hello friends welcome to free CAD tutorial in our previous tutorial we have
0:05
learned how to create a technical drawing in free CAD in this tutorial we
0:10
will learn how to give welding symbol to the free CAD drawing you can also visit
0:16
my website macnexus.com where I write articles and tutorials on a free CAD you
0:22
can also download my tutorial source frame from the here you can also
0:27
support my work by buying my free CAD crash course for beginner it is a very
0:33
basic level course for the beginner user where a beginner user can master the
0:39
free CAD and you can also support my work on coffee.com you can buy me a cup
0:46
of coffee you will get my website link and my Ko-Fi donation page link in a
0:52
video description. So before giving the welding symbol we will study our model So this is our model we can see that these two plates assembled with these two pipe and we want to give welding symbol to make a permanent connection with this pipe we will give fillet weld from the
1:23
outer side to join this plate and pipe in free cad it is not easy like other
1:34
software's autodesk or solid works to give the welding symbol I hope in a
1:44
upcoming version of a free cad it will be much easier to give the welding
1:51
symbol to give the welding symbol first we have to create a ladder so click on
1:58
add a ladder line to the view first select the view and then click on add a
2:06
ladder line and here you will get the customization option like a start symbol you can use arrow dot or triangle field as per your choice you can give color to your ladder width you can specify and type of the line like
2:30
continuous dash or dot so I will keep the settings default here now you have to
2:36
pick the points for your welding so I will click on pick points and I will
2:48
select my point and create a ladder so once you finish drawing your ladder click
2:58
on save points and say ok now I will move my view to the down now you can see
3:06
that a ladder has been created which is pointing my welding now of on the frame
3:18
and now select the ladder line and click on add welding information to the ladder line click on it here I want to give fillet weld so I will click on the symbols and from here
3:34
I will select the fillet weld I want to give 5 mm bullet as per my plate
3:40
thickness and I want to give all-round welding so I will click here all around
3:46
and say ok now I will off my frame now you can see that 5 mm fillet for the all
4:01
round has been created so while creating the ladder line make the ladder line
4:07
little bit longer so this is all about how to give the welding symbol on the
4:16
free care drawing and the same fillet weld you can give on this side this side and this
4:24
side so this is all about this tutorial thank you for watching and thank you for your valuable time
