Deep wreck diving requires you to have gear that you understand in a configuration that meets your requirements. In this video I show my Closed Circuit Rebreather and explain decisions that I have made with the configuration. These include extra elements of redundancy and tweaks to improve my safety.
At the core, it's an AP Diving XPD (Inspiration) in a G-box case but with non-standard Manual Add Valves (MAVs) in a setup that meets my requirement
*Highlights*
00:00 Introduction
01:10 Why did I choose an Inspiration?
04:20 My rebreather!
06:21 Right hand side
06:51 Left hand side
08:47 The front
11:50 Much maligned Auto-air
14:13 The four safety checks that I always do
16:11 What happens next!
*Kit I Use*
Note, some of these are affiliate links so help support making my videos:
Gloves are Ansell Alphatec 87-063 - https://amzn.to/4jDHhX4
Main torch is an Orcatorch D630 - https://amzn.to/4jlT4tA
Backup torch is an Orcatorch D710 - https://amzn.to/4jhddRk
Drysuit is an O-Three Ri200 - https://www.othree.co.uk/drysuit-rang...
CCR is an AP Diving Inspiration (XPD) - https://www.apdiving.com/
Backup computer is a Shearwater Perdix v2 - https://amzn.to/42FXZOW
Reels are by Kent Tooling - https://www.divingproducts.co.uk/
Cameras are Paralenz Vaquita
Video light is NiteScuba NSV60 - NiteScuba NSV60 - https://s.click.aliexpress.com/e/_onH...
Phone housing is Divevolk Seatouch 4 Max - https://s.click.aliexpress.com/e/_omJ...
Strobes are Prozhaozhu 3000 Lumen Diving Strobe - https://s.click.aliexpress.com/e/_oBM...
*Like this video?*
If you enjoyed this deep wreck diving video then check out my other ones 👉 / @d33puk 🙏
You also may wish to consider buying me a coffee 👉 https://buymeacoffee.com/d33puk ☕☕☕
Show More Show Less View Video Transcript
0:00
hi this is Dom Robinson and welcome to
0:02
my deep wreck diver channel the question
0:05
I get asked most frequently in the
0:07
comments on my videos is for me to talk
0:09
about the equipment that I use and
0:11
that's what I'm going to do today i'm
0:13
going to start off with this which is my
0:15
AP inspiration rebreather but I'm going
0:18
to cover all the other gear that I use
0:19
as well so I know divers love talking
0:22
about gear so I think you're going to
0:24
really enjoy it before I go on to do
0:27
that though just a a request from me if
0:29
you wouldn't mind please can you hit
0:32
that like button if you haven't already
0:34
done so please subscribe and if you have
0:36
subscribed please turn on the
0:38
notifications those things help me
0:41
immeasurably the other thing that would
0:43
be great if you feel like it is to leave
0:45
a comment it can be about anything
0:47
whether you think this video is good
0:48
whether you think it's bad doesn't
0:50
matter i'd love to get your feedback so
0:53
thank you right moving on then
0:56
so my CCR my baby this is the thing
1:01
that's h given me so many great
1:03
adventures it's kept me alive as well in
1:06
all sorts of uh of situations so I guess
1:10
uh one of the questions I get asked
1:12
quite a bit is about different types of
1:14
rebreathers and you know why did I
1:16
choose an inspiration well uh I guess
1:19
it's a really interesting question so
1:21
the classic advice for choosing a
1:23
rebreather is to use the same rebreather
1:26
as the people around you now everybody
1:29
not quite everybody but certainly when I
1:31
started the majority of people uh around
1:34
me were diving and inspiration and that
1:36
was fantastic because it meant I had
1:38
this whole pool of support all these
1:40
people who knew the little nuances could
1:42
help me out if something went wrong and
1:45
and obviously provide advice and
1:46
expertise the great thing about the
1:48
Inspiration is it has been going forever
1:52
it's pretty much the first mass market
1:55
ECR ECCR and they've been upgraded
1:58
continuously ever since so they're
2:00
always adding uh new bits of capability
2:03
most notably uh five or six years ago
2:06
the handset changed from being being a
2:08
grayscale one to being a color one and
2:10
that was a fantastic improvement loads
2:12
of other things and it's in continuous
2:14
development not least because there are
2:16
so many of them out there the other
2:18
thing to highlight of course is that I
2:20
have invested a huge amount of my
2:22
personal time in in one of these so I've
2:26
got 15 years of experience on on an
2:28
inspiration and if I was to change to
2:30
something else I would obviously not
2:33
quite have to start from scratch but
2:34
certainly it would be a long time before
2:36
I got back up to up to that level so
2:38
I've massive investment in my uh in my
2:41
particular model a question you might
2:44
ask is would I buy an inspiration if I
2:47
was starting out again and that is a
2:50
really interesting question it's one
2:51
I've asked myself several times um and
2:55
I'm not 100% certain I I know the answer
2:58
there are certainly uh more advanced
3:01
rebreathers on the market there's
3:03
probably ones that have features about
3:06
the that have been uh that are on the
3:08
inspiration that have been improved um
3:11
things that that are done differently
3:13
that that I would quite like but on the
3:15
other
3:16
hand inspiration is absolutely tried and
3:20
tested it's whatever dives you want to
3:23
do on on your inspiration have almost
3:25
certainly been done and I guess that
3:28
level of uh proven ability is something
3:31
that that you need to uh need to
3:34
consider what else um I guess you got to
3:38
you it comes down to brass tax the
3:40
reality is that the inspiration you can
3:43
get a lot of them secondhand they are
3:45
relatively pre reasonably priced so I'm
3:48
not going to use the
3:50
term bargain basement but certainly if
3:53
you want to get started in rebreather
3:54
diving the AP is very very competitively
3:59
priced so uh there's a few reasons i
4:02
haven't given you an answer i haven't
4:03
said you should buy this rebreather or
4:05
you should buy that rebreather i've just
4:06
given you a few things to consider and I
4:09
think probably the most important one is
4:10
the one that I started with so it's the
4:13
one about choose a rebreather that there
4:16
are loads of people around you diving
4:18
because you have access to that
4:20
expertise that knowledge that support so
4:23
moving on to my particular one it is
4:26
pretty much a standard AP inspiration or
4:30
XPD as they they term them now the big
4:33
change I've made to it is probably this
4:35
thing here which is the the box
4:38
inspiration comes in a kind of standard
4:41
plastic box i've replaced it with this
4:43
Gbox frame um which is an aftermarket
4:47
product uh quite a lot of Inspiration
4:49
divers use this one or or there are
4:51
other ones available as well and that's
4:53
not to say the plastic box isn't bad it
4:55
is bad rather quite a few the guys I
4:57
dive with them uh dive with still use
5:00
them but uh for me it was a bit floaty
5:04
and I think the Gbox offers more ability
5:08
to hang stuff on the side and you can
5:10
see that's absolutely what I've what
5:12
I've done here so if you're new to
5:13
rebreathers um it's probably worth just
5:16
highlighting what is inside this uh this
5:19
box because this is I guess the uh the
5:23
meat of it so uh opening this up here
5:26
what have you got inside well inside
5:28
here this canister here contains a
5:31
scrubber that's how the carbon dioxide
5:33
that you breathe out is removed you can
5:35
probably see down the left hand side
5:37
here um I was wrong the the right hand
5:40
side rather you can see this tube coming
5:42
down into the bottom so gas comes in the
5:45
top here comes up comes through the
5:47
scrubber so this is uh an axial scrubber
5:50
through the top is the head which is
5:52
where the uh O2 sensors are where the
5:55
solenoid is to inject um oxygen and it's
5:58
also where the the brains of the uh the
6:01
beast is in there as well so goes
6:04
through that lot and then comes out of
6:05
this hose here and goes into uh the
6:08
mouthpiece and there's a a set of valves
6:11
in there that make sure that the gas
6:13
only goes one way one way round so what
6:16
else do we have on here well I'm going
6:18
to start off on this side
6:20
here and on this side here you can see
6:23
uh this large cylinder here is a 3 L
6:26
cylinder of
6:27
oxygen 3 L cylinder is good um more gas
6:31
by and large is pretty good that will do
6:33
me for at least two deep dives and it
6:36
would do me for for more shallow dives
6:39
what else have I got on the right hand
6:40
side here i've got a spare O2 cylinder
6:43
it's a small one um and that's there if
6:47
for whatever reason I can't access the
6:49
oxygen in my other cylinder moving to
6:51
the other side then I've got two
6:53
cylinders on this side as well the inner
6:56
one here is uh my dilluent and that is
6:59
the Tryix mixture that provides the loop
7:04
volume when you go deep obviously as you
7:06
go deep it gets crushed down you put in
7:08
dilluent that brings the loop volume
7:10
back up as you go down and that
7:12
obviously provides the helium into the
7:14
mixture that avoids narcosis
7:17
um and provides a reasonable gas density
7:19
to to help with the work of breathing
7:21
selection of the right dilluent is a
7:23
really important part of rebreather
7:25
planning this other thing here this
7:28
large 3 liter white cylinder this is
7:30
full of good old-fashioned air now you
7:33
might say what does a rebreather diver
7:35
need air for well actually quite a few
7:37
things so the first thing is I run all
7:39
my buoyancy off the air i run my dry
7:42
suit off it i run my wing off it and
7:47
that means obviously I'm not spending
7:49
expensive gas to fill up my dry suit and
7:51
helium you don't want to be putting in
7:52
anyway and also it means I've got gas to
7:55
put in my wing and I've got I've got a
7:57
lot of it there if I need it so um and
8:00
the great thing about air is that you
8:02
can breathe it at any depth pretty much
8:04
so that also goes into my auto air which
8:07
I will talk about in in a bit now a 3
8:10
liter cylinder you might say is a bit
8:11
excessive lots of people have smaller
8:13
cylinders that do that um for me I if I
8:18
didn't carry a 3 L cylinder I would have
8:20
to carry more weight so I may as well
8:22
carry more gas why wouldn't I so that's
8:26
the back of the rebreather probably the
8:28
one other thing you've you've identified
8:29
here is this green hose this green hose
8:32
is the one that comes off my
8:35
uh air cylinder and it's the one that I
8:37
attach into my dry
8:40
suit moving around to the front of my
8:43
rebreather and uh there's quite a lot
8:46
going on here as you can probably see
8:48
let's start off up the top here with uh
8:51
this thing here this is the handset not
8:54
currently turned on but that would be on
8:56
my left wrist and that doesn't have a
8:58
brain in it all that has in there is a
9:00
controller and that allows you it gives
9:04
you information about the the what the
9:06
three cells are displaying in terms of
9:08
the P2s it gives you information about
9:11
uh decompression it gives you
9:13
information about your current depth and
9:15
you can also change various things
9:16
associated with the rebreather on that
9:18
so really important what else have we
9:20
got well we got the two hoses here this
9:23
one on the left hand side is the one
9:24
that gas comes back from the scrubber
9:26
and it comes in and is going to go into
9:28
the breathing loop this one here is the
9:30
one that um the gas goes to the scrubber
9:33
from and you've seen those on the other
9:34
side what What else have we got well
9:36
we've got the big thing here which is a
9:38
mouthpiece and this is a standard
9:40
mouthpiece it's not above at all so if I
9:42
need to bail out I'm going to have to
9:44
get one of my open circuit regulators
9:47
what else have I got attached to it i've
9:49
got this thing here which is the uh
9:51
mouthpiece retaining strap or gag strap
9:54
um if you want to use common terminology
9:56
that just m makes sure that the mouth
9:58
piece stays close to my mouth and if I
10:00
was to lose consciousness hopefully it
10:02
would keep the uh the mouthpiece in my
10:04
mouth people have different opinions on
10:06
those people some people get really anti
10:08
them i I like mine i I'm a fan but hey
10:12
this is big boy diving you make your own
10:14
decisions you take your own risks what
10:16
else have I got on here well uh you can
10:18
probably see here this small thing is um
10:21
is the HUD and there are four lights on
10:23
there two red and two green and they
10:25
provide a visual indication uh to me
10:28
whether everything is okay or not if
10:30
I've got two greens I know the world is
10:32
well if the greens start flashing
10:34
something's changing if I start getting
10:36
red lights or red flat flashing lights
10:38
then clearly something is wrong and
10:40
those are right in my ey line so they're
10:42
really good as an attention getter which
10:44
will normally then take me to the
10:45
handset and the handset on there will
10:47
tell me if something is wrong the other
10:50
thing to probably point out is just in
10:52
the back of the box here is an audio
10:55
alarm as well so if there's a problem
10:58
the audio alarm will go off and people
11:00
who die with dive with inspiration uh
11:02
divers tend to get sick of audio alarms
11:05
because they are really effective you
11:07
can hear them from a long way away you
11:08
can always tell if somebody else in the
11:09
group is having a problem um some people
11:12
say that's a bad thing i have to say I
11:14
am a big fan right so moving on to a few
11:18
other bits and pieces so I get this lot
11:21
out the way what else have I got on here
11:24
well probably the thing that's difficult
11:26
to see around here is I've got a battery
11:28
for my torch it's in there and there's a
11:31
lovely little pocket on the inspiration
11:33
where my orcrch D630 fits there the
11:36
cable goes over the top and comes around
11:38
here you can see there my torch uh great
11:42
great bit of kit i uh I love it to bits
11:45
and what else have I got well uh you can
11:48
probably see here this is the much
11:51
maligned auto air which is an AP bespoke
11:56
thing it works as a regulator so you can
11:59
inflate your BCD on it you can also uh
12:03
breathe off it as well so that is
12:05
currently plumbed into the cylinder of
12:07
air on my back so if I need to I can
12:10
breathe down that 3 liter cylinder of
12:12
air should the 3 liter cylinder of air
12:14
run out then I have a spare hose here
12:17
which I hope you can see this one here
12:19
is attached into my dilluent cylinder so
12:22
if I needed to I ran out of gas or
12:23
something like that I could switch over
12:25
onto that other hose and fill up my BCD
12:27
with a cylinder what else have I got um
12:30
these are the manual AD valves here and
12:33
you can probably see that there are two
12:36
so the the top one here is attached into
12:38
my dilluent cylinder the bottom one here
12:41
is available for connecting to something
12:43
else and I can either connect those two
12:45
and one of my offboard cylinders i've
12:47
got hoses on there that I'll show you in
12:49
a minute or if I need to I can also
12:52
attach on the other side here this is
12:54
the oxygen mav you can see there's a
12:56
spare hose that goes to my spare O2
12:59
cylinder the oxygen m is is this one
13:02
here and this is both these mavs uh so
13:05
MAV for those of you who don't know
13:07
manual AD valve uh these are both the
13:10
non-standard AP MAVs and this one here
13:14
has got this thing on here which is a
13:16
shut off it allows me to isolate the
13:18
solenoid if I need to i have had a
13:20
problem in the past with a solenoid
13:22
sticking open so I could solve that by
13:25
just uh pulling that out and shutting
13:28
the solenoid off um and I could then run
13:31
the uh the unit manually using using the
13:34
manual ad if I need to i can also
13:36
connect in my spare O2 cylinder as I've
13:38
already mentioned with that and it will
13:40
go on there and I could drive my uh I
13:44
could could use my spare O2 cylinder as
13:46
well so a couple of different things
13:48
there what else have I got well I've got
13:50
a uh oxygen pressure gauge at the front
13:54
and I've also got a dilluent pressure
13:57
gauge at the front as well now uh some
14:00
rebreathers don't have pressure gauges
14:02
they obviously they're at the front they
14:04
kind of some people think they get in
14:06
the way all those kind of things it's
14:08
I'm a bit old school like that i like to
14:10
know how much gas I've got and it's
14:12
really important particularly before you
14:14
get in the water i do four things i
14:16
check that my oxygen is turned on and uh
14:20
I've got enough contents i do exactly
14:22
the same check with my dilluent i have a
14:24
look at my handset i check that my
14:26
handset is turned on and that I've done
14:28
the pre-breed so the scrub has warmed up
14:31
and the other thing I always do is I
14:33
check that my dry suit feed is fitted
14:36
and working and I reckon if I've done
14:38
those four checks and I get in the water
14:41
I am going to be okay uh I'm not going
14:44
to uh I'm not going to die immediately
14:46
so um sorry slight slight digression
14:48
there but those are the things I've got
14:50
what else have I got on the front of my
14:51
rebreather well um this thing here which
14:55
is a uh a dive knife and bit old school
14:59
once again dive knives so obviously lots
15:01
of people use cutters and everything i
15:03
love this thing it's a little Raora dive
15:05
knife really sharp it's located there on
15:08
this hose at the front i know where that
15:10
is i can get it really quickly and
15:13
uh I don't need to worry about it
15:15
because I'm a bit paranoid about cutters
15:17
i also have another cutter located here
15:23
i have another cutter located here on
15:25
the waistband you can see it there and
15:28
that is a drill of ice you know you pull
15:30
it out and uh it's got a bit of a net
15:32
cutter in there as well so they're a
15:34
good bit of kit as well what else have I
15:36
got on my belt um I've got this thing
15:39
here which is a PLB it's actually an AIS
15:43
one it's the old one done by Nautilus so
15:45
it's actually got a radio built into
15:47
that as well so I can get on to channel
15:49
16 i can get on to channel 10 whatever
15:51
else it is obviously the range isn't
15:53
great cuz I'm going to be at sea level
15:54
but at least I can I can speak to
15:56
somebody if there's an aircraft in then
15:58
obviously the cons will be pretty good
15:59
and as I say it's got that AIS beacon on
16:01
it as well so um I do love those i
16:04
actually think they're they're much
16:05
better than the uh the newer ones so
16:08
that is my rebreather and I hope you've
16:12
all found that very interesting now
16:15
unfortunately I had hoped to do all the
16:18
rest of my gear but I've simply ran out
16:20
of time uh to get it all edited and get
16:23
it published so I'm really sorry about
16:25
this but you're going to have to wait
16:27
for another video to cover all the rest
16:29
of my gear so my my dry suit my
16:32
undersuit my stages all the bits and
16:35
pieces I carry down with me they are
16:37
coming but uh not in this video so uh
16:40
anyway I hope you've enjoyed this one
16:42
and I look forward to putting the rest
16:44
of it together and getting it out there
Diving & Underwater Activities
Water Sports Equipment
