Hello everyone, welcome to automation
0:07
community. Today in this video we are
0:10
going to discuss an example in which we
0:13
will be drawing ladder diagram for a
0:15
boolean expression.
0:17
So let's look at the example first.
0:20
Example 16. Y2.
0:24
Example 16. Y is equal to A dot B dot C
0:30
plus T E not dot M.
0:35
So for this example we have six inputs A
0:39
B C D E and F. So for input A, C and E
0:44
we will be using normally closed
0:47
contacts. Okay. So A, B and C will be
0:50
connected in series. D, E and F will be
0:53
connected in series but D, E and F will
0:56
be connected in series with each other
0:59
but parallel to A, B and C. So for
1:04
output Y to be on we have two uh you
1:07
know options either A should be off, B
1:10
should be on, C should be off or D
1:12
should be on, E should be off and F
1:16
should be on. Okay. So let's move to
1:18
codices where we will draw a ladder
1:21
diagram for this exam.
1:24
I will open codices.
1:38
Let's create a new project. Click on new
1:40
project
1:41
and we need to write the name of the
1:44
project that is sample
1:50
16. Then we can also select the location
1:53
where this project will be saved. Okay.
1:56
And then we can also select its
1:58
template. Let's keep it standard project
2:01
and click on okay.
2:04
So the project has been created. We can
2:06
also select the device uh which we will
2:09
be using. We can select this from our
2:12
from this list. For now I will be using
2:14
cords control when v3 64 cords and then
2:19
the PLC programming there is a list of
2:21
different language. We are using ladder
2:24
logic diagram LD and click on okay.
2:29
So now let's click double click here TLC
2:32
programming. So here we will be drawing
2:35
ladder diagram for the boolean
2:36
expression. So we have a kn first that
2:40
means we have to use a normally closed
2:42
contact for a not. So this will be a
2:46
so this will be a and it represents a
2:49
not and then we we have b dot b dot b
2:54
means we have to connect b in series. So
2:56
we will connect we'll insert a normally
2:59
open contact as a normally uh sorry for
3:02
B that that represents dot B and then we
3:05
have dot C not dot means in series
3:10
C not means a normally closed contact
3:13
for C. Okay so this will be C. So when
3:18
uh we are using normally closed contacts
3:20
we are implementing not logic gates.
3:23
Okay. A not C not understood? A should
3:26
be off, C should be off and B should be
3:29
on. Then the output Y will turn on. So
3:33
we have inserted a coil here for the
3:35
output Y. Great. Click on okay. And
3:40
after that we have plus. Okay. Plus
3:43
means
3:44
so. So the inputs written after plus
3:49
means they have to be inserted here in
3:52
parallel to these A B C. Okay. So we
3:55
need to select all these inputs A by uh
3:59
pressing the shift button. Click on
4:01
every this contact and then insert
4:05
contact parallel. Okay. So great. So
4:08
this normally open contact will be for
4:11
D. Okay. So this is D. Then we have E
4:16
not okay dot D dot. Dot means in series
4:20
to D. Okay. Then we have E not. E not
4:23
means a normally closed contact for E.
4:26
And then we have dot. Dot means in
4:29
series. So we have to connect F. Okay.
4:32
So we'll insert a normally open contact
4:34
for F. Okay. So for output Y to be on, A
4:39
should be off, B should be on, and C
4:42
should be off. So if A is off, it is a
4:44
normally closed contact. The signal will
4:46
pass through this. B is on, it is a
4:49
normally open contact. In true state,
4:51
the signal will pass through this. And C
4:53
is off, C is a normally closed contact.
4:55
In a false state, the signal will pass
4:57
through this. As a result, this output Y
4:59
will be on. So here we are implementing
5:02
or logic gate. Okay. So we have a choice
5:05
either A, B and C are controlling Y or
5:08
D, E and F are controlling Y. So the
5:12
second choice is D should be on A should
5:14
be off. F should be on. If D is on the
5:17
signal passes through this E A is off.
5:20
So this is a normally closed contact. In
5:22
false state the signal will pass through
5:23
this. F is on. It is a normally open
5:26
contact. The signal will pass through
5:27
this. The output Y will turn on. So now
5:31
let's go to uh sorry let's generate code
5:34
first. here.
5:38
Go to online and start simulation.
5:42
After starting the simulation, we need
5:44
to log in here. Click on yes
5:48
and then we will click here to start the
5:51
simulation. So for now this output Y is
5:54
off, isn't it? This output Y is off. We
5:57
can also see it here. The output Y is
6:00
off. So to turn on we need to to turn on
6:04
the output Y we need to uh make output
6:07
sorry input B true. So let's debug it
6:10
and write values and you can see here
6:13
the output Y turn on. Okay so here you
6:16
can see A is false B is true and C is
6:20
false. So the the signal is passing
6:22
through these contact these three
6:24
contacts. As a result this output Y is
6:27
on. If I turn on A, I will click here,
6:30
make it true. Go to debug and write
6:32
values. So A is true but it is a
6:34
normally closed contact. In true state,
6:36
it will not allow signal to pass through
6:38
this. As a result, this output Y will be
6:42
on. Okay. So when A is true, no matter
6:44
what is the state of B and C, Y will not
6:47
turn on. Similarly, if A is false and C
6:51
is true, what will happen? The output Y
6:54
will not turn on. A is off, the signal
6:56
passes. B is on, the signal passes. But
6:59
C is on at a normally closed contact. It
7:01
will not allow it will never allow the
7:04
signal to pass through this. As a
7:06
result, this output Y will turn off.
7:08
Okay, great. So we will turn off A as
7:11
well. Sorry, we will turn off B and C as
7:15
well. So let's go to debug and write
7:17
values. And now instead of A, B and C,
7:20
we can also use D, E, and F. So when I
7:23
turn on D, when I turn on D, click here.
7:26
true. Go to debug and write values. When
7:29
I turn on D, output Y will not turn on.
7:32
So we need to uh turn on F as well and
7:37
keep E keep the input E false. Okay,
7:40
let's go to debug and write values. So
7:43
what will happen? The signal will flow
7:45
through this. E is off as a normally
7:47
closed contact. In false state, the
7:49
signal passes through this. F is also
7:51
true. It is a normally open contact. The
7:53
signal passes through this. As a result,
7:55
this output Y will turn on. Great. So if
7:59
I turn on E, if I turn on E, go to debug
8:02
and write values, you can see here the
8:04
signal will not pass through this
8:06
because this is a normally closed
8:07
contact. In true state, a normally
8:09
closed contact never allow signal to
8:11
flow through this. As a result, the
8:13
output Y will not turn on. So E should
8:16
be off. E should be off and D and F
8:20
should be on. Let's debug it and write
8:22
values. Boom. Output Y will turn turn
8:26
on. It was all about this example. Thank
8:29
you for watching.
