what's up everyone if your Ford Focus
0:03
isn't starting and you're wondering if
0:05
it's a fuse or relay issue you're in the
0:08
right place i'm going to show you
0:10
exactly where the starter fuse and relay
0:12
are fast and easy let's pop the hood and
0:20
in all right in the Ford Focus MK2 the
0:24
first things first pop the hood and head
0:26
over to the main fuse box this is where
0:29
the magic starts to open it just press
0:33
these tabs on both sides and lift the
0:35
cover off now check this out this right
0:38
here is your starter relay if your car
0:41
is just clicking or doing nothing when
0:43
you turn the key this could be the
0:45
culprit try this quick trick lightly tap
0:49
the relay while someone turns the key if
0:52
it's stuck this might free it up but
0:55
even better swap it with another working
0:57
relay like the blower motor or the rear
1:00
defrost now let's talk fuses the main
1:04
starter fuse is this big 30 JC case fuse
1:08
right here you can try to wiggle it out
1:11
just don't panic if the plastic cap
1:13
breaks it still works look inside and
1:16
make sure the metal strip is intact
1:23
let's head inside for the second fuse
1:26
box it is located inside the panel on
1:28
the steering wheel area you need to
1:31
remove the fuse panel by pulling that
1:33
out then pop open your fuse cover and
1:38
fuses so here they are it's this 20 amp
1:42
fuse right here it powers the ignition
1:45
switch pop it out and check it
1:59
next in the 2012 to 2018 Ford Focus
2:03
you'll find the fuse box right here on
2:05
the driver's side go ahead and remove
2:08
this cover just pull it up and set it
2:10
aside so here are the fuses that you
2:15
this little guy right here is your
2:17
starter relay if your car won't crank
2:20
this might be the issue try this have
2:24
someone turn the key to start while you
2:26
give this relay a light tap sometimes a
2:29
stuck relay just needs a little wakeup
2:31
call still not sure if it's the relay no
2:35
problem swap it with this one over here
2:38
that's your blower motor relay same type
2:41
just don't use the AU relay or you'll be
2:45
problems next up the starter fuse is
2:49
this big 30 amp JK's fuse right here you
2:53
can look through the top to check if
2:55
it's blown you'll see the metal strip
2:57
inside either intact or burnt need to
3:01
test it you can temporarily swap it with
3:04
this fuse over here that one's for your
3:06
rear window defroster not critical for
3:09
starting the car so it's a safe bet for
3:21
testing all right if you've got a four
3:24
focus MK4 and it's not starting listen
3:27
up this could save you a ton of hassle
3:31
the starter motor fuse is located right
3:33
here in the engine bay fuse box yep that
3:36
one between the battery and the near
3:38
side wing if you're not sure how to open
3:41
it up I've got a full video showing you
3:43
exactly how to access it check that out
3:46
later once you're in look for this red
3:50
30 amp mcase fuse that's your starter
3:53
motor fuse if the car is not cranking
3:56
this guy might be the culprit peek
3:58
through the top and check the metal
4:00
strip inside if it's broken or burnt
4:03
it's blown and remember always replace
4:06
it with the same 30 a.m pm case type no
4:10
guessing games here still having issues
4:13
check the wiring or test the outlet with
4:15
another device sometimes it's not just
4:24
fuse now let's move inside the car yep
4:27
we're heading to the cabin fuse box it's
4:30
tucked away under the passenger side
4:32
console you might have to pop off a
4:34
cover to get to it but no tools needed
4:37
here's what you're looking for this is a
4:40
red 10 micro 2 fuse this one controls
4:44
your ignition switch if it's blown your
4:48
car won't even try to start need a
4:51
replacement just ask for a micro 210 a.m
4:54
fay fuse at any auto parts store they're
5:02
and that's a full breakdown of the
5:04
starter circuit on the Ford Focus
5:06
hopefully this helps you get your car
5:08
cranking again drop a comment if you've
5:11
got questions or if you've got a tip for
5:14
troubleshooting the system like
5:16
subscribe and I'll see you in the next
