Learn how to create three unique and exciting transitions for your videos in Adobe Premiere Pro CC with this tutorial and walkthrough by Leighton Milne.
Explore all FilterGrade Video Editing Products here: https://filtergrade.com/product-category/video/
In this video, you'll learn how to create three exciting video transitions:
1. Object Wipe Transition
2. Fade/Sky Replace Transition
3. Zoom In Zoom Out Transition
Be sure to keep up with Leighton's projects: https://www.instagram.com/leighton_milne/
- - - - - - - - - - - - - - - - - - - -
Follow FilterGrade!
Facebook - https://www.facebook.com/filtergrade
Twitter - https://twitter.com/filtergrade
Pinterest - https://www.pinterest.com/filtergrade/
Instagram - https://www.instagram.com/filtergrade/
Show More Show Less View Video Transcript
0:00
hello and welcome to another filter
0:01
grade tutorial my name is Leighton in
0:02
this video we're learning how to create
0:04
some of those popular video transitions
0:05
seen on YouTube today I'm talking about
0:07
the object wipes the limit fades and the
0:09
zoomin zoom-out transitions you can
0:11
create these transitions with many
0:12
different techniques and many different
0:13
programs but this video today will
0:15
specifically take a look at how to do it
0:17
in Adobe Premiere Pro CC
0:21
now a lot of people find that these
0:23
transitions are overdone
0:25
especially in travel videos but fact of
0:27
the matter is that you need to be able
0:29
to use the transitions and understand
0:31
these techniques in order to establish
0:32
yourself and show that you are a
0:35
competent and knowledgeable Video Editor
0:37
producer so I hope that you understand
0:40
these techniques I'm about to show you
0:41
today taking the information and
0:43
hopefully create your own transitions
0:46
that everyone else would be wanting to
0:48
understand trying to figure out so
0:50
without further ado let's get into it
0:51
remember me or here I got a couple of
0:53
clips we're going to work with today the
0:55
first technique I want to go through is
0:56
the object wipe so this is when
0:58
something passes through the screen left
1:01
to right or right to left see this tree
1:02
here and covering the entire screen so
1:06
what you're going to do is separate one
1:08
side of the screen and you're going to
1:10
have the next clip and this tree here
1:11
going to act as like a barrier I'm going
1:14
to separate two clips cut it great at
1:17
the end
1:18
delete that and then I'm going to have
1:20
this one after so same location
1:23
different clips the first thing you want
1:25
to do here double click and get to your
1:27
effect controls on this clip here so
1:30
this technique we're gonna be using the
1:32
pen tool in order to create a mask turn
1:34
the whole left side of this tree here
1:36
black and in order for us to get rid of
1:38
it and put the next layer behind it so
1:41
let's get to the very first frame of
1:44
behind the tree here we'll start here
1:46
right there so you want to click this
1:48
pen tool here on the under early opacity
1:52
let's go ahead and click that it's going
1:54
to create its own mask here what you can
1:56
do is just click and create points you
1:58
want to follow the line of whatever your
2:00
object may be if it's a tree if it's a
2:01
sign if it's maybe a car passing by just
2:05
going to follow the line here so we'll
2:07
move over to here justice to bring it
2:11
all the way down and then reconnect it
2:12
to the beginning you can twist it a
2:14
little bit and we
2:15
around so as you can see this mass was
2:18
created this whole screen black which is
2:20
not what we want and want to hit the
2:22
invert button here and then just like
2:24
that you changed it up all right so
2:26
that's good enough you can also adjust
2:28
the feather here which makes a little
2:30
little softer it's not so harsh if you
2:33
made a bit of a mistake or your your
2:35
line that you're following isn't 100%
2:37
straight so from here we go to the next
2:39
frame just click this button right here
2:41
track select mask and move forward one
2:43
frame this is a very tedious process
2:46
where we're going to keep redoing what
2:48
we just true move this over with this up
2:52
a little bit so as you can see it's
2:54
gonna be a lot of this but just make
2:56
sure everything is black so how precise
2:59
you want to be all depends on how much
3:00
time you want to put into this if you
3:02
really want to take your time give me a
3:04
lot more accurate but for the purpose of
3:06
this video I'm just going to go through
3:07
pretty quick here and I'll fast forward
3:10
it for you so something I forgot to do
3:12
at the beginning was actually set a
3:13
starting keyframe that doesn't have the
3:15
mask in it as you can see it kind of
3:17
comes in early here all you got to do is
3:19
find the point where it just before it
3:21
comes in just click and just move the
3:24
whole math to the left so it's not in
3:25
the way that's the easiest way of
3:26
dealing with it as you can see starting
3:28
the beginning the clip we come through
3:29
and there's our mask it blocks off the
3:32
entire left side of the screen make sure
3:34
you save what you did because you wanted
3:35
to go through that again the next thing
3:37
you want to do is bring your Clips over
3:38
raise this one up and put whatever your
3:42
next clip is going to be under it so
3:45
when you play it out
3:47
the black just turns into the next clip
3:50
show that again here just like that
3:54
now this transition works better if it's
3:56
a quick moving a wipe past the object a
3:59
lot easier if your object is straight
4:02
and you can just draw a nice straight
4:03
line the entire time like I said before
4:05
if you want it to be more accurate I'll
4:07
take more time but put on some
4:09
headphones carve out a good half hour to
4:11
really fine-tune it and you're why
4:12
people look a whole lot better so there
4:14
you have it one more time nice and
4:15
smooth so that is the object wipe
4:17
technique the next one we're gonna be
4:18
looking at is the luma fade or the
4:20
gradient wipe or the highlight sky
4:23
replace whatever you want to call it so
4:25
the effect that I'm going to show you
4:26
here in premiere is using the gradient
4:28
wipe transition you take this into After
4:30
Effects and really fine-tune it just in
4:31
the exposure to make it exactly what you
4:33
want but this is definitely the most
4:34
simple technique that going to duplicate
4:36
the look you're going for I'm in the
4:38
effects workspace here you can change
4:39
that by going up to window workspace is
4:41
you just go down to effects it's a lot
4:44
easier with such when you're doing
4:45
transition work like this so all you
4:46
have to do is search gradient and you're
4:48
going to use the one under video effects
4:49
not the one under video transitions just
4:52
make sure you doing this one here all
4:54
you do is click and drag it onto the
4:55
clip I'm going to clip with some waves
4:57
here which is the classic luma fade clip
5:00
to use you're gonna want to lift this up
5:01
above your clip up to you how much you
5:04
want it to overlap this is probably good
5:07
enough for me
5:07
so it's a clip skateboarding on a bridge
5:09
and then it's going to turn into waves
5:11
we're going to be using keyframes here
5:13
so if you go over to your Flex controls
5:14
of your clip you can see here the
5:16
gradient wipe has been added but we just
5:18
need to add keyframes and just really
5:20
turn this thing on so let's go to the
5:22
very beginning of the clip here we're
5:25
going to click this little toggle
5:26
animation button which is going to set a
5:28
keyframe so click this keyframe and
5:30
we're going to put in 100 so I just
5:32
means that the entire clip is going to
5:33
start completely opaque meaning that
5:34
you're not gonna be able to see the
5:36
waves yet we're going to put another key
5:38
frame rate about there just when the
5:41
first clip ends so we're going to hit
5:42
this add remove keyframe button here
5:45
which is the same place where we hit the
5:46
stopwatch before click that and we're
5:49
going to hit zero in this box and that's
5:51
going to bring it out so that's pretty
5:53
much all you have to do it kind of does
5:56
it for you if you play it out this is
5:57
what it looks like
5:58
highlight start to show up first and
5:59
then slowly fade everything else in just
6:02
like that you can stretch it out make it
6:04
longer make it faster you can change how
6:06
soft ingredient wipe is just by going
6:08
here softness you can go up kind of
6:11
turns into more of a fade or blur I like
6:14
to keep it at zero or maybe even just
6:16
like 10 I don't know up to you it really
6:18
depends on what you're going for here
6:19
just like that nice easy fade and here
6:22
it comes
6:23
nice and easy put some music to that add
6:25
some audio effects then just like that I
6:28
want you to show you another technique
6:29
for doing the same kind of transition
6:31
here you're going to go back up to your
6:32
effects browser you want to type in
6:34
color key and this is what you're
6:36
looking for all you do is drag this drop
6:39
it onto the clip like before that you
6:41
want it to apply to so I've got a nice
6:43
clip of some birds and some sky here
6:45
this is a nice aerial view for this
6:48
technique when you're replacing the sky
6:50
you really want a nice bright sky or
6:53
whatever you want it to replace not to
6:55
be very bright contrast to the
6:57
foreground or whatever you want to stay
6:58
I think so you got some hills here a
7:00
little bit darker you want to go over to
7:02
color key here proves that we've added
7:03
the effect I'm going to use this
7:05
eyedropper tool what this does is lets
7:07
you click anywhere on the screen and
7:08
it's going to figure out what color you
7:10
want to change so I just clicked in the
7:12
sky it's all fairly the same color here
7:14
but in order to increase the radius we
7:16
can just grab this colored tolerance
7:18
move all the way up until you pretty
7:20
much replace the entire sky you can put
7:22
a bit of a feather on it so it's not so
7:24
sharp but again really up to you of how
7:26
precise and how perfect you want this
7:28
transition to be so this whole clip is
7:30
now the sky is turned black meaning that
7:32
if we raise it and put it over here the
7:35
sky from the clip below it is going to
7:37
show through just like the transition
7:38
before we're going to be using keyframes
7:39
in order to tell it when to start the
7:42
fade and finish the fade so probably the
7:44
easiest way is to either just to overlap
7:47
this clip however much you want it
7:49
however long you want the fade to go for
7:51
threes and keyframes to initiate the
7:53
fade nice and easy so it's a nice
7:55
seamless transition add some keyframes
7:57
by clicking this toggle animation
7:58
stopwatch thing here so click that click
8:02
that for the color tolerance as well as
8:04
the key color so the keyframe tells the
8:06
clip specifically how you want the
8:07
effect to be applied at a certain point
8:09
of time in the clip
8:10
I'm going to add keyframes here both to
8:13
key color and color tolerance so I click
8:16
on the keyframe color tolerance I'm
8:18
going to bring that all the way down to
8:19
zero as you can see when we go through
8:22
this there's a nice gradient fading
8:24
effect from the first keyframe set to
8:27
the next now if we go before where we
8:29
want our transition begin if we can see
8:30
there's a little bit of the effect added
8:32
to the sky we don't really want this to
8:34
happen quick an easy way of dealing with
8:35
this - just take your blade tool cut the
8:38
clip bring it down all you have to do is
8:40
just click the FX button is how the
8:41
color key effect for this clip and it's
8:44
all gone so you've got a nice clean
8:46
effect where the sky just disappears
8:48
slowly and then the rest of the clip
8:49
follows in extend us as much as you want
8:51
stretch it out and if you want to get
8:54
rid of the foreground same way you got
8:55
rid of the sky you can go back to this
8:57
technique here use the gradient wipe and
8:59
that will get rid of your foreground as
9:01
well so just these two techniques
9:03
together create the nice luma fade okay
9:06
so finally we're going to be taking a
9:07
look at how to do the zoom in transition
9:10
this is probably one the most popular
9:11
transitions I've been seeing in videos
9:13
recently there's so many ways you can do
9:15
it different techniques using After
9:17
Effects using Premiere but this way I'm
9:20
about to show you is what I think likely
9:22
to be the easiest and it's in Premiere
9:24
which is great if you don't have After
9:26
Effects so let's get into it we're going
9:28
to be changing from this wide shot of
9:31
the bridge it's going to zoom in to the
9:33
skateboarding shot which we use the for
9:35
we're using key framing techniques like
9:37
before so we're going to count to the
9:39
left of here it really depends on what
9:41
you want if you want a faster transition
9:43
only go in like 3 2 or 3 4 frames if you
9:46
want a longer zoom I would count in five
9:49
or six even up to 10 frames it really
9:51
depends on what the look you're going
9:52
for I'm going to go in four frames here
9:54
to see what it looks like so we're gonna
9:55
go one two three four and I'm going to
9:59
cut it right here with the blade tool so
10:02
I'm going to split clip there and the
10:03
same thing we're going to do on this
10:05
side too so we're going to count in one
10:06
two three four three oh we're going to
10:11
click this clip here it's going to bring
10:13
up the effects controls on the left if
10:15
that doesn't show up first if it looks
10:16
like
10:17
just go over here to effects control
10:20
bring it back up we're going to be
10:21
adding keyframes here using the scale
10:23
section so go ahead and hit a keyframe
10:26
at the beginning of this clip scroll all
10:28
the way through the end of this clip and
10:30
hit this button right here which is add
10:31
another keyframe so click that so we got
10:34
two here you first want to do anyone be
10:36
set at whatever it was set it before so
10:38
it's 100 leave it at 100 and then the
10:41
final one go on to the end of this clip
10:43
you can do 200 you can do 150 I depend
10:46
how aggressive you want to zoom in to be
10:48
I would recommend going 200 for the zoom
10:51
in part of it it's really initiate that
10:52
quick zoom in since this is a zoom our
10:55
next clip is also going to have to zoom
10:56
in so using the same key framing
10:58
techniques we're going to hit the scale
10:59
button on this next clip hit that and
11:02
add the keyframe right there as you can
11:04
see then go to the end of this clip that
11:06
you split up already click that you got
11:10
your two keyframes this one is one
11:12
you're going to leave at 100 just one of
11:13
the beginning here again this is up to
11:15
you you can go 50 on the scale you can
11:18
even go to 0 and have just a crazy out
11:20
of nowhere zoom but that's gonna be a
11:21
lot harder to deal with especially when
11:23
we're trying to replicate the edges add
11:25
mirror effect to the outside now as you
11:27
can see if we go through it already kind
11:30
of has the zoom look to it except we
11:32
have to deal with all these black
11:33
borders around this clip here alright so
11:36
you're going to go over here to the left
11:37
bottom panel find this little button
11:40
says new items click that and you're
11:42
going to want to hit adjustment layer
11:44
this is all the settings to whatever
11:47
your timeline already is so just let it
11:49
be and it's going to pop up right here
11:50
all you do is click drag it put at the
11:53
beginning and then cut it the end
11:58
so now you have an adjustment layer
11:59
that's just going to be specific to this
12:01
clip here so up in your effects browser
12:03
you want to type in mirror you know type
12:06
that in there if you already know where
12:07
the mirror effect is you can find it
12:10
either way grab it and drag it and drop
12:12
it on to this adjustment layer so when
12:15
you click on this open your effects
12:16
control it's going to pop up right here
12:18
sitting here now you're going to want to
12:20
add this four times you need to do all
12:22
for now or you can do one of the time
12:25
might as well do all for now so you
12:27
don't forget it as you can see right
12:28
here one two three four
12:31
so each mirror you need for each side of
12:33
the clip go to the beginning we're going
12:35
to work with the first mirror and you're
12:37
going to click so as soon as you click
12:39
the mirror button you're gonna have a
12:41
little circle crosshair up here just
12:43
drag that over until it appears drag it
12:46
over right to where the clip matches up
12:48
roughly it doesn't matter too much
12:50
because it's only gonna be four frames
12:51
it's going to be zooming its me really
12:53
quick so now that you've got that you're
12:55
going to hit this toggle animation
12:56
button on the left here we're going to
12:57
add a keyframe added right there and you
13:00
can also add the reflection angle by
13:02
clicking the keyframe there as we scroll
13:04
through it you can see the main clip
13:05
zooming in but our mirrored adjustments
13:09
still there so scroll through to the end
13:12
of your clip here just one frame before
13:14
and you can see if you go to the very
13:16
last frame it disappears and you can't
13:18
find that crosshair against go before
13:20
click on the cross here we're going to
13:22
move it over until it is right on the
13:24
edge so you can't see it anymore so you
13:27
just lose it right there and then all
13:29
you have to do is drag this keyframe
13:30
over you can't really see it anymore
13:33
which is perfect so for it to add a
13:35
keyframe just for good measure
13:37
at the end of the clip here just that
13:40
your reflection angle is locked and so
13:42
we got one side down during following
13:44
this technique for all other sides so
13:47
for the next mirror we're going to go
13:48
down here to reflection angle we're
13:50
going to type in 180 for 180 degrees the
13:54
whole screen return block all you do is
13:56
click this crosshair and we're going to
13:57
drag it across the screen and there we
14:00
have it you can see it link it up there
14:01
are the key frames in the beginning
14:03
reflection Center reflection angle all
14:05
locked in
14:07
we the same thing as before as you can
14:09
see our mirrored effect stays where it
14:12
is we'll do the same technique as before
14:13
where we add a keyframe and then move it
14:16
just over to the left or right for the
14:18
final frame if you put it just off the
14:21
screen then your keyframe is going to
14:23
match up perfectly with your clip
14:25
zooming in making for a seamless zoom
14:27
with mirrored outsides you don't even
14:29
notice add your reflection angle
14:31
keyframe just for good measure in case
14:33
you accidentally get confused and mess
14:36
around with other keyframe actions now
14:38
use this mirror effect on an adjustment
14:40
layer for each side in order to extend
14:42
your clip in all directions so that you
14:44
can start from a pulled up perspective
14:46
and zoom in without making it too
14:48
noticeable and the zoom itself will be
14:50
quick enough that very few people will
14:52
be able to pick out and depending on
14:53
your clip if it's more of a landscape
14:55
clip there will be two sets of legs that
14:58
people can pick out as easy it really
14:59
depends on the clip has for most
15:01
transitions go alright so we're going to
15:02
go to the next one here so now we've got
15:05
both the sides set let's take a look at
15:07
the top and bottom for the angle let's
15:10
type in ninety degrees that way we've
15:12
got a nice reflection going here again
15:15
you can click this little crosshair and
15:18
just drag it down to the point where it
15:21
links up perfectly nice so you can can't
15:24
really tell if there's a split line
15:26
there go ahead and add our keyframes
15:29
toggle animation and toggle animation so
15:33
the keyframes are both right here scroll
15:36
towards the end of the clip just one
15:39
frame before the last frame again click
15:44
the mirror
15:45
let's bring it down just out of frame
15:49
that's good and then we'll drag the
15:52
keyframe over to the last frame and then
15:56
the reflection angle keyframe you can
15:58
guide that over there if you want to so
16:00
for the very last slide we're going to
16:02
type in negative 90 on the reflection
16:03
angle enter there you go so let's click
16:08
the mirror button again here grab our
16:09
crosshair move it up links up perfectly
16:12
yes this looks kind of weird but when
16:15
you play it all through speeds up a
16:16
little bit a little bit of motion blur
16:18
it look normal it look nice and seamless
16:20
so it's at our key frames here selection
16:22
Center reflection angle play through go
16:27
to our second last frame click the
16:30
mirror against your crosshair pops up
16:31
bring it up it doesn't matter where
16:33
you're putting this left or right just
16:34
make sure you have the the y-axis the
16:36
north/south all set and figure it out
16:38
perfectly good just out of frame right
16:42
there is perfect drag this over to the
16:44
final frame at your reflection angle
16:47
keyframe drag that over to and there you
16:49
have it
16:50
it just kind of extends your clip and
16:51
lets you do the zoom effect if you play
16:54
through see it looks like it does look a
16:56
little bit weird just because of the
16:57
dark top and the extra pair of legs but
17:00
you can change this by adjusting how far
17:02
you zoom in if you have a two point
17:05
seven K you're in a 4k clip that you're
17:06
putting on the 1080p timeline it works a
17:09
lot better because you actually have
17:10
more of a clip to use but this is a
17:12
1080p timeline and this clip that we're
17:13
moving into is 1080p so we're gonna have
17:16
to use this newer technique so finally
17:18
just to make it a little bit more smooth
17:20
how to go up here into the effects
17:22
browser under video transitions under
17:26
dissolve it's just they're a little
17:28
cross dissolve in between these two
17:29
Clips here below not the adjustment
17:31
layer but just the clips themselves make
17:33
it a little smaller it just makes a nice
17:36
kind of a smooth even more subtle look
17:38
to it let's go back to the beginning of
17:40
the clip here let's play it up see how
17:41
it works in zoom so like I said it
17:44
really depends on your clip that you're
17:46
using to zoom in zoom out technique all
17:48
you have to do is the exact opposite of
17:49
what I just did so put the adjustment
17:52
layer on this first clip pretty much the
17:54
same thing as far as the mirror effect
17:55
goes
17:55
if your zoom is still not pleasing you
17:58
can always go in just the keyframes if
18:02
you want it to be faster you can adjust
18:05
this keyframe bring it in closer that
18:08
way it's a quicker transition you do the
18:10
same thing with this clip here the one
18:12
that you're zooming into if you like you
18:14
can also hit R on your keyboard and you
18:17
can make this clip faster also with this
18:19
clip as well same with the adjustment
18:21
layer just make sure the adjustment
18:22
layer follows whatever you're doing on
18:23
this layer here bring these two clips in
18:25
together and that's going to speed up
18:27
the entire thing which is a little bit
18:30
crazy but it's all creative decisions up
18:31
to you I would recommend taking some
18:33
time figure this process of
18:35
understanding keyframes maybe you can
18:37
figure out your own technique how to
18:38
zoom in zoom out maybe you can create
18:39
your own never-before-seen transition
18:41
before and put it out there for the
18:43
world to see and then everyone will be
18:44
making tutorials and how to do your
18:45
video transitions so once you've got all
18:47
your video transitions figure it out and
18:49
you got your timeline looking nice you
18:51
may find that your video is still
18:52
missing something what you want to do is
18:54
go to filter great calm for all the best
18:56
video let's this will make your footage
18:58
look a whole lot better it'll give your
19:00
video a very unique cinematic beautiful
19:03
look it really takes your footage to a
19:04
whole other level
19:05
I recommend any of these video let's
19:07
take some time look at them see what you
19:09
let pack works best for your video or
19:11
your style of shooting and as always for
19:13
all the best Photoshop actions Lightroom
19:15
presets and video let's check out
19:17
they'll do very calm
