We can make use of Flow to create Salesforce Service Appointments from the Agentforce Agent.
Blog Post:
https://www.infallibletechie.com/2025/02/salesforce-service-appointment-scheduling-using-agentforce.html
Show More Show Less View Video Transcript
0:07
hello everyone in this video we are
0:09
going to see how to schedule service
0:12
appointments using Salesforce agent
0:15
force
0:17
agent I'm going to make use
0:20
of service agent force agent in order to
0:25
schedule service appointments
0:31
whenever we make use of
0:33
uh the standard uh field service
0:38
dispatcher
0:39
actions uh this particular topic have
0:43
good standard actions to take care of uh
0:46
Salesforce field service uh uh business
0:50
process uh but uh as of now it is not uh
0:53
allowing me to schedule an appointment
0:56
so I'm not going to make use of the
0:57
standard one since I have a requirement
1:00
to schedule service appointment I'm
1:02
going with the custom flow
1:05
development I created a topic called
1:10
appointment I have given the
1:12
classification description scope the
1:15
scope is to create service appointments
1:17
for the asset
1:18
records I have given two instructions
1:22
the first instruction is to get the
1:24
asset name from the user so that it will
1:26
fetch the asset record and then it will
1:28
try to find whether that particular
1:30
asset record is found in the system if
1:32
it is not found it will say asset record
1:35
is not found if it is found it will ask
1:38
the start and end date time from the
1:41
user so that it can schedule the service
1:43
appointment so I have done with the
1:47
instructions let me activate
1:53
it okay it is already
1:57
active I'm going to make use of
2:00
Salesforce messaging for inapp and web
2:02
feature to test
2:05
this
2:07
first let's jump onto the
2:11
demo so I'm initiating my Salesforce
2:13
messaging for inapp and web it will
2:15
invoke agent force service agent through
2:18
Omni Channel flow I will say I need
2:25
appointment it will ask the asset name
2:30
as per the instructions that are set
2:32
yeah it is asking for the
2:34
asset so I'm going to make use of this
2:37
sample asset record in me
2:45
or now it will fetch the asset record it
2:48
will say that the asset record is found
2:51
and it will ask the start and end day
2:53
time so let me say this is my start and
2:56
end date
2:58
time 14th February 2025 from 2 12:00
3:02
p.m. to 2: p.m. very important thing to
3:05
note here is whatever information we
3:06
pass it here for the date and time it
3:09
will be passed in uh GMT or UTC uh it is
3:13
our responsibility to convert this into
3:17
um the time zone of the user in order to
3:20
save properly in Salesforce so with this
3:23
is very very important uh thing to note
3:26
so I'm saying I wanted an appointment
3:29
are on 14th of February from 12:00 p.m.
3:33
from 1200 p.m. to 2: p.m. now it will
3:35
convert it into um GMT or UTC and then
3:40
it will save um so so the timing will be
3:44
different uh so let's look at this
3:47
particular service appointment which got
3:48
created in
3:51
mayor so this is the one which got
3:54
created so it is I'm I'm in easn
3:57
Standard time zone so GM minus 5 so that
4:01
is the reason it is displaying it at 7
4:03
a.m. to 9:00 a.m. um we can make use of
4:07
a variable in the flow plus or minus
4:10
based on the time zone and then if we
4:12
should be able to uh create the record
4:15
with the proper time zone of the
4:18
user let's see the technical uh um
4:22
development behind this so in this
4:24
appointment topic I have two different
4:26
actions one is Fitch asset which is a
4:29
flow
4:30
um um action so this uh fetch asset
4:35
agent action will invoke this flow in
4:37
order to invoke that flow I will be
4:39
passing the asset name which is an input
4:41
variable and then it will return the
4:43
asset record which is an output
4:46
variable first let's look at the
4:48
variables so this is an output variable
4:51
which will be returned and it will be
4:55
displayed and asset name is an input
4:58
variable I will get the asset name use
5:01
the get records flow element from uh
5:04
Salesforce flow
5:06
elements I'm using name equals to the
5:09
asset name if you want to have like
5:11
operator you can definitely
5:13
have and then I'm storing that
5:15
particular ID asset level city and name
5:18
from the asset record onto this asset
5:21
record which is an output
5:26
variable now let's look at this schedule
5:29
appointment M this is
5:33
another flow action here I'm referencing
5:37
this flow in order to invoke that flow
5:40
we have to pass the asset record which
5:42
was fed in the previous uh um agent
5:46
action and then we have to pass the due
5:48
date time and earliest start permited
5:52
these three information should be passed
5:54
to the flow as an input variable and it
5:57
will return return the appointment
5:59
number this this is an output variable
6:00
on the flow which will be displayed on
6:02
the
6:03
conversation here I'm making use of
6:06
create records flow element to create
6:08
service appointment record with the due
6:10
date earli start permitted and for the
6:13
parent record ID I'm using the asset
6:15
records as uh record ID here uh asset
6:19
record is an input variable appointment
6:22
number is an output Vari output variable
6:25
due date time earliest start permitted
6:28
or also another input VAR
6:37
variable um so what it will do is it
6:40
will create the service appointment
6:41
record it will fetch the newly created
6:43
service appointment record it will
6:45
assign the service appointment
6:47
appointment number to this appointment
6:50
number variable which is an output
6:51
variable and this appointment number was
6:54
passed back to the conversation pane
6:57
where we were able to see it
7:03
please check the video description in
7:05
the video description I have shared my
7:07
blog post from the blog post you should
7:09
be able to get screenshots of this flow
7:12
and uh some additional instructions
7:15
which will be uh very helpful so that
7:18
you can refer and do a custom
7:20
appointment schedular for your use
7:26
cases I hope it was helpful
7:30
thank you for watching
