hey what's up guys today we've got a
0:03
Toyota Corolla in the shop and if your
0:05
fuel pump isn't working this is the
0:08
video you need to see i'm going to show
0:10
you exactly where to find the fuel pump
0:12
relay the fuse that powers it and even a
0:15
couple bonus tips that could save you
0:18
hours of guesswork so let's pop the hood
0:26
all right starting with the 2003 to 2008
0:30
Corolla also known as the
0:33
E130 first things first right under the
0:36
hood we've got our main fuse box look
0:39
for a 20 a few fuse labeled EFI but
0:42
here's the catch don't confuse this with
0:45
the EFI number two this 20 amp FE fuse
0:49
is the one that actually sends power to
0:51
the fuel pump now let's talk relays
0:55
there's an FE relay sitting right here
0:57
next to the fuse this guy kicks in when
1:00
you turn the key to on and the computer
1:03
tells it "Hey time to wake up the fuel
1:06
pump." It passes power from that fuse
1:08
straight to the fuel pump relay
1:18
next up 2008 to 2013 the E14 O model go
1:24
ahead to the engine bay near the back
1:27
right corner closest to the driver so
1:29
here are the fuses that you need to
1:31
check the main EFI fuse is this yellow
1:35
20 amp fuse right here you can try to
1:38
wiggle it out look inside and make sure
1:41
the metal strip is intact you can also
1:44
check the 7.5 AMP fuse and the 10 AM
1:48
fuse because it is related to the fuel
1:50
system pop it out and check
1:59
it all right in the 2014 to 2018 Corolla
2:04
you need to pop that hood and go to the
2:06
driver's side fuse box right here under
2:08
this cover just press in on this tab and
2:11
lift the lid up now let's talk fuses
2:15
you've got two that matter first these
2:18
two little 10 fuses they responsible for
2:21
the multiport fuel injection system and
2:24
this one right here the 15 amp fuse
2:29
injectors see this little guy that's
2:32
your fuel relay and here's a cool trick
2:35
give this relay a few taps with a
2:37
screwdriver handle sometimes they stick
2:40
and a little jolt gets them working
2:50
again now for the new E210 Corolla from
2:56
2024 first check the under hood fuse box
2:59
in this location this is the engine fuse
3:02
panel on the M2A FKS and two ZR5 motors
3:08
so here are the relay that you need to
3:10
check there are two relay responsible
3:13
for the main multiport fuel injection
3:15
system this relay is the one that
3:18
actually sends power to the fuel pump
3:21
next check these three little guys they
3:24
are 10M in red color related to the fuel
3:27
injection system quick pro tip don't
3:30
just look at the fuse pull it out check
3:33
continuity or swap with a known good one
3:41
and that's it if this helped you out
3:44
give it a thumbs up drop a comment if
3:46
you've got questions or tips for other
3:49
Corolla owners and don't forget to
3:51
subscribe for more realworld car fix
3:54
guides catch you in the next one
