Cigar Tube Circuit Tester - Troubleshooting Your Breadboard - Checking Voltage Source

Name: Cigar Tube Circuit Tester - Troubleshooting Your Breadboard - Checking Voltage Source | Open Video
Uploaded: 2024-10-11T12:07:47+00:00
Duration: 1 min 54 s

0:00
Trouble Shooting
0:05
Okay, here I have a 9-volt battery. I'm going to call it the black battery
0:10
I'm going to connect the positive terminal to the positive lead of the circuit, and I'm going
0:14
to connect the negative terminal of the battery to the negative lead of the circuit
0:19
Here you can see the white LED is lit, but it's not lit up as bright as I'd like it to be
0:25
Again, if I switch the leads around, you can see the red LED
0:29
LED barely light up. I'm thinking that the battery is probably low. It's an old battery
0:36
Here is another 9-volt battery. I'm going to call it the blue battery. Again, I'm going to connect the leads to this 9-bolt battery
0:45
And we'll see the white LED much brighter now. This is a newer 9-volt battery. And now I'm going to switch the leads around
0:55
And you can see the red LED is much brighter here for the blue battery
1:01
Okay, what I'm going to do here is test each of the 9-volt batteries
1:06
First, I'll test the black battery. This is the one that is the older of the two batteries
1:12
and I suspect that it's low in voltage. As you can see here, it's reading just over 4 volts
1:19
which is very low for this 9-volt battery. Next, I'll test the blue 9 volt battery
1:27
It is a newer battery, but it has been used quite a bit and several different tests I've done in the past
1:37
You can see that it reads almost 9 volts. It's not ideal, but it is higher in voltage than the black battery
1:44
So this may be a reason why you have dim LEDs in your circuit
1:50
Just test out a new battery and see. if that helps
