Resource boundaries - Kubernetes Fundamentals Ep. 10
14K views
Nov 1, 2023
Join this live session with Rodrigo Díaz Concha on the next episode of Kubernetes Fundamentals on March 08, Wednesday at 7:30 AM Pacific Time (US). After attending this session, you will learn about Services. ABOUT SPEAKER Rodrigo Díaz Concha is a Solutions Architect, Microsoft Regional Director, and Microsoft MVP with more than 22 years of experience. In addition, he is a book author, speaker, and course author for LinkedIn Learning. Rodrigo has dozens of professional certifications from different companies such as Carnegie Mellon SEI Software Architecture Professional, Microsoft Certified: Azure Solutions Architect Expert, Microsoft Certified: DevOps Engineer Expert, and HashiCorp certifications. He also has the distinction of having written the first books on Silverlight 5 and Xamarin.Forms in the Spanish language. C# Corner - Community of Software and Data Developers https://www.c-sharpcorner.com #CSharpCorner #CSharpTV #Kubernetes
View Video Transcript
0:07
Hello, friends, and welcome to these other friends and welcome to these other
0:37
session of the Kubernetes Fundamental series only in C-sharp Corner. I'm Rodrigo
0:45
And today I'm going to talk about resource boundaries, which is necessary when you're
0:53
trying to implement Kubernetes because your containers are going to require a lot of CPU
1:03
and memory and resources, right? So there must be a way for us to limit the resources that those containers are going to use
1:17
So that will be the topic for today, okay? Resource management. So, and this is important because we should strive for high compute density
1:29
It's not that we're going to use Kubernetes for running 10 containers
1:35
or five containers, right? It doesn't make sense to run just a small amount of containers
1:44
We want to take advantage of those Kubernetes clusters like all the time, right
1:53
So this will increase the cost-benefit of money spent on infrastructure because, as you might know, having a Kubernetes cluster is not going to be cheap, right
2:05
Of course, there are some Kubernetes managed Kubernetes options in the cloud, such as AKS or whatnot
2:15
However, it's not that you're going to spend too little money to not take advantage of that, right
2:24
So resource boundaries, we can set those at the container level. that's the first demo that I want to show you today
2:37
that is inside the container specification, we can set the limits that the container should use
2:48
So this can be specified on the specification. I mean, in the Jamo file, you know, the manifest file
2:56
we are going to create one of those files. and there you can set the resource limits
3:04
In other words, you can save the minimum amount of resources that that particular container should use
3:13
And on the other hand, we can set the container limits. So in one hand, we have the resource limits
3:23
I mean, I'm sorry, the resource requests, and on the other hand, we have the resource limits
3:29
Resource request is the minimum amount of resources and resource limits is the maximum amount
3:35
Okay. And on the other hand, we have resource quotas. There are objects that we can create and apply to the Kubernetes cluster to limit the amount of resources that can be consumed by a set of pots in a single name space
3:51
Because remember, this namespace is like a logical group of objects inside the cluster
3:58
So we can set those limits at the namespace level, right? So it makes sense if you think about it because you can use namespaces for, I don't know
4:09
maybe you're using this namespace for this application and this other namespace for this other
4:14
application, right? Or maybe you're using a namespace for one of your clients and other namespace for other clients
4:24
So you want to set those limits. and those boundaries at the namespace level. Okay
4:33
When I'm talking about resource types, I'm talking about CPU most of the time, right
4:40
This is going to be CPU or memory or storage. Okay, in this session I'm going to focus on CPU and memory
4:51
But of course, you can set some boundaries around storage as well
4:56
We're not going to see that in this particular. session. And there are other less common resource types, such as network bandwidth and
5:05
GPU resources as well. However, I'm going to focus on CPU and memory. As I was mentioning
5:14
before, we can use the manifest file specifically inside the container's element to set the
5:22
minimum and the maximum resource boundaries, you know, the resources that your containers are going to use
5:31
So let's first talk about resource requests. This is the minimum amount, okay
5:38
We can use the containers element, and inside the container's element, we can use the resources element, and particularly the request's element
5:48
to specify that amount of resources that you want to use. Okay
5:53
Those values are going to be used by the scheduler. When that particular component, remember the scheduler
6:03
That's one of the control playing elements in a Kubernetes cluster. The scheduler is going to use that information to decide which note to place the bottom
6:15
Okay. So that's important because you can have, I don't know, a number of notes in a cluster in some notes
6:23
are going to be heavily used and some others want, right? So the scheduler is so intelligent and smart, and it's going to decide
6:34
I want to deploy this particular application, I want to deploy this particular pod
6:40
in this note, right? Note A or node B or node C, okay
6:47
So how in the world we're going to use that? So remember, this is at the manifest level
6:55
Of course, I'm showing you this pod, the specification. However, we can use this in a deployment as well, right
7:03
Because the deployment object has a pod specification inside it. So inside the container element, as I was mentioning before
7:15
we have the resources element. And inside the resources element, we have the requests
7:22
element, okay? That's the field that we're going to use, and inside that field we can set
7:28
memory, CPU, and whatnot. In this case, this example that I'm showing you right now, it's using
7:37
500 millicours, which, in other words, is half of a CPU, okay? So actually, that's a lot of compute
7:47
resources for this particular container. But of course, this is just only a demo, right
7:54
So please be aware of those measurement units. In this case, I'm using the M, which represents the
8:04
millicours And it depends on what resource we talking about right So if we talking about CPU we going to use millicores And if we talking about RAM I mean memory right
8:22
So those other units are different. So you better take care about that and see the documentation first before you do that
8:34
So okay, so this is great. This is for specifying your minimum amount
8:41
of resources and what about limits? This is the maximum amount of resources that a container can consume
8:51
Very similar to the requests. This is other field inside the resources element inside the containers of the pot
9:02
So in this other case, we also have containers and then resources as well and then limits
9:09
right? So we use the resources dot limits field and you can use CPU and memory and whatnot
9:18
In this other example, as we can see here on the screen, I'm using 1,000 mili cores, which, in other words, is one CPU
9:29
So I'm telling Kubernetes, hey, you know what, this particular container can use the entire CPU, which is a lot, right
9:37
But again, this is just a small example of setting your resource boundaries
9:43
Okay, 100, I'm sorry, 1,000 millicours is one CPU, okay? So let's do that, okay
9:53
Let's go to this terminal. So I'm not using my regular machine
10:03
I'm in my laptop because I'm abroad. Anyways, I'm going to create a new deployment or a new pod and I'm going to set some limits. Okay
10:17
So let's open up Visual Studio code. Actually, I did that beforehand
10:27
So you can see this to expedite this process. Okay. So you know what
10:35
Let me cope with this. because I don't want to show you the stress right now
10:42
Let me do another my pod file. So my pod dash first, okay
10:52
Anyways, forget about this right now and GnX and we're going to use this
10:57
And then I'm going to show you the stress container image. So in this particular case, as you can see here
11:06
here on the screen, I'm setting those limits for this particular container
11:12
I'm telling Kubernetes, hey, you know, this particular container can only use a quarter of a CPU, right
11:21
25% of the CPU this is allowed to use. And in terms of memory, as you can see here on the screen, I'm setting 64 megabytes of limits, right
11:36
So the MI, that's the unit for megabytes, that's why I told you you have to take a look at the documentation
11:46
because it's not a regular MB. This is MI. Okay. So other than that, this is just the regular manifest file for a pod
11:58
Let's open up the terminal and let's verify that I don't have any pots
12:05
which I do. Hold on because I was doing some other things in here
12:13
I could call delete, deploy, man, my app, okay? Forget about this, get pods
12:23
Those boats are being terminated right now. Which is actually what I want to do
12:31
Let's wait for some... Oh, let's wait a little bit. Come on, come on, come on
12:43
Anyways, I want to show you this appointment that I'm going to deploy again
12:48
which is using the stress container image because I want to show you what happens
12:55
when you have those limits, right? Anyways, my first demo is just using this pod element
13:04
Okay, so it was deleted. This is great. Now I'm ready to apply this file, which is my pod dash first, right
13:18
And then Cuddle get pods and, you know, the drill. This is creating the pod
13:24
It's trying to download the image if it's not already present. And it's running, right
13:33
So let me tell you one thing about this. I'm using Minicube as usual, right
13:40
MiniCube status because this is just a small laptop, okay? And I don't know what's, you don't have the required permission to complete this task
13:52
Anyways, I don't want to use MiniCube status. I want to show you other commands
13:57
Anyways, my point here is that I'm using Minicube and I'm using the
14:03
hyperbe driver. And when you install Minicube, you don't have a lot of different add-ons
14:14
in your Kubernetes installation, okay, in your Kubernetes deployment. So for instance, I'm telling you this
14:21
because I want to show you this command, CubeCuttle Top, which is a command
14:27
just like the regular H-Stop or top command in the Linux world
14:33
that allows you to see how many resources, processes are using, right
14:39
So in this case, I can show you top and then pod
14:44
to see that this particular pod is using how much memory, how much CPU cores, right
14:54
So the thing here is that the top command requires the metric server enabled in your
15:03
Minicube installation. So you can actually do that by executing Minicube and then add-ons
15:10
And you can see all the different add-ons that you can install and enable in your own
15:16
mini-cube installation. And actually, the one that is required is metric server
15:22
Okay. As you can see, I already enabled the metric server for this particular mini-cube installation. Okay
15:29
So you must do that if you want to execute cubecuttle top
15:35
Okay. So you should execute Minicube add-ons and then I think that's enabled and then the name of the add-on, which is Metric Server
15:46
I could be wrong in this syntax. You can search for the online help about Minicube
15:54
But the gist of this particular topic is that you must enable metric server
15:59
in order to execute Cube Cuddle Top, okay? You should do that
16:04
Anyways, Cube Cuddle Top, this is great. I want to show you this
16:11
And actually, that NGNX container, it has a very small footprint of memory and CPU
16:20
It's not very exciting to be running NGNX in a single pod
16:26
Okay And actually you can execute top node to see the node resources how are they being used Okay
16:39
Anyways, this is great. Let me keep cuddle delete pod, my app
16:47
So I want to delete this particular isolated pod. So get pots, no pots at all
16:55
And then I want to show you this other manifest file, which is a deployment
17:03
Okay, remember deployments? We actually don't deploy isolated pods. That's for sure most of the time
17:14
We want to deploy pods by means of a deployment, right? So this is our deployment, a regular deployment, is using this much
17:25
labels element to specify that the labels of the pods should be my app. They must be app and the value
17:37
should be my app. Okay. And here in the spec, I'm specifying another container image
17:47
This particular stress container image allows me to execute some stressful commands, right, for, you know, increasing memory utilization or CPU utilization, right
18:04
So I'm executing this command and it's stressing and stressing and stressing this application
18:13
all the time in terms of memory, in this case. And as you can see here, I'm specifying some limits
18:22
Okay. Let me show you first what happens if I'm setting up this limit, which is 25% of a CPU with 64 megabytes of memory, and I'm specifying five replicas
18:39
Okay. Let me show you this, friends. Um, CubeCoddle apply and then dash if my deployment.com. And this is going to be creating right now
18:52
Those pods, right? Running, running, running. Running, running. And pending what's going on here
19:03
Four pods are running and one is pending. Why in the world is that
19:09
So the thing is that I execute top and then pod. You can see that those four pods
19:18
those are using 25% of the CPU. there are no other resources left for me to deploy the fifth pot
19:31
Make sense? And this is because the limits that I set up in that particular manifest file, right
19:39
So in other words, Kubernetes is not allowed and it's not able to deploy the fifth pod
19:49
because the first four, those four are using the 100% of the CPU, right
19:59
So that's the reason why the fifth path is not running. So Kup Kuddle, get deployments, okay
20:12
Kup Kuddle, delete deployments, my app, and let's wait for this to delete
20:19
those pots. Let me go back here and those pots are being terminated. Anyways, I don't want to
20:28
wait for that and I just want to change the CPU limits for those containers. So each container
20:39
is able to use the maximum amount of CPU is going to be 20%, right? So I'm allowed to run five
20:49
containers of the same kind because of those limits. So I changed this. Let's go back here to the
20:57
terminal and now I'm ready to deploy again that deployment. Okay. Let's get all the pods again
21:09
Those boats are being created right now. We are running and now the five of them are running
21:19
right. And if I execute a pod, let's wait for the metrics to be fetched by the top command
21:31
because as you can see, the metrics are not available yet. So you have to wait for a little bit
21:36
I don't know, maybe half a minute or one minute or something. Let's try again
21:43
And eventually, I'm going to get those metrics and we're going to see that each container
21:49
I mean, each pod is using 20% of the CPU. Right
21:59
So, yeah, eventually this is going to receive those metrics. However, metrics are not available yet, which is nice
22:09
I mean, we're just going to see those pots running. Anyways, I'm going to return to this in a couple of minutes, okay
22:17
So that's great. This is for the container level, friends. Most of the time, this is a real-world situation
22:28
where you want to limit those containers that potentially are going to be running
22:34
on your Kubernetes cluster, right? On the other hand, we have those resource
22:42
quotas objects that we can create. as I mentioned before, resource quotas
22:49
they allow me to specify the maximum amount of resources per namespace
22:55
Of course, I only have the default namespace right now. Maybe I'm going to create a new namespace and then a resource quota for that particular namespace
23:07
However, remember that those objects, they allowed you to specify the maximum amount of
23:13
resources per namespace, okay? And you can also use resource quotas to limit the quantity of objects that you can create
23:24
This is awesome because you can specify, hey, you know, in this particular namespace, I want
23:31
to limit for, I don't know, maybe 100 pods or maybe five services, three deployments
23:41
and whatnot, okay? those kind of objects. Remember the primitive objects that we talked about like, I don't know, maybe one month ago
23:51
And actually, you can limit a lot of different objects, not only the primitive objects that we talked about here in this series
24:01
but other objects as well. Okay? So let's go back here to the terminal
24:09
Let's clear up the screen. Cube called Toppot and now I'm receiving those metrics from the pods and as you can see
24:19
those pods are using 25, I'm sorry, yes, 20%, no 25, 20% of CPU each one, right
24:31
So this is nice. Limits are great and the stress container image is allowing me to, you know
24:41
stress those applications, those pods, so we can see that in the Q top command Awesome So returning to the resource quota objects as you can see here on the screen this is another
24:57
kind of object that we can create. So in this case, this is a manifest file for our resource quota, as you can see here
25:07
this is the resource quota object. Okay, the API version is V1
25:12
The kind is resource quota. And of course, we can set that metadata because most of the time we need the name
25:22
In this case, is my resource quota, my RQ, right? And then we have the spec field that has hard and then the different resources and objects that you want to limit
25:38
You're specifying the quota in this particular field. Okay. So, for instance, CPU and memory, those two are for computing resources, right
25:51
Two CPU cores and maybe, I don't know, for gigabytes of RAM
25:57
That's the quota for this particular namespace. Of course, you're not specifying the namespace here
26:06
However, when you apply the resource quota object, you have to specify the namespace
26:11
I'm going to show you that. Okay? In parts 10, this is an object count quota, which is, again, this is awesome
26:20
We have a lot of flexibility in terms of this quota specification
26:27
So this is great. And then you need to deploy that particular manifest
26:33
Again, Kube Kodolapi, just a regular, Kube Kodolapi, file, my quota, dot, terminal, or the name of the file
26:43
right and that particular command is going to deploy the resource quota in the current namespace
26:53
if you want to deploy that quota in another name space you have to use the flag dash n or double
27:02
dash namespace and the name of the namespace where you want to deploy this particular resource quota okay
27:09
And again, Cube Cuddle get quota. This is for returning and displaying all the different quotas
27:17
As you can see here, the alias is quota, right? You can use actually, I think, resource quota, the entire name as well
27:28
However, quota is just an alias. And the final one, it gets all the detailed information about a particular resource quota
27:39
It's just a regular Kip Kuddle described, right? Actually, you know what
27:45
This is a typo because it should be lowercase. This is great
27:53
Thank you. Okay, so cool. Let's do this
28:03
Let me copy this because I don't have a template for creating
28:09
quotas and I don't want to type everything right my resource quota Jamal let's type this kind
28:19
resource quota my research quota two CPUs and four gigs of memory and tempots and whatnot
28:28
very easy thing to grasp in here kill color apply right um and then my research quota quota
28:39
And then the namespace. Of course, I need to create another namespace
28:45
CoupCardle create namespace and I don't know, maybe test. And now we have that test namespace, right
28:53
And now I'm able to CubeCodel apply dash F, my resource quota dot demo, and the namespace is test, right
29:06
So now that particular quota was deployed in the test, namespace. So I can actually describe quota, my resource quota, which is in the namespace test
29:24
and we can see that that heart limit at the right of the screen
29:32
I mean, the last column is the hard limits that I set in the management
29:36
FIS file and in the middle we can see the used number of objects or the limits of those compute resources, right
29:50
In this case, because of the fact that I don't have any kind of object inside that namespace, of course, those values are zero
29:57
However, I think I can use my deployment again, right? My deployment.comal, my deployment.comal, namespace, test
30:18
Okay? And now, CubeCuttle, describe, blah, blah, blah. And we can see that at this moment, I'm using one of those CPUs
30:32
and I'm using half of the parts that I specified in the quota, right
30:40
And I'm only using 320 megabytes of those four gigabytes. Anyways, you can easily see that with this kind of resource objects, I mean, resource quota objects, you can set those limits at the namespace level, which is great
31:01
Okay? So, I believe this is all I have for today. Okay
31:14
Just as an overview, you can set those limits at the container level by using limits inside the pod specification
31:26
You can also set those resource requests for specifying the minimum amount of resources that your applications need
31:35
and that's for the container level, right? And on the other hand, you have those resource code objects that you can create
31:45
and you can apply those at the namespace level. Okay? So, this is great
31:59
And I only have one screen right now, friends, because I'm abroad
32:05
I don't have my entire, my three monitors, right? So this is all I have for today, so I'm not watching the comments and questions
32:20
However, in the next session, session number 11, we're going to see the multi-container pots, right
32:30
I'm going to talk about how you can create pods with multiple containers, because most of the time, if you need that, is because one of those containers need the other one for its own logic and functionality
32:49
So we're going to see how in the world we can create that in Kubernetes
32:54
Okay? So that's everything for today. I thank you very much for your time
33:00
and I'll see you next time
#Distributed & Cloud Computing
#Enterprise Technology
#Networking
#Programming
#Software
