Hey, what's up everyone? If your Corolla
0:03
headlights aren't turning on, whether
0:05
it's high beam, low beam, or both, don't
0:08
panic. Today, I'm going to show you
0:10
exactly where the fuses and relays are
0:13
on your 2009 to 2025 Toyota Corolla. So,
0:23
All right, starting with the 2009 to
0:26
2013 Corolla, also known as the E140.
0:30
The headlight fuses and relays are all
0:32
hiding in this little guy. The main fuse
0:35
and relay box on the passenger side of
0:37
the engine bay. Pop the lid open and
0:40
you'll see a diagram right under the
0:42
cover. Inside this box, we've got our
0:45
main headlight players. You've got your
0:47
big daddy, the main headlight relay
0:50
right here. Next, see that dimmer relay?
0:54
Some call it the high low relay. This is
0:56
the VIP that decides if you're blinding
0:59
oncoming traffic with your high beams or
1:01
politely illuminating the road with your
1:04
low beams. And speaking of beams, you've
1:07
got power couples in here. We're talking
1:10
two 10 amp fuses for your high beams and
1:13
two more 10 a.m. fuses for your low
1:16
beams. Always check these first if one
1:19
set of lights is out.
1:29
Next up from 2014 to 2018, the E170
1:34
model. First things first, pop the hood
1:37
and head over to the right side of your
1:39
engine bay. Right here, you'll see this
1:41
big black fuse and relay box. Lift the
1:45
lid up and boom, here's your fuse and
1:47
relay diagram. Inside this box, we've
1:50
got our main headlight players. You've
1:53
got your big daddy, the main headlight
1:55
relay right here. But wait, there's
1:58
more. Let's start with the high beams.
2:01
They're controlled by the headlight
2:03
relay and protected by these two red 10
2:06
a.m. fuses. If either of these fails,
2:09
both high beams will go out. Moving on
2:12
to the low beams. These run through the
2:15
headlight relay, and again, those two
2:17
red 10 fuses. If they fail, both low
2:31
All right. In the 2019 to 2025 Corolla,
2:35
you need to pop that hood and go to the
2:37
driver's side fuse box right here under
2:40
this cover. Just press in on this tab
2:42
and lift the lid up. Boom. You're in.
2:46
So, let's dive deeper into this
2:48
electrical labyrinth. You've got a 10
2:51
fuse for your right-hand headlight and a
2:53
10 fuse for your left-hand headlight.
2:56
know him. Love him and check him when
2:58
your lights act up. Don't forget the
3:01
workhorse that's always on duty. The 7.5
3:04
am daytime running like fuse. This
3:07
little champion is energized no matter
3:10
if you're high beaming it or just
3:12
cruising with your low beams. It's
3:20
And that's it. Now you know how to find
3:23
and test every fuse and relay that keeps
3:26
your headlights shining bright on your
