Various types of SFD BMD for various load

Here you can be learned how to draw various types of sfd & bmd when the various type of load acting on beam. The Chracteristics of sfd bmd you can find out which is SFD formed with constant line, inclined line & for triangular load the sfd formed by cubic line. On the other hand, the bmd formed with parobolic, cubic & inclined line. So you can guess! If you didn't understood or any query please write down in the comment section below. I will try to back you at my best opinion. And make sure you subscribed 11 inches Engineering channel.
