hey what's up guys today I've got this
0:02
Toyota Corolla behind me and if your car
0:05
is acting dead when you turn the Kino
0:07
crank no click stick around because I'm
0:10
going to show you exactly where the
0:12
starter relay and starter fuses are
0:14
hiding and how to test them like a pro
0:23
all right starting with the 2003 to 2008
0:26
Corolla also known as the
0:29
E130 first check under the hood and look
0:32
at this fuse box see this little green
0:36
3M fuse right here that's your main
0:39
starter fuse if this is blown your
0:42
starter relay gets zero power quick tip
0:45
if it's blown and you're in a pinch
0:48
borrow the one right next to it that
0:50
one's for the amplifier just remember
0:58
fix let's head inside the car pop open
1:02
that little coin tray next to your
1:04
steering wheel or peek under the
1:08
pedals so here's the fuse check this 15
1:12
amp fuse labeled AM2 this sends power
1:16
straight to your ignition switch if it's
1:19
good the black wire on the ignition
1:21
switch will be live at all
1:33
times next up 2008 to 2013 the E1 40
1:38
model this one's got two locations the
1:41
cabin fuse box is right below the
1:44
steering wheel just pull the front edge
1:46
to open it up so here's the fuse it's
1:49
this 7.5 AMP fuse right here it is
1:53
responsible for the starting system and
1:55
the power outlet pop it out and check
2:03
it then head to the engine bay near the
2:07
back right corner closest to the driver
2:10
now check this out the main starter fuse
2:12
is this green 30 amp feed fuse right
2:15
here you can try to wiggle it out look
2:18
inside and make sure the metal strip is
2:22
intact you can also check this blue 15
2:25
a.m fuse because it is related to the
2:38
system all right in the 2014 to 2018
2:42
Corolla you need to pop that hood and go
2:44
to the driver's side fuse box right here
2:47
under this cover just press in on this
2:50
tab and lift the lid up now let's talk
2:52
fuses you've got two that matter first
2:56
this big 30 AM fuse it powers the
2:58
starter when the relay clicks and this
3:01
one right here the 7.5 a.m pam2 fuse
3:06
feeds the ignition switch which tells
3:08
the relay when to fire see this little
3:11
purple guy that's your starter relay and
3:15
here's a cool trick have a buddy turn
3:16
the key to start while you give this
3:19
relay a few taps with a screwdriver
3:21
handle sometimes they stick and a little
3:24
jolt gets them working again if tapping
3:27
didn't help pull the relay out wiggle it
3:30
side to side and pop it free now here's
3:33
the hack swap in another relay with the
3:35
same pin layout if the car starts now
3:38
boom you've got a bad
3:50
relay now for the modern E210 Corolla
3:54
from 2019 to 2024 we've got two fuse
3:58
boxes to check first check the under
4:01
hood fuse box in this location this is
4:03
the engine fuse panel on the M2 FKS and
4:08
two ZR5 motors now check this out this
4:12
right here is your starter relay if your
4:14
car is just clicking or doing nothing
4:17
when you turn the key this could be the
4:19
culprit try this have someone turn the
4:22
key to start while you give this relay a
4:25
light tap sometimes a stuck relay just
4:28
needs a little wakeup call next up the
4:31
starter fuse it's this green 30 amp fuse
4:35
right here you check if it's blown
4:37
you'll see the metal strip inside either
4:45
burnt now let's move inside the car yep
4:48
we're heading to the cabin fuse box you
4:51
may need to kneel down and look just
4:53
left of the driver's footwell to spot it
4:56
easily here's what you're looking for
4:59
this is a 7.5 AM mini fuse this one
5:03
controls your starter system if it's
5:06
blown your car won't even try to start
5:09
need a replacement just ask for a mini
5:12
7.5 amp fuse at any auto parts store
5:22
so that's it that's how you find and
5:25
test the starter relay and fuses on your
5:27
Toyota Corolla hit that like button if
5:30
this saved you time and drop your
5:32
questions or tips down in the comments i
5:34
read everyone catch you in the next one
