Model Holder Block with FreeCAD Part Design Workbench | FreeCAD Tutorial | Mechnexus |
May 14, 2025
#freecad #freecadtutorial #learnFreeAD
In this video I have explained How to Model Holder Block with FreeCAD Part Design Workbench.
▶️ Get my Complete FreeCAD Course : From Zero to Expert !
https://ko-fi.com/s/1ab4385434
▶️ Join my channel membership and keep supporting my work:
https://www.youtube.com/channel/UCcn6z2whMaFu-_LDsEXCfVA/join
▶️ Visit my website for more info on FreeCAD-:
https://mechnexus.com/
▶️ Download Source File of Tutorial-:
https://mechnexus.com/mechnexus-youtube-tutorial-source-file/
▶️ Buy Me a Coffee
I am very grateful that you watch my videos and I am constantly trying to improve the quality of the videos on this channel. If you'd like to help me do this, please consider supporting me so that I can to continue to produce content for your enjoyment.
👉 Help support this channel by buying me a coffee: https://ko-fi.com/mechnexus
Show More Show Less View Video Transcript
0:00
hello friends welcome to Frecad tutorial
0:02
and in this tutorial we will model this
0:04
holder block in freead as you can see
0:07
that I have already model it and I will
0:10
show you from the scratch how you can do
0:12
the same in free if you want to learn
0:16
free CAD from the scratch then you can
0:18
buy my complete free course from zero to
0:21
expert this course also available on
0:25
Udemy but uh problem is that uh UDMI
0:28
only give me the
0:30
37% of a course selling you can see here
0:34
user had paid $15 but I have only got $5
0:41
if you wanted to see the review of my
0:43
course you can go to the Udemy and s
0:47
search for the free CAD and you will see
0:50
my course complete free course from zero
0:53
to expert and this course is took by the
0:56
more than 2,000 students and I have got
1:00
the rating of
1:02
4.1 for the demo lectures you can expand
1:06
it and uh see the demo lectures and the
1:10
course structure but I will request you
1:13
if you found my course interesting and
1:17
uh reviews of the other student on Udemy
1:21
then I would request you to buy my
1:25
course from the my coffee shops because
1:30
if you buy from here it will help me a
1:33
lot so once you buy my course you will
1:37
be redirected to the Google drive and
1:40
here is the my course complete free
1:43
course from zero to expert go inside and
1:47
uh the sections I have shown you on my
1:52
kofi shop page so exactly same lectures
1:57
under the section is created for example
2:01
section one is a introductions to free
2:04
1.0 and what is new in a freecad 1.0 so
2:08
if you go to the section one so there
2:11
are the 18 lectures and if you go inside
2:15
of the sections one you will find the 18
2:19
lecture total and once you go to the
2:21
lecture one you will find a video file
2:25
which you can download to your system
2:28
and you can watch it and this course is
2:32
updated on a equal interval of a time
2:35
once the new feature is came and uh once
2:38
you purchase the course you have the
2:41
lifetime access to the course and in the
2:45
case of any doubt any query you can mail
2:48
me at admin
2:51
ratemnexus.com you can find my course
2:54
link on my YouTube channel you can see
2:57
the course link and uh you can also find
3:00
my Kofi course page link on uh pin
3:04
comments and uh video descriptions so I
3:08
will close this file and create a new
3:14
file so here I have created my new file
3:17
and I will insert my body and press the
3:19
space bar and on my origin and we will
3:22
read our drawing
3:25
so as we can see that uh here is a base
3:30
feature and after that uh there is a
3:33
boss of a 48 mm and there is a cut and
3:37
there is a hole so first we will make
3:41
this 16 mm plate on our top plane so we
3:44
will select our top plane and click on
3:47
the
3:48
sketch i will go to the model tab and of
3:52
my origin and I will click on the
3:54
isometric view
3:56
now here on this axis we will create a
4:00
construction
4:03
line we will create a
4:06
line and we will make a coincidence
4:09
relation with the origin
4:12
now I will give the horizontal
4:15
dimension of 90
4:18
mm 90 mm because if you see here here is
4:24
R45 on one side and R45 on the other
4:28
side as well but on the other side we
4:32
have this cut so therefore we have made
4:35
it 90 mm
4:37
now to make it symmetric we will add one
4:40
more
4:41
dimension and give it
4:45
45 and we will make this line as a
4:48
construction
4:50
line now we will move this dimension
4:54
outside and now we will draw a 20 mm
4:58
vertical line and then one line at a
5:02
30° so we will select the
5:06
line and then draw one more
5:09
line and we will make
5:11
it
5:13
20 and the angle we will give the
5:20
30° so this will be
5:23
150 and the dimension is
5:27
95 vertical so I will select this point
5:31
and this point and give the dimension
5:34
95 now I will move my
5:43
dimensions and now from this point to
5:47
this point is a straight vertical line
5:50
so we will select the line
5:53
and create a vertical
5:57
line and we will move it here and now I
6:02
will connect these
6:06
two so this is the half portion which we
6:10
have
6:11
drawn and
6:14
now we will move this dimension we will
6:18
create a line at a distance of a 20 of a
6:22
same distance 90 so click on the
6:28
line select this point and this point
6:31
and a vertical dimension of a
6:41
20 and add a vertical
6:45
this one also
6:47
vertical and make it a
6:53
construction and
6:56
now we will create a threepoint
6:59
arc but before that we will connect
7:08
it now select the threepoint arc select
7:12
this point and this
7:15
point and add the tangency
7:20
relation say
7:22
tangent so now it is
7:27
a 90 mm
7:29
diameter and our sketch is also fully
7:32
constrained so we will go to the task
7:34
and close it switch to the
7:37
isometric now this is of a plate of a 16
7:40
mm so we will select the sketch click on
7:43
the pad and give here 16
7:47
mm and
7:51
now we will create this cut so we will
7:55
select the face and click on the sketch
7:58
we will click on project geometry
8:01
we will project these
8:03
two
8:07
and we
8:09
will create a
8:13
line so this is the 20 mm so from here
8:18
20 mm this is a 30° line so from this
8:22
point we will create a line so I will
8:29
join i will select the line select this
8:36
point
8:39
and connect with this arc and now this
8:43
point is 10 mm from the this origin so
8:46
we will select horizontal dimension
8:49
select this point and this point and
8:51
give the 10 mm
8:56
and now I will connect these two points
9:00
select line
9:02
tool join it and here is a
9:09
conflict right click delete
9:18
it i will select this and this and say
9:22
merge this and this
9:25
merge and this and this merge and now I
9:30
will create a threepoint
9:33
arc and
9:35
uh join it click on
9:39
close click on extrude
9:41
cut from here say through all say
9:46
okay and now we will make this cut
9:51
for this we will again select the face
9:53
and click on the sketch and we will
9:56
project this
9:59
edge now select the
10:05
line and create this
10:08
profile this will be horizontal this
10:11
will be horizontal and this one will be
10:14
vertical
10:17
and this will be in a vertical
10:21
relation and this uh width is a 20 so I
10:25
will select it and give the vertical
10:27
dimension
10:32
20 and we can see that uh from the
10:35
origin it is a 20 mm so this
10:39
point this point and
10:45
line we will select this point and this
10:48
point and add a vertical relation of 20
10:52
mm now we will connect these two
10:55
points select
10:59
line join it click on
11:03
close save to isometric
11:06
click on the sketch click on the
11:08
pocket say through all say
11:11
okay so we have made the base now we
11:14
will add the material we will select the
11:16
face click on the
11:21
sketch and we will click on the edges to
11:25
project
11:28
it and we will select the line
11:32
tool to close our profile
11:47
we will close it now this height is of
11:51
48 mm so we will click on the pad and
11:55
give it 48 mm
11:58
now you are seeing here partition
12:01
line which means that uh it seems like
12:05
it is not merge but it is not like that
12:08
go to the last feature click on it and
12:12
drop down you will see here refine
12:15
false set it to the true now you can see
12:19
that it has been
12:21
merged now select the isometric view
12:24
select the face and click on the sketch
12:28
and here is
12:30
a R
12:34
31.8 so we will select the
12:37
circle create a circle in a dimension
12:42
select radius and give the
12:44
radius
12:47
31.8 click on close depth is
12:51
28.6 click on cut
12:58
28.6
13:01
now we will create the hole select the
13:05
face click on the
13:07
sketch and it is in a line of the this
13:11
axis which is passing through origin
13:13
this one so we will select the
13:16
circle create a circle and it is 19 mm
13:21
drill
13:23
select the
13:25
diameter and give the 19
13:27
mm and from center it is a 50 mm so
13:32
select this and this and add a vertical
13:35
dimension of 50 mm click on close click
13:40
on sketch click on
13:42
pocket drop down say through all say
13:45
okay
13:46
now select the back face and uh click on
13:51
the
13:52
sketch and project this
13:57
geometry click on the age to project it
14:02
now create a lines
14:05
line and uh give the dimension 50 select
14:10
the horizontal
14:12
dimension sorry dimension 75
14:17
75 and angle is
14:27
300 and now select the
14:31
line join
14:34
it and join
14:37
it now click on the sketch click on the
14:41
pocket and from here say through all say
14:44
okay
14:47
select the
14:49
isometric so this is how we have modeled
14:51
the holder block in Frecad so this is
14:54
all about this tutorial thank you for
14:56
watching and thank you for your valuable
14:58
time
