yo what's up guys welcome back to the
0:02
channel today I've got this Ford Focus
0:06
i'm going to show you exactly where the
0:08
horn fuse and horn relay are hiding so
0:11
if your horn's not honking this might be
0:13
your quick fix let's get right into
0:19
it starting off with the MK3 Focus this
0:23
one's a 2013 pop the hood and head over
0:27
to your fuse box right here on the
0:29
driver's side crack that open by
0:32
pressing these tabs boom you're in all
0:35
right now your horn fuse is this blue 15
0:38
amp fuse right here yep this guy pull it
0:42
out with the tool and test it for
0:44
continuity or just swap it with a known
0:46
good fuse if you're in a rush need a
0:49
quick swap to test it grab this one it's
0:52
your rear wiper fuse same 15 amps
0:55
that'll let you test the horn while you
0:57
go grab a replacement now for the horn
1:00
relay look right in this back corner
1:02
this little cube right here is your guy
1:05
if your fuse is good but the horn's
1:08
still dead this relay might be the
1:10
problem here's a cool trick have someone
1:13
press the horn while you tap on the
1:15
relay if it suddenly works your relay
1:18
might be sticking still not sure swap it
1:22
with this relay over here same type but
1:24
it controls the rear wiper easy way to
1:27
confirm without buying
1:37
parts now let's jump over to the MK4
1:40
focus 2019 through 2021 things moved
1:44
around a bit here the horn fuse is
1:46
located right here in the engine bay
1:48
fuse box yep that one between the
1:52
battery and the near side wing if you're
1:54
not sure how to open it up I've got a
1:56
full video showing you exactly how to
1:59
access it check that out later your horn
2:02
fuse is fuse number 37 and it's a yellow
2:07
microfuse same deal pull it out check
2:10
for continuity or swap in a spare 2 or a
2:13
microfuse to test it out unfortunately
2:16
the hoing relay on the MK4 is built into
2:19
the BCM body control module so it's not
2:23
a simple plugandplay swap like on the
2:26
MK3 but if the fuse is good and the horn
2:29
still won't work you might be looking at
2:38
issue and that's how you track down your
2:41
horn issues on both the MK3 and MK4 Ford
2:45
Focus if this helped you save time and a
2:48
trip to the shop hit that like button
2:51
drop your questions below and don't
2:53
forget to subscribe for more focus fixes
2:56
and DIY guides see you in the next one
