Power BI - Creating and managing hierarchies

Hello, friends and welcome

In this segment of the video, I'm going to show you how to create and manage hierarchies

in Power BI desktop. So let's get started off. Now to help the user to navigate through your data, we tend to create different hierarchies

in such a way that he can understand the data flow and how to move up and down between them

And that's the only reason we create hierarchy so that we have some order of the data

Alright, so how we create this hierarchy? Now as I move on to my next slide, it can be seen on the extreme left side of your screen

you will find the field's pane. So in order to create a hierarchy, you simply have to pick one field and drop it onto another

The moment you drop it onto another, a hierarchy will be created right in front of you

So once you have created your hierarchy after dropping each and every segment, you can make sure

that the order of that sequence can also be changed. how you can change that you simply have to right click on any of the column and you can ask

him to go up or you can ask him to go down as well so this is how you can manage the position of

different columns in your hierarchy as well so if you move on with this so now at any time

whenever you would like to create a new presentation or a new projection at that time we

can take this entire hierarchy and drop it on your axis in such a way that the projection that you

want to build will be a easier task all right guys so how to create this

hierarchy and how to manage this hierarchy will be having a better understanding

of this in our practical approach hello friends and welcome in this video we

are going to learn how to create and manage hierarchies in power bi so let get started and see how it is done now in order to do that first me let me show you a quick table and I will tell you what is the difference by creating hierarchies how it will help you and by not creating how tedious my work can get apparently So I quickly create a table under the product table I will take the category column the manufacturing column the segment column and the product column All right So out here you can see I have the product column I have the product column

product, the category, manufacturing and segment. So while creating this table, if you have noticed, what we have done here is I have manually selected each and every column and

drag it in the visualization sheet that is my report pane, right

And we have create a table out here. Now this involves loads of manual work and this is not even in the hierarchy which I want

So basically let's say I want it in a hierarchy. First it will be having category, then segment

then segment then manufacturing and then product right we can get a hierarchy like

this so in order to get that hierarchy see what is needed to be done so as of

now we will go ahead and delete this visualization and we'll create a hierarchy

under the product column itself or the product table itself alright so see how

it is done I will simply pick any of the column and drag it under the product

ID see what happens when I drag it under this product ID column it will

automatically create a new hierarchy and name by default it is naming as

product ID hierarchy if I want to change the name of this hierarchy I simply have

to go to this three dots which can be seen on the extreme right hand side right

I will simply click on it and this an option which allows me to rename this

hierarchy as of now we will name this as hierarchy one is the first hierarchy that we have created so I just name it hierarchy underscore 1 and I hit enter it gets added out here Alright so basically what I want is I want the segment as well out here so I simply select this column segment

I'm sorry the segment which has column in it and I will simply drag it here okay so I have the segment

column as well and also I want the manufacturing column to be added in this

hierarchy so I'll simply drag it okay so out here you can see I have all the columns

which will be needed for my projection but I now what I want to do is I want to

align them in such a way that it should be in a proper order so I would like to

get the category first then the segment the product and then manufacturer all

right so in order to do that I need to simply select this category and drag it

upwards so this is how you manually do it so category gets on the

top similarly I want segment on top so this time we'll try a different way I will

click on this three dots and I'll ask him to move up all right I'm sorry I

have by mistake I have selected move down that's a reason it has moved from third

position the fourth position so I'll simply select this and drag it up all right

now I have this category segment product and manufacturing in my order all right

so this is the order which we which we required all right so we have

in hierarchy now what is the use of hierarchy we will see it in at the time of

we create a projection so let's go ahead and create a projection I will go

under the visualization pane and select a stat column chart all right now it's as

of now it's empty we need to add some values inside it so I will select this

hierarchy and drop it here the moment you drop it here you can see all those category segment product ID manufacturer got involved in it in this particular projection automatically and I do not have to do it

manually all right so this is how it is useful also will be requiring some values out here so I will go on to the sales fact and select the revenue and drag it under the value

All right the moment you drag it in the value. You can see my projection is right here in front of me in which I have all the category so revenue by category

as it can be seen right so I have the mix all this all these categories the very first one so the moment I drill down on it it will show me segment wise right so how I do that is very simple if you want to select if you want to drill down so in any of the columns you simply have to go to that particular projection let's say for urban I want to drill down and want to know the detail of it so I'll simply right click on it and I will click on this option which drill down right so at the moment I click

click on drill down see what happens now I'm getting it the

cat revenue by category by it segment as you can see first it was category now it is

allowing me to get the category along with the segment so I have this different

segment all together and what is the revenue for urban that they have generated

so as simple as that guys if you want to drill down more it will add the product

ID as well so simply right click on any of the column and drill down more

So now it is selling me revenue by category segment and product ID

So this is how the projection looks like. Now if you want to simply go up, you simply have to go drill up so that it goes to the previous projection and drilling up is taking me to the previous projection all together itself

All right. So guys, this is how you can create and manage hierarchies in power

All right guys. So this was all for this video. See you until next time
