A common issue with Yanmar Marine Engine panels is that they lose their LCD engine hour readings after a few years. As this is not a commonly serviceable part you are faced with either installing a new panel at $800 and resetting your engine hours, or adding a new engine hour meter, which is a clunky fix.
//Creative Commons Attribution Licence video (Reuse allowed)
Show More Show Less View Video Transcript
0:00
Welcome to yet another Technical Tuesday episode
0:16
In this week's episode we are looking at the LCD engine meter on a Yanmar Model B panel
0:24
Now it is common that these fail after a few years and so you are no longer able to accurately log your engine
0:29
hours. Now there's a few fixes for this. One is to completely get a new panel. However, that is a
0:35
really expensive part and it also resists the engine hours. Another thing is to put a separate
0:41
engine arm monitor somewhere else on the boat. However, we have found that a $30 part ordered
0:47
from the internet is a direct replacement for the LCD engine hour meter on this boat. So today
0:53
we're going to strip it all down, put it back together and hope we will have a working engine panel
1:00
this is a bit of a fiddly job and for this you are going to need some tools the first thing you're
1:05
going to need the replacement LCD panel it is about 30 dollars you can buy it from this source
1:11
up on the internet this is a European supplier there should be a supplier elsewhere in your region
1:17
however contact them if you have no joy the second thing you're going to need is a set of talks
1:22
screwdrivers for those that don't know they are the little five pointed star shaped bits and you will need
1:29
those to access parts of this engine panel. The third thing you are going to need is a set of
1:35
craft knives. Now you can buy these in Walmart, very, very sharp pointed blades and that will become
1:41
apparent later on in the video when you need these. So probably a $10 set of craft knives
1:46
And the final thing that you're going to need, and honestly, I know that I used to be a dentist
1:51
but these things are so important when you're doing fiddly boat jobs. Get yourself a set of dental
1:58
tools like a mirror, a probe and a set of long-nose tweezers. You can get these on Amazon
2:03
you can get them on eBay, but for doing small fiddly jobs, they are invaluable. And I know
2:09
that I'm going to use these a lot today. Now, access to the back of the engine panel is relatively
2:14
straightforward. Four Phillips screws hold the panel in place. Be careful with this. There is a rubber
2:20
gasket, and if it has been in place for a while, you can accidentally tear the gasket. So gently
2:25
remove the engine panel. The rev counter which contains the LCD engine hours is held
2:32
in place by four torque screws. Remove these put them somewhere safe. I always put them in
2:38
a glass and then remove the wiring loom gently by pulling it from the back of the rev counter This should come away pretty simply and once you done that you will be left with your engine hour meter with the broken LCD hours meter
2:54
Now, I cannot emphasize enough that this job needs to be done inside on a flat surface
2:59
There are three torque screws which hold the whole unit together. Again, with your torque screwdriver
3:05
simply remove those three screws and keep them somewhere safe. Now the unit will still all be held together by mechanical friction, so a little bit of downward pressure from a blunt object like a Philip screwdriver through the back of the unit should allow it all to pop out onto your work surface. There we go
3:23
With the plastic lens cover and the bezel somewhere safe, we are left with the inner workings of your engine hour meter and your rev counter
3:33
Now, this is a pretty delicate piece of machinery, so you are going to have to be pretty careful as you handle it
3:39
With the electronics exposed, we now need to remove the old LCD panel and the ribbon connector
3:47
Now, on the Yanmar panel, there are blobs which are insulating putty that look like old chewing gum
3:53
This is where your craft knife comes in super handy. You have got to very, very carefully remove all the excess insulation putty
4:02
So using a very sharp tip knife and taking obvious care with fingers, we sliced the way
4:09
at all the putty. Now, be aware you don't need to be overly cautious with the ribbon connector
4:14
as you are going to be replacing the unit in its entirety. On this panel, we found that the
4:20
insulating putty had to be removed from two places. Blob number one, which is where the ribbon
4:25
connector connected to the circuit board, that was quite a lot of work and you do have to be
4:30
careful of the components underneath, especially the adapter that goes into the circuit board
4:35
And area two is the insulating putty where the ribbon connector passes through to the front of the LCD panel
4:43
Now overall, removing the old insulating putty from the circuit board took about 60 minutes
4:50
I cannot tell you how careful you have to be. And yes, I did chop through the old ribbon connector
4:55
It was pretty worn and it kind of fell apart in my hands. But again, I have to emphasize you've got to be super careful and super slow in getting everything cleaned up
5:05
Once most of the putty had been removed from the circuit board, it was pretty easy to pull the male connector from the female connector on the circuit board
5:14
This releases the whole ribbon connector and allows you to continue cleaning the area up
5:20
Now, this close-up should show you what you are left with. Star number one shows you the circuit board with the female part of the adapter for the ribbon connector This should be very carefully cleaned to remove all excess putty Star 2 is the male part of the adapter for the ribbon connector This should be very carefully clean to remove all excess putty Star 2 is the male part of the ribbon connector
5:37
Now the white plastic plug is not connected to the ribbon itself
5:41
so you should gently remove this from the ribbon connector and put it to one side once you have cleared all the excess putty from it
5:48
You will need this later. Its function is simply to hold the ribbon connector onto the circuit board
5:54
once you have connected the new part. So it attaches by finger pressure
5:59
It's pretty easy to unclip and to clip back in. But be aware, try not to damage this part
6:04
It is super important to make sure that this all works at the end of the day. Now, the next step is to access the old LCD panel
6:13
To do this, you need to lift the printed face of the rev counter away from the body of the instrument
6:18
This is done using the tip of a craft knife. You do not need to remove the face completely
6:24
Just lift it sufficiently to gain access. to the old LCD engine hour meter
6:30
Removing the old LCD engine hour meter was pretty straightforward. It is held in place by contact adhesive
6:37
but there is a little gap at the back of the instrument panel where you can actually use a small fine instrument
6:42
in this case a dental probe to push through and by applying some pressure through the panel
6:47
onto the back of the LCD engine hour meter, you can push it out and remove it
6:53
Once complete, we can offer up the old panel to the new one to make sure they are the same size
6:58
we can then spend some time making sure that there is no excess putty
7:02
anywhere in the mechanism that will hamper our ability to put the new LCD panel back in
7:09
So with everything clean and ready to accept the new LCD engine hour meter
7:13
we need to push the new one back into place. The ribbon connector is pretty new
7:18
and so needs to be carefully pushed through the slot that allows it to be connected to the circuit board
7:23
In this case, my more than capable assistant, the engine hour meter while we gently and very gently bent using pair of tweezers, the ribbon
7:32
connector through the slot. Once the end of the ribbon connector had been pushed through the slot
7:38
to take it to the circuit board, we were able to relocate the new LCD engine hour meter in the
7:44
position that the previous engine hour meter occupied. It was pushed firmly into place using finger
7:50
pressure and there was enough contact adhesive left on the unit to not require any more adhesive to be
7:56
used. Similarly, the printed dial from the rev counter still had contact adhesive on it and so we just simply were able to push this back down to relocate it. If however you find that you need a little bit more contact adhesive, you can simply get this and apply it using a Q-tip
8:12
The new LCD panel in place we are left with the ribbon connector which now needs to be connected to the printed circuit board Now the connector needs to be pushed into place on the circuit board and that is held in place with that little white male plug that we kept from when we disassembled it
8:30
Now, attaching the ribbon connector to the printed circuit board involves utilizing that small white male plastic connector that we removed during the disassembly of the unit
8:40
The easiest way we found to do this was to push the ribbon connector onto the circuit board
8:46
make sure that everything lined up and that the contacts were in place with the circuit board
8:51
And once we had that in place using some light finger pressure, maintaining its position
8:56
we then took the small male white plastic connector. And all this does is simply holds everything in place
9:02
That clicks in. And once you've done that, you have a secure ribbon connector against a circuit board
9:08
as you can see here. From here on in, we need to reassemble the unit
9:14
put the guts of the dial and the instrument back into its case
9:19
They have to align in a certain way, but it should all become pretty apparent. Then apply the bezel, the lens
9:24
and the retaining screws at the back should be pushed in place, and everything is secure
9:29
And once this is done, it is simply a question of taking the dial
9:33
reinserting it into the engine panel and making sure that everything works correctly
9:38
So now that's all fitted, let's have a look and see if we've got our engine hours back
9:55
So I'm pretty pleased with that a $30 part rather than replacing a whole $800 engine panel
10:01
In addition to that, I managed to preserve the engine hours because the chip is still the original chip that holds the data
10:08
So as you may have noticed, while I was taking the engine panel apart, replace the decal sticker on the front of the engine panel
10:15
This is a $50 part, but again, the UV gets to it, and I'll put a link to that decal there
10:20
Again, that is a really simple. That was a two-minute job. Just take the old chipped panel off and put a new decal on
10:26
So all good there. Anyway, I really hope you enjoyed that technical Tuesday
10:30
We obviously will back with more technical Tuesdays covering a whole variety of different topics
10:35
relating to boating, sailing, and all different. aspects of the life that we lead. So if you haven't already done so, feel free to subscribe
10:42
Click down there and also click the notification bells so you don't miss any more episodes
10:47
Hope you enjoyed that. Goodbye
