CTT Batch Counting - Multi-mode (Timer Counter Tachometer) - Counter Modes

We will now look at batch counting on our CTT - Counter Timer Tachometer multi-mode unit. The CTT series from Automation Direct are multi-function digital units. They incorporate a multi-function digital counter, timer and tachometer all within the same unit. The counter mode will operate in five (5) different ways. Up to five different count input modes can be selected. Up, Down, UP/Command Counting Down (UdA), UP/Counting Down (UdC) and Quadrature (UdC) can be selected. We also have a number of output modes to select so this unit can adapt to a great number of applications. We will be looking at each of the Counter modes using the Up count input on this versatile digital unit. 1-Stage, 2-Stage, Batch, Total and Dual are the modes. Let’s get started. https://accautomation.ca/series/ctt-multi-functional-digital-counter-timer-and-tachometer/ More information can be obtained at our website. This includes all of the links mentioned in this video. http://accautomation.ca/ctt-counter-timer-tachometer-counter-modes Stage 1 Counting https://youtu.be/1yrwF8uaB4s Stage 2 Counting https://youtu.be/s6yCUptKDCs Batch Counting https://youtu.be/GL6tJob3z9Q Total Counting https://youtu.be/XRXFRY283Rg Dual Counting https://youtu.be/AuTxaL0dhLc Previously in this CTT Counter Timer Tachometer Series we looked at the following:
