This video shows you how to use Github project edgetunnel to create your own proxy tunnel site with free cloudflare edge computing page.
Related Post:
✍https://blog.51sec.org/2024/11/create-your-own-proxy-node-site-bpb.html
Related Videos:
🌟Get Free Subdomain DNS from EU.ORG & Integrate with Cloudflare - https://youtu.be/V1xnhqqg4Rw
🌟Use Cloudflare Snippets to Create Free Forever V2Ray Vless Proxy Site (Fast& Permanent) - https://youtu.be/8log07W45lc
🌟Create Your Own V2Ray Vless VPN Site Through Cloudflare Worker Without Getting an Error 1101 - https://youtu.be/c7H-1H6ZiJ0
🌟Use Cloudflare Worker To Generate V2ray Vless Nodes for V2rayN VPN To Bypass Internet Censorship - https://youtu.be/OOwRoP_SWzk
💖Chapters:
0:00 - Introduction
2:06 - Lets start it
4:02 - 1. Rapid Deployment
6:44 - 2. Bind Project to Cloudflare Namespace
10:03 3. Use Your Own Custom Domain for This Project
12:35 4. v2rayN Connect to This New Proxy Site
15:36 End Scene
✅#51Sec #NetSec #Cyber #Security #CyberSecurity #HomeLab
🔰https://github.com/cmliu/edgetunnel
If you found this video has some useful information, please give me a thumb up and subscribe this channel to get more updates:
⚡https://www.youtube.com/c/Netsec?sub_confirmation=1
⚡Resource Collection and Bookmarks: https://sites.51sec.org/
Learning and Sharing - 🔊海内存知己,天涯若比邻! A bosom friend afar brings a distant land near!
Discord: https://discord.gg/fCW9phn, Blog: https://blog.51sec.org
Show More Show Less View Video Transcript
0:05
Hello everyone. Welcome back to my
0:07
channel NexSec.
0:09
Previously, I had a few videos to talk
0:12
about how to build your own VPN proxy
0:17
site using online free services such a
0:20
Cloudflare worker pages snippet or some
0:24
like collab rapidly or some free V2Ray
0:27
VLESS proxy site to build it so you can
0:30
find from those videos I created before.
0:34
Today, I'm going to show you some other
0:37
which I found very amazing project
0:40
Edge Tunnel. So, this has 41k
0:44
stars. Very popular now.
0:47
Uh it's version 2.1.
0:49
Previously, I already did show you some
0:52
other similar project which like this
0:55
one Cloudflare VLESS Trojan
0:58
15k
1:00
and the worker panel BPP worker panel
1:03
13k.
1:04
This one is also Edge Tunnel from
1:09
z-z-zfn.
1:11
It's a 9k. So, just to mention that.
1:15
The one I'm going to talk about Edge
1:17
Tunnel 2.1
1:19
from CM Liu which is also using this
1:25
Edge Tunnel from z-z-zfn.
1:27
Basically
1:29
the new one CM Liu's Edge Tunnel 2.1 is
1:32
built up from this version as well. So,
1:35
there's others V2Ray worker and also CF
1:39
snippet proxy.
1:41
All those I have been testing it. I put
1:44
in two my blogs. You can find it from
1:47
the video description. Also, I made
1:49
quite a few videos here.
1:51
Um in this video, I'm going to talk
1:54
about this one. I'm going to build this
1:56
one and show you how to step-by-step
1:59
to create one for yourself, which is
2:01
very powerful and a very easy to set up.
2:05
Now, let's jump into it.
2:11
If you watched my previous videos, you
2:13
must know how V2 Ray
2:17
this protocol working. If you haven't,
2:19
then you can watch
2:21
my previous videos and also read this
2:23
blog post to show you some concept. The
2:26
main purpose is build your own proxy
2:31
site or you can call it VPN tunnel site.
2:35
Then you can create a subscription and
2:37
use V2 Ray and this kind of client to
2:42
connect to your proxy site. Then
2:45
you can bypassing all those internet
2:49
censorship, which is very popular in
2:52
certain region.
2:54
I'm going to show you how to rapid
2:57
deployment using the way
3:00
like recommended like they
3:02
recommended using CF pages to do that.
3:06
So, I'm going to show you how you can do
3:09
it. Basically, you need to have two
3:11
things. You need to have a Cloudflare
3:14
account, which is free as long as you
3:17
have a email address, you can get one.
3:19
I already have my own. I created before.
3:22
You might also need your own domain.
3:25
eu.org can provide free domain since
3:29
1996.
3:31
I already got mine long time ago, which
3:34
is working beautiful still
3:37
working very stable and I don't have any
3:39
concerning on that. Strongly recommended
3:42
to watch my those videos and then you
3:45
will find how to get your own eu.org
3:49
domain and how to
3:51
add it into Cloudflare to use it.
3:56
Now,
3:57
let's follow the guide and complete this
4:00
deployment.
4:06
Well, here are the steps you need to
4:09
download the main the zip file.
4:13
It will automatically download. It's
4:14
very small file, 300 K bytes.
4:22
Then we come back to our Cloudflare,
4:25
assuming
4:27
you already have account. Now, we need
4:29
to create application.
4:31
We're going to create in a page site,
4:33
deploy to page. Get started with page.
4:37
You can import existing Git repository.
4:41
A Git project does provide you a way to
4:44
do that, but the let's using a
4:47
traditional way uploading
4:50
the download the file
4:52
and put in here. So, let's give a name.
4:55
We call it Edge Tunnel.
5:02
Create project.
5:05
So, we give a project name here.
5:08
Then we need to drag
5:11
the file you downloaded to put in here.
5:21
So, there are nine files uploaded, which
5:24
are inside of this zip file.
5:27
So, let's do deploy site.
5:31
Success. Your project is deployed to
5:33
region Earth.
5:35
That is funny.
5:37
Let's go to next step.
5:39
We go to settings.
5:43
Variables.
5:50
>> admin.
5:53
Going to set the password. This is your
5:55
admin password.
5:57
For testing, I'm going to use in this
5:59
popular password.
6:01
And save.
6:04
You also can create a
6:07
secret. So, in that way, you don't have
6:10
to show your value here. But, for demo
6:13
purpose, I'm going to use plain text
6:15
type
6:16
to type in here.
6:19
Go back to deployment.
6:22
Create deployment.
6:28
Save and deploy.
6:33
Continue the project. There's still one
6:35
more thing to do here. You need to bind
6:39
the KV namespace. So, we will do it in
6:42
next section.
6:49
Our first step, we create our project,
6:52
we deployed it, but we don't need
6:54
namespace.
6:56
So, we going to create that. If you go
6:58
to your storage and databases menu here,
7:03
there's a workers KV.
7:07
So, workers KV, I had one before. So,
7:10
now let's create my own one. We call it
7:15
So, we know this is for external
7:17
project.
7:19
So, that's it. We're going to go back to
7:21
our
7:23
workers and the pages.
7:25
We're going to show our pages. That's
7:27
the way we created.
7:29
We go to settings.
7:31
Go to bindings.
7:33
Add the bindings. So, then you need to
7:36
scroll down to get the KV namespace.
7:39
Variable name, we put the KV uh select
7:42
guide. It shows us KV name space. You
7:46
should be able to find the list new
7:47
created name space.
7:50
If you didn't find it, you might need to
7:52
log off your account, log it back in
7:54
again. The cache in the back end might
7:57
cause an issue here. You might need to
7:59
wait a bit. So, save for it.
8:03
Perfect. So, now you have bind your
8:07
project with your name space.
8:10
Now, we can go back to our project here
8:12
again. Now, you should be able to access
8:15
it.
8:16
It says
8:22
unbound KV name space variable name to
8:25
the KV name space.
8:29
This way
8:31
we do need to now we need to deploy it
8:33
again. So, let's create deployment.
8:40
Save
8:41
and deploy.
8:44
Perfect.
8:52
Now, you can enter your admin page. So,
8:57
we put the password 1 2 3 4
9:00
here. So, we should be able to log in.
9:04
Thanks.
9:05
So, that's the page here we can have.
9:09
So, I translate to the English. Now, you
9:12
got those node link.
9:14
If you want to do more configuration,
9:16
you can click on this and expert.
9:21
So, then you can get the much more
9:23
configuration settings here.
9:26
For you to use, it's really easy. You
9:28
just need to get those node link and
9:32
then import it into your V2Ray and the
9:37
client and connect to it. I will
9:39
demonstrate later on.
9:41
There's one more thing you need to do in
9:43
next section. I will show you how to
9:46
bind your own domain. So, that's why we
9:49
need to have your own domain so we can
9:51
use our own domain to access to it not
9:54
using the pages.dev
9:57
to access to it. But if you don't have
9:59
your own domain,
10:01
you still can using that.
10:08
Well, we can go back to your project
10:10
deployment page. You will find there's a
10:14
custom domains page here.
10:17
Yes, that's the place we can set up your
10:20
own custom domain. But the first thing
10:22
you need to have your own domain first.
10:26
If you don't have it, go to eu.org or
10:28
watch this video to get one.
10:34
Okay, we can add our custom domain. So,
10:36
I'm going to using
10:38
htunnel.51sec1.eu.org.
10:43
Continue.
10:46
So, they're going to create
10:48
CNAME for that. So, basically CNAME
10:51
htunnel going to map to this
10:54
domain.
10:56
So, it shows initializing. Not ready
10:59
yet.
11:01
So, it says it's verifying right now.
11:04
Check the NS record.
11:08
Well, we're going to do it by ourselves.
11:12
htunnel
11:15
So, we're going to go to our domains
11:18
overview.
11:20
I do have 51sec1.eu.org.
11:25
So, I have DNS record.
11:28
I'm going to
11:33
Yeah, it's already here.
11:35
And we go back to
11:40
our compute
11:42
workers and pages, edge tunnel.
11:47
The pages.dev works.
11:50
So, we can now see this one. It's also
11:53
works. It's just take a couple minutes
11:56
to get it working. So, we can do admin.
12:00
Then we need to log in.
12:05
So, the password
12:08
1 2 3 4
12:12
No, thanks.
12:14
This notification we can now change it
12:16
to English.
12:17
Basically the same. This domain is not
12:19
configured as a
12:21
node
12:23
must creating domain.
12:26
But to be what? Not required to do that.
12:29
So, that's basic setup.
12:32
We are going to use V2 Ray to do
12:33
connection.
12:39
Now we have our edge tunnel project set
12:42
up in Cloudflare.
12:45
We will need to copy this
12:48
link and then put it into our
12:52
V2 Ray. And um this is the client. I'm
12:57
running in the admin mode, so we can
13:00
copy paste in. If you don't have V2 Ray
13:03
and and you don't know how to use it,
13:05
you can watch my previous video and the
13:08
blog post for it. But the basically it
13:10
is a client connection to build the
13:14
tunnel between your machine and
13:16
Cloudflare project edge tunnel.
13:20
So, we are going to
13:21
replicate node.
13:24
We can now paste it in. You can do
13:25
control V or you can just paste it in
13:29
here.
13:32
Right away, you can see it's been copied
13:35
in. Um there's some settings we don't
13:38
need to go through it.
13:40
Um you can right click on it, you can
13:43
test
13:45
configuration with TCP ping with real
13:50
delay.
13:52
So, you will see those. Once you're
13:54
done, um you going to see your IP. So,
13:57
right now we didn't enable it. That's my
13:59
IP here. I'm using 65.95.158.49.
14:05
So, you can see my ISP.
14:09
So, we going to enable V2Ray. Basically,
14:12
we going to set
14:14
system proxy up. So,
14:17
that means the browser going to using
14:20
this system proxy. This is V2Ray and
14:23
proxy go to internet and it's through a
14:25
tunnel.
14:27
And it go to Cloudflare edge network and
14:30
then it get out of from there to go to
14:32
the internet.
14:34
So, the IP address here should be
14:37
able to be changed. Right away, you can
14:39
see it's changed.
14:41
ISP is Cloudflare incorporation. IP has
14:45
been changed. So, in this way, you kind
14:47
of like hiding your IP real IP behind
14:51
your home network and then nobody going
14:54
to lock your IP real IP when you
14:57
visiting internet.
15:00
You're also using this way because it's
15:03
encryption your all your traffic
15:05
encrypted well. So, in this way, you can
15:09
bypassing certain firewall configuration
15:12
limitation and restriction for your
15:15
region
15:17
if you have that. So, that's pretty much
15:19
everything I want to show you guys here.
15:22
I hope you enjoyed it. If you do see any
15:25
issue,
15:27
please let me know. If you like this
15:29
video, please give me a thumb up, and
15:31
also subscribe my channel if you
15:33
haven't.
15:34
I will see you in my next one.
15:37
>> [music]
15:53
[music]
#Science
