0:00
Determine in which area you would like to install your QuietCool Solar Attic Gable Fan
0:15
Find the contact points between the roof and the back side of the solar panel
0:19
Apply adhesive to the roof and firmly secure the panel to the surface
0:38
Now it's time to run the solar panel plug-in cord from the solar panel into the attic through
0:58
Be sure to include a drip curve in the wire to ensure no water can run down the solar
1:02
panel plug-in cord and enter the attic through the gable vent
1:14
Fasten the fan to the vent frame studs
1:27
Once fastened, tighten the eight mounting bracket nuts to secure the fan flush to the
1:31
gable vent. Now connect the wire to your solar panel plug-in module
1:44
The AFG-SLR will automatically turn on if there is sunlight and the temperature is above
1:49
75 degrees Fahrenheit. Plug the inverter plug-in cord into the outlet so you can experience 24-7 cooling all year long
2:05
Call 1-888-QUIET-COOL or visit quietcoolsystems.com for more information
