Devolutions PAM Configuration for JIT Provisioning and JIT Elevation (Lab Series #4)

Name: Devolutions PAM Configuration for JIT Provisioning and JIT Elevation (Lab Series #4) | Open Video
Uploaded: 2026-09-19T20:39:22+00:00
Duration: 23 min 42 s

0:01
[music]
0:06
>> Hello everyone. Let's continue our
0:08
Delinea PAM journey.
0:11
This is our third one in this series.
0:14
Previously, we already talked about how
0:16
to install Delinea server, how to
0:18
install RDM plus gateway, and how to
0:22
configure
0:24
monitor session, remote access,
0:27
web session, all those basic stuff using
0:31
a free Delinea server.
0:34
In this video, I'm going to show you how
0:35
to add license to learn you can test it
0:39
PAM feature. We also going to integrate
0:41
it with our domain controller, so we're
0:44
going to use in domain user to log in
0:46
and adding our first provider domain
0:48
user provider, so we can manage our
0:51
domain privilege account. Now, let's
0:54
start it.
0:59
Before we start the lab, let's go over
1:02
the topology again.
1:04
We have Windows 2025 with all service
1:08
required AD, DNS. We also installed the
1:13
Delinea servers, gateway, DB all-in-one
1:16
server to make it very simple. Also, I
1:19
have RDM client on the same machine for
1:21
testing.
1:23
I also have a workstation 10.0.0.5
1:27
this IP, which is same network as the
1:30
Delinea server to make it simple.
1:32
We can use the browser or RDM to log in
1:35
to simulating a user. Remote, we have
1:38
couple of remote target we can use for
1:41
testing.
1:42
The most important part we have some
1:45
service account and user account created
1:48
for this testing. We have vault DB
1:51
owner, domain admin user, which we used
1:55
to log in to our those machines to start
1:57
testing. We also have DVLS-Admin
2:01
this built-in admin account for
2:03
Devolutions Server. I also have this
2:06
service account provided for next step,
2:09
which is our domain user provider. Of
2:12
course, I have some test user accounts
2:15
and privileged user accounts. We going
2:17
to use this lab to testing pen function,
2:21
which is
2:22
just in time access. We log in with test
2:24
user. Then we can elevate our permission
2:27
to privileged account user, and then we
2:31
can do RDP, etc., etc.
2:34
So, now let's start the lab.
2:40
Currently,
2:42
we only able to sign in using our
2:44
Devolutions Server user. As a free
2:47
version, we only can sign in with one
2:49
user.
2:50
So, let's our built-in
2:55
There's no other authentication method
2:57
available since we haven't enable any.
2:59
But, what we going to do is we going to
3:01
enable our domain authentication.
3:05
So, go into administration, server
3:07
settings, authentication.
3:10
Authenticate with domain user. You also
3:13
have other options, but for this lab,
3:17
domain user authentication is enough. We
3:20
going to set up a Devolutions Server
3:21
user as our main primary authentication
3:24
method. You don't need to enable single
3:27
sign-on and emergency code
3:29
authentication. Save. Save button is
3:32
here.
3:34
As you can see, domain authentication is
3:36
available here now. But, we have to do
3:39
one more thing, enable license.
3:42
Because free license only allows just
3:45
one login.
3:46
Free version designed for solo work.
3:49
Let's do the 30-day trial. Then we can
3:52
use five users.
4:01
Sometimes, it may not working.
4:06
In this case,
4:07
you may need to enter your license and
4:09
to continue.
4:11
Let's add the existing key if you got it
4:13
from Devolutions trial or your customer
4:17
manager.
4:18
So, you can add it.
4:20
Add it or you also can import it.
4:24
So, either way works.
4:27
So, now our license has been added
4:30
successfully. You can enable auto assign
4:34
or you can assign to certain group.
4:37
But, for now,
4:39
we just
4:41
using this for demo
4:43
trial license.
4:44
So, we have signed out. Now, we should
4:47
be able to see we have new
4:50
authentication method Cyber to Local. As
4:53
mentioned before, we have a couple users
4:55
created.
4:56
DPN user one, DPN user two. We're going
4:59
to use one of them to log in.
5:05
Perfect. So, now we have integrated our
5:08
Devolutions Server with our domain.
5:15
Now, we have our license added. So,
5:18
let's go back in as a admin here.
5:21
Now, if you go to users,
5:24
you should be able to see multiple
5:26
users. Now, we have DVL as dash admin.
5:29
We also have
5:30
DPN user one at cyber to local as for
5:33
testing. Let's go to enable PAN for our
5:37
this lab.
5:38
We do have Devolutions Gateway. So, at
5:40
this moment, we have added license. But,
5:43
when we go to administration, we won't
5:45
be able to see PAM modules here, even we
5:49
already have license for it.
5:51
But we haven't assigned our privileged
5:54
access management license to anyone yet.
5:57
So, what are we going to do is we going
5:58
to assign to our DVLS-Admin.
6:02
So, we want to
6:04
our admin be able to use
6:08
PAM this module. So, now PAM module is
6:11
ready for us to use. Our next step is
6:15
going to add a new provider, which is a
6:18
domain user into our PAM solution, and
6:23
then we can manage our domain privilege
6:25
account.
6:30
As mentioned at the beginning, we're
6:32
going to log in as
6:34
the PAM user
6:36
and then elevating our privilege account
6:41
and then performing privilege tasks in
6:44
our target server.
6:46
That's our target. Of course, we are
6:48
able to locating our privilege account
6:53
users
6:54
password, and also we can use workflow
6:58
to approval change for access, and then
7:02
to session recording those kind of
7:05
tasks. So, we're going to demonstrate
7:07
that slowly step-by-step through here.
7:11
The first step we can of course we're
7:12
going to add the provider.
7:14
We're going to add domain user. This is
7:17
our provider. You have quite a few.
7:20
We're using Azure and ID or AWS, SQL
7:25
user, MongoDB user, and uh SSH.
7:31
We're going to use domain user. We're
7:33
going to use cyber.local
7:36
domain
7:37
user
7:38
domain name at our testing.
7:42
Domain controller
7:44
which is the same
7:50
same on the server because all in one
7:53
set up credential type
7:57
we're going to use
8:00
our service account here.
8:06
Test connection.
8:07
Now works.
8:09
You can use LDAP or LDAPS, that's a
8:12
matter.
8:13
And add it.
8:16
So, now we're going to add a new task
8:19
which is to do the account discovery.
8:21
Dovolutions able to use the account that
8:24
you configured to automatically discover
8:27
the account in your domain. So, we're
8:30
going to say domain user discovery. You
8:34
can
8:35
define
8:38
the OU
8:40
or you can choose multiple of them. So,
8:42
for this demo purpose I would just
8:45
choose two of them. Select.
8:47
You also can set up uh
8:49
recurrence. Repeat it every couple days.
8:54
You want to do it again. So, for demo
8:55
purpose, I'm going to leave it.
8:58
Once down, the domain user discovery
9:01
should automatically happen. You can go
9:03
back and and then look at account
9:05
discovery configuration which we already
9:08
defined through our domain user provider
9:12
creation process. So, status is queued.
9:16
So, we can let it run and we can all
9:18
come back later. But for now, we have
9:21
onboarded our provider here. There's a
9:24
couple policy you may want to define
9:27
which is account lifecycle policy,
9:30
password policy, also just-in-time
9:34
privilege elevation. And we will do that
9:37
later on. We can all test it to onboard.
9:40
our privilege account and we will see
9:43
how we can manage our privilege account.
9:47
Go back discovery.
9:49
You wait a bit once it's finished it we
9:51
will show you the result here.
9:55
One thing you might notice it may take a
9:57
very long time that usually caused by
10:02
scheduler.
10:03
As you can see scheduler
10:05
service isn't started yet so we can
10:09
quickly go to companions to start the
10:13
service.
10:15
Here you can see starting the scheduler
10:17
service.
10:18
With default installation the scheduler
10:21
service may not auto start it. So that's
10:25
something you may want to check. Once we
10:27
enable the scheduler service we got
10:31
eight results here.
10:34
We found eight
10:36
account
10:37
which we should be able to import it
10:40
into
10:41
our system the evolution system.
10:45
Here we have
10:46
DPM
10:48
privilege account one, DPM privilege
10:50
account two. So we going to lose two
10:52
because that's what we going to test
10:54
for. So we check both
10:57
and here
10:58
import selected account.
11:01
You need to put a destination.
11:04
So we can add
11:06
a pen vault.
11:07
So if you don't have a vault already
11:10
then you need to add it in. We don't
11:12
have one so this is first time so we
11:15
going to say
11:16
pen vault
11:18
for
11:20
domain visibility default
11:24
users
11:26
user groups
11:28
vault owners.
11:29
So we We want to have DPM user one to
11:34
take a look like. So, we just going to
11:36
check this one.
11:39
Add it.
11:40
Account life cycle policy, we didn't
11:42
create those policy yet like password
11:44
policy, account life cycle. We're going
11:46
to use the default one for now.
11:50
Here's the option. You can reset
11:51
password on import. We want to do that.
11:55
Once we import it, we want the our D
11:58
evolution to manage those privileged
12:00
account. That's the whole purpose why we
12:02
doing this.
12:03
Okay.
12:04
Close.
12:06
You will notice there's a new vault
12:08
created here, PAM vault. On the list PAM
12:12
domain vault, there are two accounts
12:14
here.
12:15
You can see history.
12:18
You can see more
12:20
password history.
12:22
Modified by DVL-admin.
12:25
Previously, there's no password.
12:28
Same as seen on the PAM preview 2.
12:32
What we can do here, we can
12:35
check out
12:36
and we can reset password.
12:40
We can do that. Let's give you a quick
12:42
check. Reset password line history.
12:44
Again, you can see the password has been
12:46
updated. Now, you should be able to see
12:49
password history what I have created
12:52
for. That's the new password.
12:54
Based on the password policy default one
12:57
and then they will reset it for you.
13:00
That's basic PAM procedures how you can
13:03
import it, onboard your privileged
13:05
account, and rotating the password. So,
13:08
our next step going to do a little bit
13:10
more which is just-in-time access. We're
13:13
going to elevate it into different
13:16
privilege. Right now, it's just domain
13:18
user. We're going to elevate it to a
13:19
higher privilege and then use it to log
13:22
into our destination.
13:28
So, in this screen, we're going to
13:30
configure three things. One is our
13:32
permission to allow our D Pen user one
13:35
to access
13:37
the Pen vault and also access those
13:39
privileged account. We also need to
13:41
configure just-in-time provisioning, so
13:44
they won't have access until they
13:46
request for it. And then, once the
13:49
domain approved the request, they will
13:51
have access. We call it just-in-time
13:53
provisioning. Then, we also would like
13:56
them to have just-in-time elevation. By
13:58
default, those accounts doesn't have
14:02
privileged permissions, such as domain
14:04
admins. They are not in domain admins
14:07
groups.
14:08
So, we're going to provide just-in-time
14:11
elevation.
14:12
So, when they request access, they also
14:15
can request elevated permission to
14:17
higher level, which is domain admin we
14:21
configured for D Pen privileged account
14:24
one. So, we will do that step-by-step.
14:26
The first thing we come into the
14:28
permission.
14:29
So, we go down to the vault level, give
14:31
the permission. By default, it's
14:33
disallowed.
14:36
Click add button, permissions.
14:39
Default, disallowed. We're going to
14:41
custom. We're going to
14:43
select
14:46
D Pen user one.
14:48
Um we're going to do
14:50
custom.
14:52
Going to grant access
14:53
D Pen user one.
14:55
We're going to give a couple
14:57
permissions, view,
15:00
view password, view sensitive
15:01
information,
15:03
connect, view password, view sensitive
15:06
information. Those will be for the
15:08
opening the browser web session. We also
15:10
want it to have checkout because level
15:13
required. If they want to checkout, we
15:16
want to enable that feature.
15:20
So, once we have that, select update.
15:23
We can open an alarm in private window.
15:27
That's simulating
15:30
the PAM user one to log in. Of course,
15:33
we need to change authentication mode.
15:35
Set it up to local. We going to use in
15:37
PAM user one, sign in. So, this is under
15:40
user PAM user one's view. You do see
15:44
they don't have administration menu
15:47
since they are not administrator.
15:50
But, they do able to see PAM domain one,
15:53
domain two.
15:58
They can do check out. They can request
16:00
check out.
16:03
Here's their permission what they have.
16:06
They also don't have access to the
16:08
server vault,
16:10
which we going to configure it later on.
16:13
So, that's their permission. Now, we
16:15
going to configure just-in-time
16:17
provisioning.
16:18
So, we go back to PAM privilege one. We
16:21
going to have properties.
16:24
We going to have check out policy.
16:27
We going to tell them this is custom
16:29
check out policy. Check out mode is
16:31
default mandatory. And then, we want to
16:34
have approval. Right now, it's no. So,
16:38
we going to have mandatory on JIT
16:40
elevation. If you don't want to elevated
16:43
privilege, then I don't need approval.
16:46
You can go ahead to use it. But, once
16:48
you go to JIT elevation, yes.
16:51
Okay, we can update that.
16:54
We also want to set up the privilege,
16:57
what kind of privilege they can elevate
17:00
to. So, that will go back to
17:02
administration.
17:05
PAM module, providers.
17:08
This is a provider we created. We going
17:10
to configure JIT privilege elevation.
17:14
Here, we going to choose a privilege,
17:17
which is
17:19
group DPA MRI one. So, this is a group
17:23
we already set up as a domain admin.
17:27
So, we want to elevate it that account
17:30
to this domain admin group.
17:35
There's a couple things you need to
17:36
configure. We're going to do
17:39
JIT, that's a prefix.
17:43
Temporary group creation location, it's
17:46
important. You may want to choose
17:48
the panda or test OU
17:50
account creation location. Same thing.
17:56
Choose the panda select.
17:58
Replication latency, yeah, maybe you
18:01
have some latency there. Once you
18:03
elevate it, you may want to give a
18:05
couple seconds for the replication to
18:08
other domain machines. So, let's go to
18:12
update.
18:13
So, that's the configuration. We also
18:15
want to have a
18:17
new vault.
18:20
Let's get the default vault. We're going
18:21
to campaign server.
18:25
We're going to give the user
18:27
access.
18:28
In the pen server, we're going to add a
18:30
new server.
18:32
RDP
18:46
So, here is important. We're going to
18:48
use a privilege account to log in.
18:50
By default, we don't want our regular
18:53
users able to log in to the server. We
18:56
want them to elevate them to a specific
18:59
privilege account permissions to log in.
19:02
So, then here is
19:04
So, we already configured the
19:07
privilege account, so we're going to
19:09
pick this one.
19:11
We're We're to use in the host IP
19:13
address easy. So, there's no option for
19:15
you username, domain, password because
19:17
we already chose the privilege account
19:19
to login.
19:21
So, you may want to enable
19:23
session recording, all those things, but
19:25
those are
19:26
not important at this moment. We just
19:30
going to
19:31
do basic settings and edit since we
19:34
going to testing other features.
19:38
Let's go back to users
19:40
portal.
19:41
Now, we should be able to see
19:44
this PAM server.
19:47
But at this moment, you can see the
19:49
vault, but you cannot see the server
19:51
under the vault. We still need to set up
19:53
permission.
19:55
Go back
19:56
to admin portal.
19:59
We going to add it permission
20:03
at the root level.
20:05
Default is disallowed.
20:07
We going to allowed.
20:10
We're a custom.
20:14
Grant access
20:16
to the user one. So,
20:19
for user one to use this server, he
20:21
should be able to
20:22
view it, view password, view sensitive
20:25
information, and then to connect. That's
20:27
pretty much everything
20:29
for this server.
20:33
Update.
20:35
Go back to user
20:37
portal here. Refresh.
20:40
Now, let's go back to ADM.
20:44
Let's sign in as the PAM user one.
20:52
Let's change authentication mode. The
20:55
PAM user one. Perfect. We logged in.
20:59
Based on the permission, you should be
21:01
able to see those vaults you have
21:04
access, which is PAM domain vault
21:08
for the domain privilege account or so
21:10
PAM server which is using
21:13
the PAM account to log into those
21:17
servers. So, we have test domain server
21:20
one which open session.
21:22
So, here is come through the interesting
21:25
part. Now, it's 4 hours. We need to
21:28
elevate permission. So, once you clicked
21:31
on that, you need to get the approval.
21:34
So, we give you or as the domain going
21:35
to approve that. Request check out.
21:39
So, request has been sent.
21:41
Now, we go back to
21:43
browser. This our DPM admin logged in.
21:49
You will see this messages.
21:53
Check out request.
21:55
Approval.
21:57
Once you're done, go back to RDM.
22:01
You can see this red email icon.
22:04
You will see those has been approved.
22:07
You can reply for it. This is a previous
22:09
one I tested.
22:11
Close the
22:12
open session again.
22:15
So, there's a 5 seconds we wait to wait.
22:20
Perfect. We logging again.
22:22
So,
22:23
run CMD.
22:26
Who am I?
22:28
DPM privilege one. Again, DPM privilege
22:32
one wasn't having the domain admin role
22:36
which RDP role to log into this server.
22:39
If you don't do elevation, you won't be
22:42
able to log in.
22:43
So, this is the devolution PAM how it
22:46
works, how to set up just-in-time
22:48
access, just-in-time elevation,
22:51
just-in-time privilege and also typical
22:54
PAM features. You also can do schedule,
22:57
location, schedule checking. Also, you
23:01
can do session recording this fancy
23:04
feature which we presented before. I
23:07
hope you enjoyed this video, learn
23:09
something from the revolution pen. If
23:12
you have any questions, leave me a
23:14
comment in this video and let me know. I
23:16
will reply back as long as possible.
23:18
Thank you for watching. See you in my
23:20
next video.
23:23
>> [music]
23:30
[music]
23:37
[music]

Devolutions PAM Configuration for JIT Provisioning and JIT Elevation (Lab Series #4)

51Security

Everyone's On Camera with the Nuroum 360 Pro All-In-One Conference Camera - DEMO & REVIEW

Supervised Learning | Classification and Regression | Machine Learning Tutorial | Tutorialspoint

Tim’s done, now it’s John’s Ternus (Cult of Mac Podcast #17)

META Ray-Ban Wayfarer – Fix Photos & Videos Not Syncing

The Offline & Private Innioasis R1 Digital Voice Recorder: Demo and Review

P1-M622-16DR Mini PLC: Is This Your Factory's New Best Friend?

Adding Outdoor Motorized Blinds to a Pergola/Hanging Bed | DIY Install

LENOVO Yoga Slim 7 – Fix Wi‑Fi Not Working

CODESYS Academy Training - Simple PLC Learning for Beginners

CODESYS PLC Course: Memory Bits and Latching Logic Program

Create Self Hosted Open Source Mulitiple Storage Management Site - OpenList [5 Min Docker]

Deploy Self Hosted & Open Source Privacy Focus Web Traffic Analytics Tool (Free & Easy)

Granola AI The Free AI That Records and Analyzes Your Meetings!

Bali Networking Hub | Stopped by Fear of Self-Doubt? (Raymonda's Mindset Masterclass)

Video Stuttering and Lagging in Windows 11

Up next in 10

Devolutions PAM Configuration for JIT Provisioning and JIT Elevation (Lab Series #4)

51Security
