tutorial so basically gr tool in a
0:52
freead is a tool to Revol a sketch or
0:56
profile about and access cutting out the
0:58
material from the supports so grou tool
1:01
is a very similar to the Revol tool in
1:04
freead the difference is that grou tools
1:07
used for to remove the material if you
1:10
see this uh sketch so here B is the axis
1:19
and this profile a revolves with respect
1:23
to the this AIS B and material got
1:26
removed so let's see with a example
1:30
so here I have activated the part design
1:33
workbench now I will create a
1:36
file I insert a body and on my origin
1:41
plane now I will select this YZ plane
1:46
sketch I will off my origin plane and
1:50
now I will uh create a
1:58
rectangle and let let's give the
2:00
dimension select the horizontal
2:04
300 and this uh vertical
2:15
0mm and uh come out of the
2:22
isometric and now first we will revolve
2:26
it we will select the reference
2:36
it and where is our sketch yes here is
2:41
sketch we will on our
2:44
plane now we will select the sketch
2:47
click on the revolve tool and from here
2:50
we will select our reference so I will
2:52
revolve around this y AIS and click on
2:57
okay now I will off my origin plane
2:59
switch to the right side view and now
3:03
here for example I wanted to insert a
3:08
external retaining ring also known as a
3:11
circlip so for this I will on my origin
3:16
plane and I will select this YZ plane
3:23
sketch and I create a
3:36
I will switch to the wire
3:42
frame and let's give some random
3:58
vertical vertical 50 mm just approximate
4:04
uh give this horizontal
4:13
this vertical dimension of let's say
4:17
50 now we will close our
4:21
sketch switch to the Flatline
4:25
views and off our origin plane and now
4:30
we will remove the material with the
4:32
help of a Groove tool we will select the
4:35
sketch and click on the
4:37
groove so here freead has took this Z
4:41
axis so I will select it and click on
4:45
axis so you can see that a Groove has
4:49
been created here let's modify the
5:07
let's make it uh to the 30
5:14
60 and close it so you can see that
5:17
group profile has been
5:19
modified so this is the material removal
5:24
operations to remove the material with
5:27
the help of a Groove tool this Revol
5:31
tool and groove tools are very similar
5:34
this is the material addition process
5:36
where Groove is a material removal
5:38
process so this is all about this
