descriptions so here I will create a new
3:16
file and I will insert my body and on
3:20
the origin plane and let's select this
3:22
front plane and click on the sketch and
3:26
of the origin plane by pressing the
3:28
space bar now here I will uh create an
3:42
slot and I will merge the arc center
3:50
origin make it a coincidence and
3:55
now we will uh constrain it select uh
4:00
smart dimension and provide this radius
4:04
mm and uh this radius
4:09
200 and now I will uh move this
4:15
point and here I will create a
4:19
construction line to join the origin
4:21
with this arc center so select a line
4:25
tool select this and this and uh made it
4:31
construction so here is a toggle
4:36
and select the line tool and join
4:42
this and we will also make it a
4:46
construction now we will give the
4:49
angular dimension so select the
4:53
angular dimension and provide the angle
4:59
way we will also provide here
5:05
here in the case if you wanted to keep
5:09
the dependency of a one angular
5:11
dimension on other for example if I
5:14
change this angle this will get
5:17
automatically changed
5:19
let's see it let's for example if I make
5:22
it 55 so this is become 55 but it is a
5:26
45 so we will link these two dimension
5:30
so let's see how we can link it so here
5:33
I will again make it a 45 and edit this
5:38
dimension and here I will give the name
5:43
so here it is an angular dimension
5:46
so for my understanding I will give the
5:50
angular dimension alphabet A and it is
5:54
the first angular dimension so I will
5:58
A1 and say okay so name is given here
6:03
and now on the second dimension we will
6:05
edit it and here you will find the
6:10
expression so we will click on here
6:12
expression icon and here we will type
6:16
constraints so once you type the first
6:19
two alphabets you will get here so click
6:21
on the constraint dot and here we are
6:25
seeing the A1 because frecad have saved
6:28
this and we will select A1 so constraint
6:31
dot A1 and we can see the result is 45
6:38
now this is a driving dimension and this
6:41
is the driven dimension so once we
6:44
change the driving dimension let's if I
6:46
make it 60 so you can see that uh this
6:50
dimension is changed to
6:57
30 so this dimensions become 30 if I
7:03
uh 75 so you can see that my dimension
7:07
is changed to the 75 bottom one if I
7:13
20° so you can see that it is a
7:17
perfectly changing so this is how you
7:20
can uh link the dimension in a frecat
7:23
sketch so this is the very simple
7:25
example I took for the slot and this
7:28
method is applicable to the any type of
7:30
a dimension either it is a linear
7:32
dimension angular radius diameter
7:36
anything else so this is how we can uh
7:40
interlink the two dimension in a fread
7:43
thank you for watching and thank you for
