is going to connect with a SQL

It is successfully connected. Click on create. So now we have a two data set and the one pipeline exists as per this diagram

diagram what we talked about here. We have this section in place, we have this section in place

now we left it over. We need to create an activity which is going to connect both

Okay so coming back here the table name, what the blank table we have created. We need to select

the table name. I clicked on ok. So now the section we are good to go. Now we'll go back

to the pipeline and pipelines I will select the activity which is copy data I'll just drag and

drop here and this is no more is required I will just right click and delete this section yep so

here once I select this one so it just come up with a settings what configurations we need to do

what is my source and what is my destination so I go to the source source is my blob storage

where my data exists. Okay. And the sync, which is my destination

where the data is going to go, which is a SQL. So let it come

So here we have a lot of process. If we need to use the stored processors

we can define pre-copy script when any processing is happening from the block to SQL

So I need to do any pre-processing we can do here with the scripting

Now going to the mapping. So this section what it says, Whatever the columns we have

it may not be the same in the Blob storage or in the SQL. So we need to do the mapping from the column

As you can see on my screen, my columns also not the same. So here are a few columns which is same as map

but not of the columns it's not mapped. Here I have a destination section

but sources doesn't map. So I will select those particular columns, which I feel it's appropriate

Prom is this one. So here is the airport code. Here I have a country code

So similarly for the other columns, for the destination, it's a 2. It's a 2 airport code. It's a 2 country. Yep. And then finally the status. So here I have a flight status, but here I don't have a column with the name of flight status. I will select a status. So I'm good to go. This is a warning. I will just keep it as of now. Yep

So this section has done. So what we have done, we connected with a blob storage

we connected with a SQL center mapping. So let's validate this section

Yep, so our pipeline has been validated at no error found. So we are good to go

So before publishing all those things, better to debug this application, entire process

what we have defined and check whether it's work find or not or any error access for that

So when we are debugging, our pipelines is running. So it's in process

So let's see, let's wait for a couple of seconds and it will show the status if it succeed or not

Yep, it succeed, we got the message. It succeed when we did the debugging

So let's go to the Azure SQL and just check before publishing whether we really get the data

or not here. I'll just select the command and click on run

Yep, so it's that easy. So I didn't write a single line of code

using the Azure Data Factory, the very vital tool, and I got the all data in my SQL

If you need to see what data it's came here, we can just check how many records we were having

in the blob storage and what it came here. Yep, all 44 records came here

So now we are good to go and we can publish all this activity

So Blob storage, apart from that, we can, so with Azure Data Factory

we can do a lot of other things. So like once we did the publish all, we can define the notification

When my job is get success or job is get fail. So accordingly, the target audience will get the notify

and we can monitor when our job has been published and it's going to trigger as per the schedule

So we can monitor all the jobs and we can see what the status is coming

what job is running and which job is took the what time

and what's the trigger run, what's the integration service. So all the activities will be listed down here

It's a quite rich dashboard, we can get it here. So as of now, it's a blank because just now I created

and didn't run using the publishing services, right? So that means now as I publish, I will go back again

and let it run one more time. Yep, let me run it

So it's running again. So the agenda running again, why I'm showing

So I didn't write any of the pre-scripts, pre-validation scripts as I ran

What is doing? It's just taking the data from the blob and keep copying the data into the SQL and data

will get keep adding. Now we have a, earlier we have a 44 records

Once my job will finish, it's here. So it's still in queue

Once it's finished, as it succeeds, and if I run it again, data will keep adding here

So we can write all those scripts to validate the data. So I'll write one simple script

So I just want to delete the data, whatever it exists, and it will upload the data from the scratch

So it's quite simple. We'll just select our activity. And here in the mapping section, not in mapping thing

Yep, so we can write the pre-copy script here. So it just says delete from this particular table

So we have a table like data. I'll come up here and just run it

We'll just validate one more time and just do the run it again

So let it run. Now we'll see what type of data and how much records we will get it again

It's queued again. It will not take couple of more seconds

Yep, it succeeds. I will go back to my query and I will check how many records we have

Hopefully we should have 44. Yep, here we go. So we have 44 records

Now, earlier whatever the records was there. So we can just do the processing

before uploading the data into the SQL. So this is more about how we can transform the data

before doing the loading here. Yep. So that's all from my side for this session

So as in recap, so what we did, we just take the data from the external source

that is a blob storage and did the processing and dump the data into the Azure SQL

via the Azure Data Factory or ETL as a service process. Thank you for joining me
